AV

AV CONTROL UNIT

AV-149

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

9

 (BG)

Ground

Illumination control signal

Input

ON

Headlamps ON

Battery voltage

11

(G)

12

(R)

Sound signal front speaker
and tweeter RH

Output

ON

Sound output

13

(LG)

14

(GR)

Sound signal rear speaker
RH

Output

ON

Sound output

17

(R)

AV communication (L)

Input/

Output

18

(P)

Ground

Vehicle speed signal (8
pulse)

Input

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

19

(L)

Ground

Battery power supply

Input

OFF

Battery voltage

20

(B)

Ground

Ground

ON

0 V

21

(R)

Ground

AUX jack audio signal RH

Input

ON

Received audio signal
(AUX input)

22

(W)

Ground

AUX ground

ON

0V

23

(B)

Ground

AUX jack audio signal LH

Input

ON

Received audio signal
(AUX input)

25

(G)

Ground

Reverse signal

Input

ON

Selector lever in R (re-
verse)

Battery voltage

Selector lever in any posi-
tion other than R (reverse)

0 V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

SKIB3609E

JSNIA0012GB

SKIB3609E

SKIB3609E

AV-150

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

AV CONTROL UNIT

30

(SB)

MR output

Output

31

(SB)

CAN  (H)

Input/

Output

32

(LG)

CAN  (L)

Input/

Output

34

(W)

36

(Shield)

Microphone signal

Input

ON

While speaking into micro-
phone.

35

(O)

MIC VCC

Input

ON

37

(Shield)

AUX signal shield

38

(SB)

CAN  (H)

Input/

Output

39

(LG)

CAN  (L)

Input/

Output

40

(LG)

Ground

Ignition power supply

Input

ON

Battery voltage

41

(W)

*1

(G)

*2

Ground

Camera image signal

Input

ON

When camera image is dis-
played

42

(Shield)

Camera image signal
shield

43

(R)

Ground

Camera power supply

Input

ON

Battery voltage

44

(B)

Ground

Camera ground

Input

ON

0 V

56

Ground

GPS antenna signal

Input

ON

AV control unit ON, NAV se-
lected.

5.0 V

57

(Shield)

GPS antenna shield

58

(R)

USB D

 signal

59

(W)

V BUS signal

60

(G)

USB ground

61

(L)

USB + signal

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

SKIB2251J

AV

AV CONTROL UNIT

AV-151

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

*1:WITHOUT AROUND VIEW MONITOR

*2:WITH AROUND VIEW MONITOR

DTC Index

INFOID:0000000010435661

62

USB shield

150

Ground

FM sub signal

Output

ON

AV control unit ON, FM-AM
selected.

Battery voltage

151

Ground

AM-FM main antenna

Input

ON

AV control unit ON, FM-AM
selected.

5.0 V

152

Ground

Antenna amp. ON signal

Output

ON

AV control unit ON, FM-AM
selected.

Battery voltage

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

Signal name

Input/

Output

Ignition

switch

Operation

CONSULT Display

Reference Page

U1000: CAN COMM CIRCUIT

AV-189, "AV CONTROL UNIT : DTC Logic"

U1010: CONTROL UNIT (CAN)

AV-190, "AV CONTROL UNIT : DTC Logic"

U1217: BLUETOOTH MODULE

AV-208, "DTC Logic"

U1229: iPod CERTIFICATION

AV-209, "DTC Logic"

U122F: Digital broadcasting connection error

AV-210, "DTC Logic"

U1244: GPS ANTENNA CONN

AV-212, "DTC Logic"

U1258: SXM ANTENNA CONN

AV-213, "DTC Logic"

U1263: USB OVERCURRENT

AV-214, "DTC Logic"

U12AA: Configuration Error

AV-215, "DTC Logic"

U12AB: FM Antenna error

AV-216, "DTC Logic"

U12AC: Display Temperature too High

AV-217, "DTC Logic"

U12AD: ECU Temperature too High

AV-218, "DTC Logic"

U12AE: Internal Amplifier temperature Warning

AV-219, "DTC Logic"

U12AF: CD Mechanism Temperature Warning

AV-220, "DTC Logic"

U1300: AV COMM CIRCUIT

AV-221, "DTC Logic"

U1310: CONTROL UNIT(AV)

AV-225, "DTC Logic"

AV-152

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

AROUND VIEW MONITOR CONTROL UNIT

AROUND VIEW MONITOR CONTROL UNIT

WITHOUT DRIVER ASSISTANCE SYSTEM

WITHOUT DRIVER ASSISTANCE SYSTEM : Reference Value

INFOID:0000000010435662

VALUES ON THE DIAGNOSIS TOOL

TERMINAL LAYOUT

PHYSICAL VALUES

Monitor Item

Condition

Value/Status

CAMERA OFF SIGNAL

CAMERA switch ON.

Off

CAMERA switch OFF.

On

CAMERA SWITCH SIGNAL

CAMERA switch OFF.

Off

CAMERA switch ON.

On

DR-SIDE CAMERA IMAGE SIG

Side camera LH inoperative.

NG

Side camera LH operative.

OK

F-CAMERA IMAGE SIG

Front camera inoperative.

NG

Front camera operative.

OK

PA-SIDE CAMERA IMAGE SIG

Side camera RH inoperative.

NG

Side camera RH operative.

OK

REAR CAMERA IMAGE SIGNAL

Rear camera LH inoperative.

NG

Rear camera LH operative.

OK

REVERSE SIGNAL

When selector lever is in any position other than R (reverse).

Off

When selector lever in R (reverse).

On

ST ANGLE SENSOR SIGNAL

Around view monitor control unit is not receiving steering angle
sensor signal.

Off

Around view monitor control unit is receiving steering angle sen-
sor signal.

On

ST ANGLE SENSOR TYPE

Steering angle sensor type.

Absolute

ST GEAR RATIO TYPE

Steering gear ratio type.

Type O

STEERING POSITION

Left hand drive vehicle.

LHD

Right hand drive vehicle.

RHD

VEHICLE SPEED SIGNAL

While driving, equivalent to speedometer reading

mph, km/h

AWNIA3139ZZ
