[BASE AUDIO WITH COLOR DISPLAY]

DISPLAY UNIT

DISPLAY UNIT

Reference Value

INFOID:0000000009721608

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0006ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

2

(Y)

Ground

Inverter VCC

Input

Ignition

switch

ACC

—

9.0 V

3

(GR)

Ground

Signal VCC

Input

Ignition

switch

ACC

—

9.0 V

4

(V)

Ground

Composite image signal
ground

—

Ignition

switch

ON

—

0  V

5

—

Shield

—

—

—

—

6

(L)

Ground

RGB signal (G: green)

Input

Ignition

switch

ON

Start Confirmation/Adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
Display Diagnosis screen.

7

—

Shield

—

—

—

—

8

(G)

Ground

Horizontal synchronizing
(HP) signal

Output

Ignition

switch

ON

—

SKIB2236J

SKIB3601E

AV

DISPLAY UNIT

AV-79

< ECU DIAGNOSIS INFORMATION >

[BASE AUDIO WITH COLOR DISPLAY]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

9

(W)

Ground

RGB area (YS) signal

Input

Ignition

switch

ON

At RGB image is displayed.

5.0 V

At AUX image is displayed.

11

(P)

Ground

Communication signal
(CONT

→

DISP)

Input

Ignition

switch

ON

When adjusting display
brightness.

13

(BR)

Ground

Inverter ground

—

Ignition

switch

ON

—

0  V

14

(SB)

Ground

Signal ground

—

Ignition

switch

ON

—

0  V

15

(LG)

Ground

Composite image signal

Input

Ignition

switch

ON

At camera image is dis-
played.

17

(G)

Ground

RGB signal (R: red)

Input

Ignition

switch

ON

Start Confirmation/Adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
Display Diagnosis screen.

18

(Y)

Ground

RGB signal (B: blue)

Input

Ignition

switch

ON

Start Confirmation/Adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
Display Diagnosis screen.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

PKIB4948J

PKIB5039J

SKIB2251J

SKIB2238J

SKIB2237J

AV-80

< ECU DIAGNOSIS INFORMATION >

[BASE AUDIO WITH COLOR DISPLAY]

DISPLAY UNIT

19

(B)

Ground

RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(R)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

Shield

—

—

—

—

22

(L)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display
brightness.

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3603E

SKIB3598E

PKIB5039J

AV

SATELLITE RADIO TUNER

AV-81

< ECU DIAGNOSIS INFORMATION >

[BASE AUDIO WITH COLOR DISPLAY]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SATELLITE RADIO TUNER

Reference Value

INFOID:0000000009721609

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0010ZZ

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

2

(Y/L)

1

(W/L)

Satellite radio sound signal
LH

Output

Ignition

switch

ON

When satellite radio mode
is selected.

4

(BR/L)

3

(Y/G)

Satellite radio sound signal
RH

Output

Ignition

switch

ON

When satellite radio mode
is selected

5

—

Shield

—

—

—

—

6

—

Shield

—

—

—

—

8

(R/W)

Ground

Request signal
(SAT

→

CONT)

Output

Ignition

switch

ON

When satellite radio mode
is selected

9

(R/L)

Ground

Communication signal
(SAT

→

CONT)

Output

Ignition

switch

ON

When satellite radio mode
is selected

SKIB3609E

SKIB3609E

SKIA9299J

SKIA9300J
