Nissan X-Trail 32. Manual - part 2120





TM-438

< REMOVAL AND INSTALLATION >

[CVT: RE0F10D]

CVT FLUID COOLER SYSTEM

6.

Pull out fluid cooler hose E

, fluid cooler hose D

 and fluid

cooler hose C

 from CVT fluid cooler

 and fluid cooler

bracket (with tube)

.

7.

Remove the four bolts (

) and separate bracket

 and fluid

cooler bracket (with tube)

 from CVT fluid cooler

.

8.

Pull out fluid cooler hose F

 and fluid cooler hose B

 from

CVT oil warmer.

INSTALLATION

Note the followings and Installation is in the reverse order of removal.

CAUTION:

• Be careful not to damage CVT fluid cooler.
• Never reuse hose clamps.

Transaxle side

Refer to the followings when installing CVT fluid cooler tube.
• When installing fluid cooler tube A

 and fluid cooler tube B

 to

transaxle assembly, contact fluid cooler tubes stopper

 and

 to

transaxle case.

• Refer to the followings when installing fluid cooler hose.

: Hose clamp

JSDIA5379ZZ

JSDIA5380ZZ

: Hose clamp

: Vehicle front

JSDIA6137ZZ

JSDIA5321ZZ

CVT FLUID COOLER SYSTEM

TM-439

< REMOVAL AND INSTALLATION >

[CVT: RE0F10D]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

• Refer to the followings when installing hose clamp.

CAUTION:

Hose clamp should not interfere with the bulge of tube.

Vehicle side

• Refer to the followings when installing fluid cooler hose.

• Refer to the followings when installing hose clamp.

CAUTION:

Hose clamp should not interfere with the bulge of fluid cooler tube.

Hose

Installation side

tube

Direction of paint mark

Hose insertion depth

(A)

Fluid cooler
hose A

CVT oil warmer

Frontward

 Hose end reaches the
end of tube.

CVT fluid cooler
tube B

Align with the paint
marks on the CVT fluid
cooler tube B

SCIA7203E

Hose

Installation side

tube

Hose clamp

Direction of tab

Clamping position

Fluid cooler
hose A

CVT oil warmer

Frontward

5 – 9 mm (0.20 – 0.35
in) (A) from hose end

CVT fluid cooler
tube B

JSDIA2424ZZ

Hose

Installation side

tube

Direction of paint

mark

Hose insertion

depth (A)

Fluid cooler hose B

Fluid cooler tube A

Frontward

Hose end reaches
the 2-stage bulge.

Fluid cooler tube
assembly

Leftward

Fluid cooler hose C

Fluid cooler tube
assembly

Fluid cooler brack-
et (with tube)

Frontward

Hose end reaches
the end of tube

Fluid cooler hose D

Fluid cooler brack-
et (with tube)

CVT fluid cooler

Hose end reaches
the end of tube

Fluid cooler hose E

CVT fluid cooler

Fluid cooler tube
assembly A

Leftward

Hose end reaches
the 2-stage bulge.

Fluid cooler hose F

Fluid cooler tube
assembly A

CVT oil warmer

Upward

SCIA7203E

TM-440

< REMOVAL AND INSTALLATION >

[CVT: RE0F10D]

CVT FLUID COOLER SYSTEM

MR20DD : Inspection and Adjustment

INFOID:0000000010622631

INSPECTION AFTER INSTALLATION

Start the engine and check visually that there is no leakage of CVT fluid.

ADJUSTMENT AFTER INSTALLATION

Adjust the CVT fluid level. Refer to

TM-401, "Adjustment"

.

QR25DE

Hose

Installation side

tube

Hose clamp

Direction of tab

Clamping position

(A)

Fluid cooler hose B

Fluid cooler tube A

Frontward

5 – 9 mm (0.20 –
0.35 in) from hose
end

Fluid cooler tube
assembly

Leftward

Fluid cooler hose C

Fluid cooler tube
assembly

Fluid cooler brack-
et (with tube)

Frontward

Fluid cooler hose D

Fluid cooler brack-
et (with tube)

CVT fluid cooler

Fluid cooler hose E

CVT fluid cooler

Fluid cooler tube
assembly A

Leftward

Fluid cooler hose F

Fluid cooler tube
assembly A

CVT oil warmer

Upward

JSDIA2424ZZ

CVT FLUID COOLER SYSTEM

TM-441

< REMOVAL AND INSTALLATION >

[CVT: RE0F10D]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

QR25DE : Exploded View

INFOID:0000000010622632

QR25DE : Removal and Installation

INFOID:0000000010622633

REMOVAL

NOTE:
When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spill-
ing.

1.

Remove front bumper. Refer to

EXT-15, "Removal and Installation"

.

Bracket

Fluid cooler hose C

Bracket

Hose clamp

CVT fluid cooler

Bracket

Fluid cooler hose D

Fluid cooler hose B

Fluid cooler tube assembly

Fluid cooler hose E

Fluid cooler hose A

CVT oil warmer

Transaxle assembly

: Always replace after every disassembly.

: N·m (kg-m, in-lb)

JSDIA5375GB
