FAX-104 < REMOVAL AND INSTALLATION > [4WD] FRONT DRIVE SHAFT 6. Remove cotter pin, adjusting cap and then loosen wheel hub 7. Patch wheel hub lock nut with a piece of wood. Hammer the 8. Remove wheel hub lock nut. 9. Remove transverse link from steering knuckle and front suspension member. Refer to 10. Separate steering outer socket from steering knuckle. Refer to ST-22, "Removal and Installation" 11. Remove drive shaft from wheel hub and bearing assembly. CAUTION: • Never place drive shaft joint at an extreme angle. 12. Remove retainer mounting bolts and retainer. • Use the drive shaft attachment (SST: KV40107500) and a sliding hammer while inserting tip of the drive shaft attachment between housing and transfer assembly. CAUTION: Never place drive shaft joint at an extreme angle when removing drive shaft. Also be careful not 14. If necessary, remove the support bearing bracket mounting bolts and the support bearing bracket. INSTALLATION Left Side Note the following, and install in the reverse order of removal. CAUTION: Always replace differential side oil seal with new one when installing drive shaft. Refer to JSDIA2708ZZ JPDIG0070ZZ JSDIA5562ZZ |
