AV-194

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

AV CONTROL UNIT

40

(W)

Ground

RGB area (YS) signal

Output

Ignition

switch

ON

At RGB image is displayed.

5.0 V

At AUX image is displayed.

41

—

Shield

—

—

—

—

42

(B)

Ground

RGB synchronizing signal

Output

Ignition

switch

ON

—

43

(G)

Ground

RGB signal (R: red)

Output

Ignition

switch

ON

Start Confirmation/Adjust-
ment mode, and then dis-

play color bar by selecting

“Color Spectrum Bar” on

Display Diagnosis screen.

44

(L)

Ground

RGB signal (G: green)

Output

Ignition

switch

ON

Start Confirmation/Adjust-
ment mode, and then dis-

play color bar by selecting

“Color Spectrum Bar” on

Display Diagnosis screen.

45

(Y)

Ground

RGB signal (B: blue)

Output

Ignition

switch

ON

Start Confirmation/Adjust-
ment mode, and then dis-

play color bar by selecting

“Color Spectrum Bar” on

Display Diagnosis screen.

46

(V)

Ground

Composite image signal
ground

—

Ignition

switch

ON

—

0  V

47

(LG)

Ground

Composite image signal

Output

Ignition

switch

ON

At camera image is dis-
played.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

PKIB4948J

SKIB3603E

SKIB2238J

SKIB2236J

SKIB2237J

SKIB2251J

AV

AV CONTROL UNIT

AV-195

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

48

(Y)

Ground

Inverter VCC

Output

Ignition

switch

ACC

—

9.0 V

49

(BR)

Ground

Inverter ground

—

Ignition

switch

OFF

—

0  V

50

(R)

Ground

Vertical synchronizing (VP)
signal

Input

Ignition

switch

ON

—

51

(P)

Ground

Communication signal
(CONT

→

DISP)

Output

Ignition

switch

ON

When adjusting display
brightness.

52

—

Shield

—

—

—

—

57

—

Shield

—

—

—

—

58

—

Shield

—

—

—

—

61

(Y)

Ground

AUX image signal

Input

Ignition

switch

ON

At AUX image is displayed.

62

(R)

Ground

Camera image signal

Input

Ignition

switch

ON

At camera image is dis-
played.

69

(BR)

Ground

AUX image signal ground

—

Ignition

switch

ON

—

0  V

70

—

Shield

—

—

—

—

71

—

Shield

—

—

—

—

72

(LG)

Ground

Camera ground

—

Ignition

switch

ON

—

0  V

73

(V)

Ground

Camera power supply

Output

Ignition

switch

ON

Selector lever is in “R” posi-
tion.

6.0 V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3598E

PKIB5039J

SKIB2251J

SKIB2251J

AV-196

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

AV CONTROL UNIT

76

(LG)

—

AV communication signal
(L)

Input/

Output

—

—

—

77

(SB)

—

AV communication signal
(H)

Input/

Output

—

—

—

78

(LG)

—

AV communication signal
(L)

Input/

Output

—

—

—

79

(SB)

—

AV communication signal
(H)

Input/

Output

—

—

—

80

(P)

—

CAN–L

Input/

Output

—

—

—

81

(L)

—

CAN–H

Input/

Output

—

—

—

82

(V)

Ground

Switch ground

—

Ignition

switch

ON

—

0  V

86

—

Shield

—

—

—

—

87

(R)

88

(L)

TEL voice signal

Input

Ignition

switch

ON

During voice guide output

with the



 switch

pressed.

92

(V)

Ground

Vehicle speed signal (8-
pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).

93

(LG)

Ground

Parking brake signal

Input

Ignition

switch

ON

Parking brake is applied.

4.5 V

Parking brake is released.

0 V

94

(SB)

Ground

Reverse signal

Input

Ignition

switch

ON

Selector lever is in R posi-
tion.

12.0 V

Selector lever is in other
than R position.

0 V

95

(G)

Ground

Ignition signal

Input

Ignition

switch

ON

—

Battery voltage

96

(W)

Ground

Disk eject signal

Input

Ignition

switch

ON

Pressing the eject switch.

0 V

Except for above.

5.0 V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output
