MIR-26

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

DRIVER SEAT CONTROL UNIT

TILT SW-UP

Tilt switch

Upward

ON

Other than above

OFF

TILT SW-DOWN

Tilt switch

Downward

ON

Other than above

OFF

TELESCO SW-FR

Telescopic switch

Forward

ON

Other than above

OFF

TELESCO SW-RR

 Telescopic switch

Backward

ON

Other than above

OFF

DETENT SW

Selector lever

P position

OFF

Other than above

ON

STARTER SW

Ignition position

Cranking

ON

Other than above

OFF

SLIDE PULSE

Seat sliding

Forward

The numeral value decreases *

Backward

The numeral value increases*

Other than above

No change to numeral value*

RECLN PULSE

Seat reclining

Forward

The numeral value decreases*

Backward

The numeral value increases

*

Other than above

No change to numeral value

*

LIFT FR PULSE

Seat lifter (front)

Up

The numeral value decreases

*

Down

The numeral value increases

*

Other than above

No change to numeral value

*

LIFT RR PULSE

Seat lifter (rear)

Up

The numeral value decreases

*

Down

The numeral value increases

*

Other than above

No change to numeral value

*

MIR/SEN RH U–D

Door mirror (passenger side)

Change between 3.4 (close to peak)

0.6 (close to valley)

MIR/SEN RH R–L

Door mirror (passenger side)

Change between 3.4 (close to left edge)

0.6 (close to right edge)

MIR/SEN LH U–D

Door mirror (driver side)

Change between 3.4 (close to peak)

0.6 (close to valley)

MIR/SEN LH R–L

Door mirror (driver side)

Change between 0.6 (close to left edge)

3.4 (close to right edge)

TILT PULSE

Tilt position

Upward

The numeral value decreases

*

Downward

The numeral value increases

*

Other than above

No change to numeral value

*

TELESCO PULSE

Telescopic position

Forward

The numeral value decreases

*

Backward

The numeral value increases

*

Other than above

No change to numeral value

*

STEERING STATUS

NOTE:
This item is displayed, but cannot be monitored

VEHICLE SPEED

The condition of vehicle speed is displayed

km/h

P RANG SW CAN

Selector lever

P position

ON

Other than above

OFF

Monitor Item

Condition

Value/Status

DRIVER SEAT CONTROL UNIT

MIR-27

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

*

: The value at the position attained when the battery is connected is regarded as 32768.

TERMINAL LAYOUT

PHYSICAL VALUES

R RANGE (CAN)

Selector lever

R position

ON

Other than above

OFF

DOOR SW-FL

Driver door

Open

ON

Close

OFF

DOOR SW-FR

Passenger door

Open

ON

Close

OFF

IGN ON SW

Ignition switch

ON position

ON

Other than above

OFF

ACC ON SW

Ignition switch

ACC or ON position

ON

Other than above

OFF

KEY ON SW

Intelligent Key

Inserted is key slot

ON

Inserted is not key slot

OFF

KEYLESS ID

UNLOCK button of Intelligent Key is pressed

1,2,3,4or5

KYLS DR UNLK

Intelligent Key or driver
side door request switch

ON

ON

OFF

OFF

VHCL SPEED (ABS)

Can signal from ABS

Received

ON

Not received

OFF

HANDLE

The BCM for handle position is displayed

LHD

RHD

TRANSMISSION

Transmission type is displayed

AT or CVT

MT

Monitor Item

Condition

Value/Status

JMJIA1689ZZ

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx)

+

-

Signal name

Input/

Output

1

(R)

Ground

Power source

Input

—

Battery voltage

2

(B)

Ground

Ground (power)

—

—

0

3

(G)

Ground

Sliding motor backward
output signal

Output

Seat sliding

Operate

(backward)

Battery voltage

Stop

0

MIR-28

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

DRIVER SEAT CONTROL UNIT

4

(G/R)

Ground

Sliding motor forward out-
put signal

Output

Seat sliding

Operate

 (forward)

Battery voltage

Release

0

5

(V)

Ground

Reclining motor backward
output signal

Output

Seat reclining

Operate

(backward)

Battery voltage

Stop

0

6

(R/L)

Ground

Reclining motor forward
output signal

Output

Seat reclining

Operate

 (forward)

Battery voltage

Release

0

7

(L)

Ground

Lifting motor (rear) down
output signal

Output

Seat lifting (rear)

Operate

(down)

Battery voltage

Stop

0

8

(L/W)

Ground

Lifting motor (rear) up out-
put signal

Output

Seat lifting (rear)

Operate

(up)

Battery voltage

Stop

0

9

(L/R)

Ground

Lifting motor (front) down
output signal

Output

Seat lifting (front)

Operate

(down)

Battery voltage

Stop

0

10

(L/B)

Ground

Lifting motor (front) up out-
put signal

Output

Seat lifting (front)

Operate

(up)

Battery voltage

Stop

 0

11

(G/B)

Ground

Sliding switch backward
signal

Input

Sliding switch

Operate

(backward)

0

Release

Battery voltage

12

(G/W)

Ground

Sliding switch forward sig-
nal

Input

Sliding switch

Operate

 (forward)

0

Release

Battery voltage

13

(R/G)

Ground

Reclining switch backward
signal

Input

Reclining switch

Operate

(backward)

0

Release

Battery voltage

14

(R/W)

Ground

Reclining switch forward
signal

Input

Reclining switch

Operate

 (forward)

0

Release

Battery voltage

15

(Y/B)

Ground

Lifting switch (rear) down
signal

Input

Lifting switch

(rear)

Operate

(down)

0

Release

Battery voltage

16

(Y/R)

Ground

Lifting switch (rear) up sig-
nal

Input

Seat lifting switch

(rear)

Operate

 (up)

0

Release

Battery voltage

17

(LG/B)

Ground

Lifting switch (front) down
signal

Input

Lifting switch

(front)

Operate

(down)

0

Release

Battery voltage

18

(LG/R)

Ground

Lifting switch (front) up sig-
nal

Input

Seat lifting switch

(front)

Operate

 (up)

0

Release

Battery voltage

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx)

+

-

Signal name

Input/

Output

DRIVER SEAT CONTROL UNIT

MIR-29

< ECU DIAGNOSIS INFORMATION >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

19

(G/Y)

Ground

Sliding sensor signal

Input

Seat sliding

Operate

Stop

0 or 5

20

(R/Y)

Ground

Reclining sensor signal

Input

Seat reclining

Operate

Stop

0 or 5

21

(L/Y)

Ground

Lifting sensor (rear) signal

Input

Seat lifting (rear)

Operate

Stop

0 or 5

22

(BR/Y)

Ground

Lifting sensor (front) signal

Input

Seat lifting (front)

Operate

Stop

0 or 5

23

(P)

—

CAN-H

—

—

—

24

(P/L)

—

CAN-L

—

—

—

25

(G/O)

Ground

Memory indictor 1 signal

Output

Memory indictor 1

Illuminate

1

Other than above

Battery voltage

26

(L/O)

Ground

Memory indictor 2 signal

Output

Memory indictor 2

Illuminate

1

Other than above

Battery voltage

27

(V)

Ground

Memory switch 1 signal

Input

Memory switch 1

Press

0

Other than above

5

28

(V/W)

Ground

Memory switch 2 signal

Input

Memory switch 2

Press

0

Other than above

5

29

(O/L)

Ground

Set switch signal

Input

Set switch

Press

0

Other than above

5

Terminal No.

(wire color)

Description

Condition

Voltage (V)

(Approx)

+

-

Signal name

Input/

Output
