BR-50 < REMOVAL AND INSTALLATION > [LHD] FRONT DISC BRAKE 1. Remove brake pads. Refer to BR-47, "BRAKE PAD (2 PISTON TYPE) : Removal and Installation" 2. Press the pistons. Refer to BR-47, "BRAKE PAD (2 PISTON TYPE) : Removal and Installation" 3. Install brake pads. Refer to BR-47, "BRAKE PAD (2 PISTON TYPE) : Removal and Installation" 4. Depress the brake pedal several times. 5. Check a drag of front disc brake again. If any drag is found, disassemble the cylinder body and replace if BR-57, "BRAKE CALIPER ASSEMBLY (2 PISTON TYPE) : Disassembly and Assem- • Burnish contact surfaces brake pads and disc rotor after refinishing or replacing brake pads, or if a soft pedal occurs at very low mileage. Refer to BR-17, "BRAKE PAD : Inspection and Adjustment" . BRAKE CALIPER ASSEMBLY (1 PISTON TYPE) BRAKE CALIPER ASSEMBLY (1 PISTON TYPE) : Exploded View INFOID:0000000010838534 REMOVAL DISASSEMBLY Brake caliper assembly : N·m (kg-m, ft-lb) JPFIA0834GB JSFIA2351GB |
