SR-46
< REMOVAL AND INSTALLATION >
DISPOSAL OF AIR BAG MODULE
2.
Connect deployment tool (SST: KV99104600) (A) and deploy-
ment tool adapter (SST: KV99110500) (B) orange connector to
lap pre-tensioner
.
3.
Put the lap pre-tensioner
connected with the deployment tool
into a tire without a wheel.
4.
Put the tire with the lap pre-tensioner onto another tire without a
wheel. Add an additional tire without a wheel and then a tire
mounted on a wheel on top, and then tie all tires together with a
strap (C) in order keep them standing.
5.
Connect the test pin at the tip of deployment tool (SST:
KV99104600) (A) to both terminals of 12V battery (B), and then
the lap pre-tensioner deploys.
CAUTION:
When deploying the lap pre-tensioner, stand at least 5.0 m
(16.4 ft) away from the lap pre-tensioner.
LAP PRE-TENSIONER : Disposal
INFOID:0000000010927755
DISPOSING OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
Deployed air bag module, seat belt pre-tensioner, and lap pre-tensioner are very hot. Before disposing of air
bag module and seat belt pre-tensioner, wait at least 30 minutes, and 10 minutes, respectively. Seal them in a
plastic bag before disposal.
CAUTION:
• Never apply water to a deployed air bag module or seat belt
pre-tensioner or lap pre-tensioner.
• Wear gloves when handling a deployed air bag module or seat
belt pre-tensioner or lap pre-tensioner.
• No poisonous gas is produced upon air bag module deploy-
ment. However, be careful not to inhale gas since it irritates
the throat and can cause choking.
• Never disassemble air bag module, seat belt pre-tensioner
and lap pre-tensioner.
• Air bag module, seat belt pre-tensioner and lap pre-tensioner
cannot be reused.
• Wash your hands clean after the work is complete.
JMHIA2657ZZ
PHIA1288J
JMHIA0067ZZ
SBF276H
