RF-76

< ECU DIAGNOSIS INFORMATION >

SUNSHADE MOTOR ASSEMBLY

JRKWC8143GB

SUNSHADE MOTOR ASSEMBLY

RF-77

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

JRKWC8144GB

RF-78

< SYMPTOM DIAGNOSIS >

SUNROOF DOES NOT OPERATE PROPERLY

SYMPTOM DIAGNOSIS

SUNROOF DOES NOT OPERATE PROPERLY

Description

INFOID:0000000009719673

Sunroof does not operate normally.
• Glass lid does not slide or tilt.
• Judder occurs during sliding operation of glass lid.
• Sliding or tilting operation of glass lid is slow.

Diagnosis Procedure

INFOID:0000000009719674

1.

CHECK GLASS LID

Check the following items.
• Cracks, damage, or deformation of weather-strip.
• Sticking of weather-strip.
• Loose or missing glass lid mounting blot.
• Misalignment of glass lid.

Refer to

RF-98, "Adjustment"

.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair or replace the malfunctioning parts.

2.

CHECK SUNROOF FRAME ASSEMBLY

Check the following items.
• Damage, deformation or trapped foreign material of slide rail.
• Insufficient application of grease to sliding section of slide rail.

Refer to

RF-114, "Disassembly and Assembly"

.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace the malfunctioning parts.

3.

CHECK SUNSHADE

Check sunshade for damage, deformation, of interference with other parts.
Refer to

RF-124, "Removal and Installation"

.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace the malfunctioning parts.

4.

CHECK SUNROOF MOTOR ASSEMBLY POWER SUPPLY AND GROUND CIRCUIT

Check sunroof motor assembly power supply and ground circuit.
Refer to

RF-12, "SUNROOF MOTOR ASSEMBLY : Diagnosis Procedure"

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Repair or replace the malfunctioning parts.

5.

CHECK SUNROOF SWITCH

Check sunroof switch.
Refer to

RF-16, "Diagnosis Procedure"

.

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Repair or replace the malfunctioning parts.

6.

CONFIRM THE OPERATION

Confirm the operation again.

Is the result normal?

YES

>> Check intermittent incident. Refer to

GI-44, "Intermittent Incident"

.

SUNROOF DOES NOT OPERATE PROPERLY

RF-79

< SYMPTOM DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

NO

>> GO TO 1.
