TM-26

< SYMPTOM DIAGNOSIS >

[6MT: RS6F94R]

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000010842442

Use the chart below to find the cause of the symptom. The numbers indicate the order of the inspection. If nec-
essary, repair or replace these parts.

SUSPECTED PARTS
(Possible cause)

OIL

 (Oil

lev

e

l is

 l

o

w)

OI

L (W

ro

ng

 oi

l)

OIL

 (Oil

lev

e

l is

 h

igh

)

GASKE

T (Damaged)

OIL SEAL (W

orn or

damaged)

O-RING (W

orn

 or

da

ma

ge

d)

SHIF

T CONTROL L

INKAGE

(W

o

rn)





















SHIF

T FORK (W

o

rn)

GEAR (W

o

rn o

r da

m

age

d)

BEAR

ING

 (W

orn

 o

r

da

ma

ge

d)

BAUL

K

 RING (W

orn

 o

r da

ma

ge

d)

INSE

R

T

 S

P

RING (Dam

ag

ed

)

Reference

TM

-2

7

, "

Insp

ectio

n

"

TM

-4

3

, "

Ex

pl

od

ed

 V

iew

"

TM

-3

5

, "

Insp

ectio

n

"

TM

-4

3

, "

Ex

pl

od

ed

 V

iew

"

TM

-4

3

, "

Ex

pl

od

ed

 V

iew

"

Symptoms

Noise

1

2

3

3

Oil  leakage

3

1

2

2

2

Hard to shift or will not shift

1

1

2

3

3

Jumps out of gear

1

2

2

M/T OIL

TM-27

< PERIODIC MAINTENANCE >

[6MT: RS6F94R]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

PERIODIC MAINTENANCE

M/T OIL

Inspection

INFOID:0000000010842443

OIL LEAKAGE

Make sure that gear oil is not leaking from transaxle or around it.

OIL LEVEL

1.

Check oil level from filler plug mounting hole as shown in the fig-
ure, after removing filler plug

 and gasket from transaxle

assembly.

CAUTION:

Turn the ignition switch OFF while checking oil level.

2.

Set a gasket on filler plug and install it on transaxle assembly.

CAUTION:

Never reuse gasket.

3.

Tighten filler plug to the specified torque. Refer to

TM-43,

"Exploded View"

.

Draining

INFOID:0000000010842444

1.

Start engine and let it run to warm up transaxle.

2.

Stop engine. Remove drain plug

 and gasket, then drain gear

oil.

3.

Set a gasket on drain plug and install it to transaxle assembly.

CAUTION:

Never reuse gasket.

4.

Tighten drain plug to the specified torque. Refer to

TM-43,

"Exploded View"

.

Refilling

INFOID:0000000010842445

1.

Fill with new gear oil until oil level reaches the specified level
at filler plug mounting hole, after removing filler plug

 and gas-

ket from transaxle assembly.

2.

After refilling gear oil, check the oil level. Refer to

TM-27,

"Inspection"

.

3.

Set a gasket on filler plug, and install it to transaxle assembly.

CAUTION:

Never reuse gasket.

4.

Tighten filler plug to the specified torque. Refer to

TM-43, "Exploded View"

.

JSDIA5819ZZ

JSDIA5820ZZ

Recommended
oil and capacity

: Refer to

MA-23, "Fluids and Lubri-

cants"

.

JSDIA6128ZZ

TM-28

< REMOVAL AND INSTALLATION >

[6MT: RS6F94R]

M/T SHIFT SELECTOR

REMOVAL AND INSTALLATION

M/T SHIFT SELECTOR

Exploded View

INFOID:0000000010842446

Removal and Installation

INFOID:0000000010842447

REMOVAL

1.

Shift shift lever to the neutral position.

2.

Remove ornament

 from shift lever knob

.

CAUTION:

Never damage ornament and shift lever knob.

3.

Pull out retainer

 using suitable pliers.

Ornament

Retainer

Shift lever knob

M/T shift selector assembly

M/T shift selector bracket

: N·m (kg-m, in-lb)

JSDIA6131GB

JSDIA6132ZZ

JSDIA6134ZZ

M/T SHIFT SELECTOR

TM-29

< REMOVAL AND INSTALLATION >

[6MT: RS6F94R]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

4.

Turn shift lever knob

 counterclockwise (30 degrees) and

remove it straight from the shift lever

.

5.

Remove center console assembly. Refer to

IP-25, "Removal and

Installation"

.

6.

Disconnect and remove shift cable and select cable from M/T
shift selector assembly. Refer to

TM-31, "Removal and Installa-

tion"

.

7.

Remove M/T shift selector assembly

 from M/T shift selector

bracket .

8.

Remove M/T shift selector bracket

.

INSTALLATION

Note the following, and install in the reverse order of removal.
• For each tightening torque, refer to

TM-28, "Exploded View"

.

• Install shift lever knob to the shift lever, as per the following procedure.

CAUTION:

Never reuse shift lever knob.

1.

Set retainer and ornament into shift lever knob.

2.

Displace shift lever knob

 counterclockwise (30 degrees) and

insert it straight to the shift lever

 without pressing the orna-

ment .

JSDIA6135ZZ

JSDIA5749ZZ

JSDIA5750ZZ

: Vehicle front

JSDIA6032ZZ
