Nissan X-Trail 32. Manual - part 491





FRONT DOOR LOCK

DLK-305

< REMOVAL AND INSTALLATION >

[TYPE 1]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

7.

Disconnect door harness connector

 and disengage outside handle harness connector fixing clip

.

8.

Disengage rod holder

 and disconnect key rod

 from door lock assembly

 according to the numerical

order 1

2 indicated by arrows as shown in the figure (driver side).

9.

Remove door side grommet

, and then loosen TORX bolt

 from grommet hole.

: Clip

: Vehicle front

: Vehicle front

JMKIB3671ZZ

JMKIB3672ZZ

JMKIB3066ZZ

DLK-306

< REMOVAL AND INSTALLATION >

[TYPE 1]

FRONT DOOR LOCK

10. Remove outside handle escutcheon

 while pulling outside

handle grip

 according to the numerical order 1

2 indicated

by arrows as shown in the figure.

11. Slide outside handle grip

 toward rear of vehicle and remove it

according to the numerical order 1

2 indicated by arrows as

shown in the figure.

12. Remove front gasket

 and rear gasket

.

13. Slide outside handle bracket toward rear of vehicle and remove

it.

JMKIA0441ZZ

JMKIA2948ZZ

: Pawl

: Vehicle front

JMKIB2240ZZ

: Vehicle front

JMKIB2241ZZ

FRONT DOOR LOCK

DLK-307

< REMOVAL AND INSTALLATION >

[TYPE 1]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

14. Disconnect outside handle cable

 from outside handle bracket

 according to the numerical order 1

2 indicated by arrows as

shown in the figure.

INSTALLATION

Note the following items, and then install in the reverse order of removal.

CAUTION:

• When installing outside handle cable to outside handle, be careful that outside handle cable is

routed normally.

• When installing key rod, rotate key rod holder until a click is felt.
• After installation, check door lock. Refer to

DLK-303, "DOOR LOCK : Inspection"

.

JMKIB2242ZZ

DLK-308

< REMOVAL AND INSTALLATION >

[TYPE 1]

REAR DOOR LOCK

REAR DOOR LOCK

Exploded View

INFOID:0000000010708299

DOOR LOCK

DOOR LOCK : Removal and Installation

INFOID:0000000010708300

REMOVAL

1.

Disconnect inside handle cable from inside handle. Refer to

DLK-309, "INSIDE HANDLE : Removal and

Installation"

.

2.

Disconnect outside handle cable from outside handle bracket. Refer to

DLK-310, "OUTSIDE HANDLE :

Removal and Installation"

.

3.

Disconnect door lock assembly connector.

4.

Remove door lock assembly TORX bolts, and then remove door lock assembly.

INSTALLATION

Note the following items, and then install in the reverse order of removal.

CAUTION:

• Never reuse TORX bolt. Always replace it with a new one when it is removed.

Outside handle escutcheon

Outside handle grip

Inside handle

Door lock assembly

TORX bolt

Rear gasket

Front gasket

Outside handle bracket

: Pawl

: Vehicle front

: Always replace after every disassembly.

: N·m (kg-m, in-lb)

: Body grease

JMKIB3684GB
