FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY FL-19 < REMOVAL AND INSTALLATION > [GASOLINE ENGINE MODEL] C D E F G H I J K L M A FL N P O • Pull the tube and the connector to check that they are securely connected. 7. Connect harness connector. Inspection Hole Cover • Before installing inspection hole cover, check that the connecting part has no fuel leakage. Refer to 1. Install inspection hole covers with the front mark (arrow) facing front of vehicle. 2. Lock clips by turning counterclockwise. Disassembly and Assembly INFOID:0000000010778226 DISASSEMBLY 1. Disconnect fuel level sensor harness connector . 2. Remove fuel level sensor from fuel filter and fuel pump assembly, according to the following steps. a. Remove fuel level sensor harness from fuel filter and fuel pump assembly. b. Press into pawl of fuel level sensor mounting area. c. With the fuel level sensor unlocked, slide it in the direction . CAUTION: • Be careful not to damage the fuel level sensor. JPBIA0140ZZ JPBIA6862ZZ JPBIA6863ZZ JPBIA6864ZZ |
