SN-116 < REMOVAL AND INSTALLATION > [WITHOUT PARK ASSIST] BUZZER BUZZER FRONT FRONT : Removal and Installation INFOID:0000000010917672 REMOVAL 1. Remove instrument lower panel LH (LHD models) or RH (RHD models). Refer to the following. • RHD models: 2. Remove buzzer (frontward) mounting screw and buzzer (frontward) connector. 3. Remove buzzer (frontward) . INSTALLATION Install in the reverse order of removal. REAR REAR : Removal and Installation INFOID:0000000010917673 REMOVAL 1. Remove luggage side lower finisher LH. Refer to INT-43, "LUGGAGE SIDE LOWER FINISHER : . 2. Remove buzzer (backward) mounting screw and buzzer (backward) connector. 3. Remove buzzer (backward). INSTALLATION Install in the reverse order of removal. JSNIA6768ZZ : Vehicle front JSNIA7378ZZ |
