DLN-66 < UNIT DISASSEMBLY AND ASSEMBLY > [TRANSFER: TY20A] DRIVE PINION 8. Remove pinion sleeve oil seal from the pinion sleeve with a suit- CAUTION: Be careful not to damage the pinion sleeve. 9. Remove pinion rear bearing inner race. 10. Remove the pinion rear bearing outer race with the puller (A) [SST: KV381054S0 (J-34286)]. 11. Remove the pinion front bearing outer race with the puller (A) [SST: KV381054S0 (J-34286)]. 12. Remove dust cover. 14. Using the replacer (A) (commercial service tool), press the pin- ion front bearing inner race out of the drive pinion. Assembly INFOID:0000000005514224 1. Select the pinion sleeve shim. Refer to 2. Install dust cover. TFB0286D JPDIE0026ZZ JPDIE0027ZZ JPDIE0028ZZ |
