EC-364 < DTC/CIRCUIT DIAGNOSIS > [VQ35DE] P1551, P1552 BATTERY CURRENT SENSOR 3. Disconnect battery negative cable (1). 4. Install jumper cable (A) between battery negative terminal and 5. Turn ignition switch ON. 6. Check the voltage between ECM harness connector terminals Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to . Is the inspection result normal? YES >> INSPECTION END NO >> Replace battery negative cable assembly. : Vehicle front : To body ground ECM Voltage (V) Connector + – Terminal Terminal F8 42 (Battery current sensor signal) 44 (Sensor ground) Approx. 2.5 ALBIA0076ZZ |
