EM-100 < DISASSEMBLY AND ASSEMBLY > CYLINDER HEAD Disassembly and Assembly INFOID:0000000003802291 DISASSEMBLY 1. Remove spark plug with spark plug wrench (commercial service tool). 2. Remove valve lifter. 3. Remove valve collet. KV10116200 (J26336-A)] (A), the attachment [SST: CAUTION: When working, take care not to damage valve lifter holes. 4. Remove valve spring retainer, valve spring and valve spring seat. 5. Push valve stem to combustion chamber side, and remove valve. 6. Remove valve oil seal with the valve oil seal puller [SST: 7. Remove valve seat, if valve seat must be replaced. recess in cylinder head. Set the machine depth stop to ensure this. Refer to CAUTION: Prevent to scratch cylinder head by excessive boring. 8. Remove valve guide, if valve guide must be replaced. a. To remove valve guide, heat cylinder head to 110 to 130 ° C (230 to 266 ° F) by soaking in heated oil (A). JPBIA0180ZZ JPBIA0177ZZ JPBIA0184ZZ |
