Nissan Qashqai J11. Manual - part 2161
DAS-58
< ECU DIAGNOSIS INFORMATION >
[DRIVER ASSISTANCE SYSTEM]
FRONT CAMERA UNIT
DAA LEVEL DISPLAY
No display
0
DAA OFF
1
DAA level (1 – 8)
2 – 9
DAA standby
14
DAA malfunction
15
DAA WARNING DISPLAY
No warning
0
DAA warning
1
LDW MALFUNCTION MSG
No display
0
LDW malfunction message is displayed
1
BSW MALFUNCTION MSG
No display
0
BSW malfunction message is displayed
1
CAMERA HI TEMP MSG
No display
0
Front camera unit high temperature message is displayed
1
FCW BLOCK MSG
NOTE:
The item is indicated, but not monitored
0
1
FEB BLOCK MSG
No display
0
Radar blockage message is displayed for FEB
1
FEB MALFUNCTION MSG
No display
0
FEB malfunction message is displayed
1
LDW FUNCTION
When LDW function is ON
NORMAL
When LDW function malfunction is detected
MALFUNCTION
LDW SETTING DISPLAY
Nothing
NTHNG
LDW is OFF
Off
LDW is ON
On
DRIVER ASSIST SYSTEM
BZZR
No request
NO REQ
BSW is requested
BSW
LDW is requested
LDW
MOD is requested
MOD
LDW LEFT
Left side lane maker is not detected
Off
Left side lane maker is detected
On
LDW RIGHT
Right side lane maker is not detected
Off
Right side lane maker is detected
On
LDW STATUS DISPLAY
LDW is OFF
OFF
LDW is ON
ON
LDW indicator is flashing
TPM MF
LDW is malfunctioning
MF
HBA FUNCTION
HBA is malfunctioning
MALF
HBA is normal
NORMAL
HBA is unavailable
TP OFF
HBA REQUEST
No request
NO REQ
Low beam is requested
LOW
High beam is requested
HIGH
HBA is unavailable
UNMBL
Monitor item
Condition
Value/Status
