RF-64

< ECU DIAGNOSIS INFORMATION >

SUNROOF MOTOR ASSEMBLY

8

(BR)

Ground

Vehicle speed signal
(2-pulse)

Input

Speed meter operated [When vehicle
speed is approx. 40km/h (25MPH)]

9

(W)

Ground

Sunroof switch signal
(2nd)

Input

Sunroof switch

OPEN or
CLOSE
(2nd)

0

Other than
above

Battery voltage

10

(V)

Ground

Sunroof switch signal
(CLOSE)

Input

Sunroof switch

CLOSE
(1st and 2nd)

0

Other than
above

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Voltage (V)

(Approx.)

+

-

Signal name

Input/

Output

ELF1080D

SUNROOF MOTOR ASSEMBLY

RF-65

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

Wiring Diagram - SUNROOF CONTROL SYSTEM -

INFOID:0000000009719670

JRKWC0976GB

RF-66

< ECU DIAGNOSIS INFORMATION >

SUNROOF MOTOR ASSEMBLY

JRKWC8140GB

SUNROOF MOTOR ASSEMBLY

RF-67

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

JRKWC8141GB
