OUTSIDE KEY ANTENNA

DLK-239

< ON-VEHICLE REPAIR >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

2.

Remove the outside key antenna (rear bumper) mounting clips
(A), and then remove outside key antenna (rear bumper) (1).

INSTALLATION

Install in the reverse order of removal.

JMKIA2444ZZ

DLK-240

< ON-VEHICLE REPAIR >

[WITH INTELLIGENT KEY SYSTEM]

INTELLIGENT KEY WARNING BUZZER

INTELLIGENT KEY WARNING BUZZER

Exploded View

INFOID:0000000003795140

Removal and Installation

INFOID:0000000003795141

REMOVAL

1.

Remove the Intelligent Key warning buzzer mounting nut (A),
and then remove the Intelligent Key warning buzzer (1).

INSTALLATION

Install in the reverse order of removal.

1.

Intelligent Key warning buzzer

JMKIA2435ZZ

JMKIA2445ZZ

KEY SLOT

DLK-241

< ON-VEHICLE REPAIR >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

KEY SLOT

Exploded View

INFOID:0000000003795142

Removal and Installation

INFOID:0000000003795143

REMOVAL

1.

Remove the instrument lower panel LH. Refer to

IP-12, "Removal and Installation"

.

2.

Disconnect key slot connector.

3.

Remove the key slot mounting screws (A), and then remove key
slot (1) from instrument lower panel LH.

INSTALLATION

Install in the reverse order of removal.

1.

Key slot

2.

Instrument lower panel

JMKIA1820ZZ

JMKIA2351ZZ

DLK-242

< ON-VEHICLE REPAIR >

[WITH INTELLIGENT KEY SYSTEM]

TRUNK LID OPENER REQUEST SWITCH

TRUNK LID OPENER REQUEST SWITCH

Exploded View

INFOID:0000000003846685

Refer to

EXT-38, "Exploded View"

.

Removal and Installation

INFOID:0000000003846686

REMOVAL

1.

Remove the trunk lid finisher outer. Refer to

EXT-38, "Removal and Installation"

.

2.

Remove the trunk lid opener request switch mounting pawl (A),
and then remove trunk lid opener request switch (1) from inner
bracket.

INSTALLATION

Install in the reverse order of removal.

:

Pawl

JMKIA2446ZZ
