WT-58

< PERIODIC MAINTENANCE >

[WITH TPMS]

ROAD WHEEL

• When installing balance weight (1) to road wheels, set it into

the grooved area (A) on the inner wall of the road wheel as
shown in the figure so that the balance weight center (B) is
aligned with the tire balance machine indication position
(angle) (C).

CAUTION:

• Always use genuine NISSAN balance weights.
• Balance weights are non-reusable; always replace with

new ones.

• Never install three or more sheets of balance weight.

c.

If calculated balance weight value exceeds 50 g (1.76 oz), install
two balance weight sheets in line with each other as shown in
the figure.

CAUTION:

Never install one balance weight sheet on top of another.

3.

Start the tire balance machine again.

4.

Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position
(angle).

CAUTION:

Never install three or more balance weight.

5.

Start the tire balance machine. Check that the inner and outer residual unbalance value is within the
allowable unbalance value.

CAUTION:

If either residual unbalance value exceeds limit, repeat installation procedures.

Wheel Balance Adjustment (Steel Wheel)

INFOID:0000000010339570

PREPARATION BEFORE ADJUSTMENT

Remove balance weight from the road wheel.

CAUTION:

Never scratch the road wheel during removal.

ADJUSTMENT

JPEIC0040ZZ

PEIA0033E

Allowable unbalance value

Dynamic (At flange)

: Refer to

WT-66, "Road Wheel"

.

Static (At flange)

: Refer to

WT-66, "Road Wheel"

.

ROAD WHEEL

WT-59

< PERIODIC MAINTENANCE >

[WITH TPMS]

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

• The details of the adjustment procedure are different for each model of wheel balancer. Therefore, refer to

each instruction manual.

• If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting,

select and adjust a drive-in weight mode suitable for steel wheels.

1.

Set road wheel to wheel balancer, and then start wheel balancer.

2.

Install balance weight to road wheel according to the unbalance and position (angle) displayed on wheel
balancer.

CAUTION:

• Always use genuine NISSAN balance weights.
• Balance weights are non-reusable; always replace with new ones.
• Always use a plastic hammer when attaching the weight.
• Never install three or more balance weights on one side.

3.

Start the tire balance machine. Check that the inner and outer residual unbalance value is within the
allowable unbalance value.

CAUTION:

If either residual unbalance value exceeds limit, repeat installation procedures.

Tire Rotation

INFOID:0000000010339571

• Follow the maintenance schedule for tire rotation service intervals.

Refer to

MA-6, "General Maintenance"

.

• When installing the wheel, tighten wheel nuts to the specified

torque. Refer to

WT-60, "Exploded View"

.

CAUTION:

• Never include the T-type spare tire when rotating the tires.
• When installing wheels, tighten them diagonally by dividing

the work two to three times in order to prevent the wheels
from developing any distortion.

• Never tighten wheel nut at torque exceeding the criteria.
• Use NISSAN genuine wheel nut.

• After tire rotation, perform following:
- Perform the ID registration. Refer to

WT-29, "Work Procedure"

.

- Perform TPMS temperature calibration. Refer to

WT-14, "TPMS temperature calibration"

.

Allowable unbalance value

Dynamic (At flange)

: Refer to

WT-66, "Road Wheel"

.

Static (At flange)

: Refer to

WT-66, "Road Wheel"

.

SMA829C

WT-60

< REMOVAL AND INSTALLATION >

[WITH TPMS]

ROAD WHEEL TIRE ASSEMBLY

REMOVAL AND INSTALLATION

ROAD WHEEL TIRE ASSEMBLY

Exploded View

INFOID:0000000010339579

Removal and Installation

INFOID:0000000010339580

REMOVAL

1.

Remove wheel nuts.

2.

Remove tire assembly.

INSTALLATION

Note the following, install in the reverse order of removal.
• When replacing or rotating wheels, perform following;
- Perform the ID registration. Refer to

WT-29, "Work Procedure"

.

- Perform TPMS temperature calibration. Refer to

WT-14, "TPMS temperature calibration"

.

Inspection

INFOID:0000000010339581

1.

Check tires for wear and improper inflation.

2.

Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel
runout.

a.

Remove tire from aluminum wheel and mount on a tire balance machine.

b.

Set dial indicator as shown in the figure.

c.

Check runout, if the axial runout (A) or radial runout (B) exceeds
the limit, replace aluminum wheel.

1.

Tire assembly

: N·m (kg-m, ft-lb)

E1EIA0119GB

Limit

Axial runout (A)

: Refer to

WT-66, "Road Wheel"

.

Radial runout (B)

: Refer to

WT-66, "Road Wheel"

.

SEIA0737E

ROAD WHEEL TIRE ASSEMBLY

WT-61

< REMOVAL AND INSTALLATION >

[WITH TPMS]

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

How to Handle Puncture Repair Agent (With Puncture Repair Kit)

INFOID:0000000010493950

CAUTION:

• Never spill the sealant in the tire during repair.
• If the sealant spills, wipe it out with a waste cloth.
• Never reuse the repair kit hose used for a temporary repair of a flat tire because some of the punc-

ture repair agent remains in the hose.

• After using a puncture repair agent, replace valve core with a new one.
• Complete tire blowout repair or tire replacement within two days from the tire removal work start to

prevent the hardening of the repair agent which attached to tire pressure sensor. Replace tire pres-
sure sensor with a new one if tire blowout repair or tire replacement does not be completed within
two days from tire removal work start.

1.

Remove tires from the vehicle.

2.

Remove tire from road wheel, using a tire changer.

CAUTION:

• When deflating a tire, cover the valve with a waste cloth to prevent the sealant from splattering.
• Never spill the sealant in the tire during repair.

3.

Dispose of sealant in the removed tire.

CAUTION:

• Wipe out sealant spilled on the road wheel, tire, tire changer, and floor with a waste cloth.
• Drained sealant or expired sealant returned by the customer must be disposed according to the

law and local regulations.

• Fix a tire blowout, if repairable.

NOTE:
Sealant blocks holes caused by blowouts. These holes may not be found and repaired, depending on
the level of blowout. Therefore, it is necessary to check tire air pressure frequently and replace tire with
a new one, if the air pressure is decreasing.

• Replace tire with a new one, if not repairable.

CAUTION:

Never dispose of tires with the sealant contained.
