AV-202

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

DISPLAY UNIT

19

(B)

Ground

RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(R)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

Shield

—

—

—

—

22

(L)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display
brightness.

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3603E

SKIB3598E

PKIB5039J

AV

BOSE AMP.

AV-203

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE AMP.

Reference Values

INFOID:0000000009721727

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA1223ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(LG)

2

(V)

Sound signal front squawk-
er LH

Output

Ignition

switch

ON

Sound output

4

(P)

3

(L)

Sound signal front squawk-
er RH

Output

Ignition

switch

ON

Sound output

7

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

10

(SB)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

11

(GR)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

12

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

13

(GR)

8

(BR)

Sound signal woofer

Output

Ignition

switch

ON

Sound output

SKIB3609E

SKIB3609E

SKIB3609E

AV-204

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE AMP.

14

(L)

9

(O)

Sound signal rear door
speaker RH

Output

Ignition

switch

ON

Sound output

16

(GR)

17

(BR)

Sound signal rear speaker

Output

Ignition

switch

ON

Sound output

18

(W)

19

(B)

Sound signal front door
speaker LH

Output

Ignition

switch

ON

Sound output

20

(SB)

Ground

Amp. ON signal

Input

Ignition

switch

ACC

—

12.0 V

24

(GR/V)

23

(W/L)

Sound signal rear LH

Input

Ignition

switch

ON

Sound output

26

(GR/V)

25

(W/L)

Sound signal rear RH

Input

Ignition

switch

ON

Sound output

28

(G)

15

(R)

Sound signal rear door
speaker LH

Output

Ignition

switch

ON

Sound output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-205

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

29

(V)

30

(P)

Sound signal center speak-
er

Output

Ignition

switch

ON

Sound output

31

(BR)

32

(Y)

Sound signal front door
speaker RH

Output

Ignition

switch

ON

Sound output

33

(W/R)

34

(B/R)

Sound signal front RH

Input

Ignition

switch

ON

Sound output

35

(W/R)

36

(B/R)

Sound signal front LH

Input

Ignition

switch

ON

Sound output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
