Nissan Primera P12. Manual - part 621





MA-26

ENGINE MAINTENANCE (F9Q)

Pour coolant through coolant filler neck slowly of less than
2

(1-3/4 lmp qt) a minute to allow air in system to escape.

3.

Fill reservoir tank to specified level.

4.

Warm up engine to normal operating temperature reservoir tank
cap installed.

If coolant overflows reservoir tank filler hole, install reser-
voir tank cap.

5.

Run engine at 3,000 rpm for 10 seconds and return to idle speed
with reservoir tank cap installed.

Repeat two or three times.

Watch coolant temperature gauge so as not to overheat the engine.

6.

Stop engine and cool down to less than approximately 50

°

C (122

°

F).

Cool down using a fan to reduce the time.

If necessary, refill radiator up to filler neck with coolant.

7.

Refill reservoir tank to MAX level line with coolant.

8.

Repeat steps 5 through 7 two or more times with reservoir tank cap installed until coolant level no longer
drops.

9.

Check cooling system for leaks with engine running.

10. Warm up engine, and check for sound of coolant flow while running engine from idle up to 3,000 rpm with

heater temperature controller set at several position between COOL and WARM.

Sound may be noticeable at heater unit.

11. If sound is heard, bleed air from cooling system by repeating steps 5 through 7 until coolant level no

longer drops.

Clean excess coolant from engine.

FLUSHING COOLING SYSTEM

1.

Fill radiator and reservoir tank with water and reinstall reservoir tank cap.

2.

Run engine and warm it up to normal operating temperature.

3.

Rev engine two or three times under no-load.

4.

Stop engine and wait until it cools down.

5.

Drain water.

6.

Repeat steps 1 through 5 until clear water begins to drain from radiator.

Checking Cooling System

ELS000PQ

WARNING:

Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure
coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly turn it a quarter turn to
allow built-up pressure to escape. Carefully remove the cap by turning it all the way.

CHECKING COOLING SYSTEM HOSES

Check hoses for improper attachment, leaks, cracks, damage, loose connections, chafing and deterioration.

CHECKING RADIATOR

Check radiator for mud or clogging. If necessary, clean radiator as follows.

Be careful not to bend or damage the radiator fins.

When radiator is cleaned without removal, remove all surrounding parts such as cooling fan, radiator
shroud and horns. Then tape the harness and connectors to prevent water from entering.

1.

Apply water by hose to the back side of the radiator core vertically downwards.

2.

Apply water again to all radiator core surface once per minute.

3.

Stop washing if any stains no longer flow out from the radiator.

4.

Blow air into the back side of radiator core vertically downwards.

Use compressed air lower than 490 kpa (5 kg/cm

2

, 71psi) and keep distance more than 30 cm (11.8 in).

Reservoir tank

: 1.0

(1-7/8 lmp qt)

MBIB0981E

ENGINE MAINTENANCE (F9Q)

MA-27

C

D

E

F

G

H

I

J

K

M

A

B

MA

5.

Blow air again into all the radiator core surface once per minute until no water sprays out.

Checking Fuel Lines

ELS000PR

Inspect fuel lines, filler cap and tank for improper attachment, leaks,
cracks, damage, loose connections, chafing or deterioration.
If necessary, repair or replace faulty parts.

Changing Fuel Filter

ELS000PS

REMOVAL

1.

Remove wiper arms and wiper motor.

2.

Remove brackets as shown.

3.

Remove quick connectors as shown.

4.

Remove fuel filter from fuel filter bracket.

CAUTION:

Do not spill the fuel during removal. If the fuel is spill,
immediately wipe it off. Be especially careful to prevent the
fuel from adhering to the insulators of the engine mounts.

INSTALLATION

Install in the reverse order of removal.

After installation, operate the priming bulb vertically to perform air bleeding. Refer to

FL-7, "Air Bleeding"

.

SMA803A

MBIB0977E

MBIB0927E

MBIB0928E

MA-28

ENGINE MAINTENANCE (F9Q)

INSPECTION AFTER INSTALLATION

Run engine and check for fuel leakage at connections.

Changing Air Cleaner Filter

ELS000PT

REMOVAL

1.

Remove clips, and lift air cleaner case (upper).

2.

Remove air cleaner filter.

INSTALLATION

Install in the reverse order of removal.

Changing Engine Oil

ELS000PU

WARNING:

Be careful not to burn yourself, as the engine oil is hot.

Prolonged and repeated contact with used engine oil may cause skin cancer: try to avoid direct
skin contact with used oil. If skin contact is made, wash thoroughly with soap or hand cleaner as
soon as possible.

1.

Put vehicle horizontally.

2.

Warm up engine, and check for oil leakage from engine components.

3.

Stop engine and wait for 10 minutes.

4.

Remove oil pan drain plug and oil filler cap (with oil level gauge).

5.

Drain oil and refill with new engine oil.

Oil specification and viscosity:

Refer to

MA-15, "RECOMMENDED FLUIDS AND LUBRICANTS"

.

Oil capacity (Approximate):

The refill capacity depends on the oil temperature and drain time. Use these specifications for reference
only.
Always use the dipstick to the determine when the proper amount of oil is in the engine.

CAUTION:

Be sure to clean drain plug and install with new washer.

The refill capacity depends on the oil temperature and drain time. Use these specifications for ref-
erence only.
Always use the dipstick to the determine when the proper amount of oil is in the engine.

6.

Warm up engine and check area around drain plug and oil filter for oil leakage.

7.

Stop engine and wait for 10 minutes.

MBIB0946E

Drain and refill

With oil filter change

4.66

(4-1/8 Imp qt)

Without oil filter change

4.5

(4 Imp qt)

ENGINE MAINTENANCE (F9Q)

MA-29

C

D

E

F

G

H

I

J

K

M

A

B

MA

8.

Check oil level.

Changing Oil Filter

ELS000PV

REMOVAL

1.

Using an oil filter wrench (special service too), remove oil filter.

CAUTION:

Be careful not to get burned when the engine and engine oil
are hot.

When removing, prepare a shop cloth to absorb any oil
leakage or spillage.

Do not allow engine oil to adhere to the drive belts.

Completely wipe off any oil that adhere to the engine and
the vehicle.

INSTALLATION

1.

Remove foreign materials adhering to the oil filter installation surface.

2.

Apply engine oil to the oil seal contact surface of the new oil fil-
ter.

3.

Install the oil filter to oil cooler.

4.

After warming up the engine, check for engine oil leakage.

5.

Check oil level and add engine oil. Refer to

LU-16, "ENGINE OIL"

.

Draining Water

ELS000PW

1.

Prepare a tray at the drain plug.

2.

Open drain valve at the bottom of fuel filter.

CAUTION:

Water in filter is drained with fuel. Prepare larger capacity
tray than fuel filter volume.

Drained water is mixed with fuel. Prevent fuel from adher-
ing to rubber parts.

3.

After draining, close drain plug.

4.

Bleed air in fuel piping and check for fuel leakage. Refer to

FL-7,

"Air Bleeding"

.

5.

Start engine.

MBIB0936E

MBIB0939E

SMA010

MBIB0926E
