BCS-82

< ECU DIAGNOSIS INFORMATION >

BCM

110

(SB)

Ground

Dimmer signal

Output

Power position
ON

Either of the following
conditions
• Lighting switch OFF
• Bright outside of the ve-

hicle (Lighting switch
AUTO)

0 V

Either of the following
conditions
• Lighting switch 1ST or

2ND

• Dark outside of the ve-

hicle (Lighting switch
AUTO)

12 V

111

(R)

Ground

Door lock status indi-
cator lamp

Output

Door lock status
indicator lamp

OFF

0 V

ON

12 V

112

(SB)

Ground

Stop/start OFF
switch indicator

Output

Stop/start OFF
switch indicator

ON

0 – 0.5 V

OFF

9 – 16 V

113*

4

(LG)

Ground

NATS antenna amp.

Input/

Output

Just after inserting ignition key in key cylinder

Pointer of tester should move

Other than above

0 V

114*

3

(Y)

Ground

NATS antenna amp.

Input/

Output

Intelligent Key
battery is re-
moved and
brake pedal is
depressed

When a registered Intelli-
gent Key backside is con-
tacted to push-button
ignition switch

0 V

Other than above

115*

3

(W)

Ground

NATS antenna amp.

Input/

Output

Intelligent Key
battery is re-
moved and
brake pedal is
depressed

When a registered Intelli-
gent Key backside is con-
tacted to push-button
ignition switch

0 V

Other than above

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

JMMIA1650GB

JMMIA1651GB

BCS

BCM

BCS-83

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

116*

3

(BG)

Ground

Inside key antenna
(Console) (-)

Input

Power position
ON and any
door is open

Intelligent Key is outside
the vehicle

Intelligent Key is inside
the vehicle

117*

3

(GR)

Ground

Inside key antenna
(Console) (+)

Output

Power position
ON and any
door is open

Intelligent Key is outside
the vehicle

Intelligent Key is inside
the vehicle

118*

3

(LG)

Ground

Passenger door an-
tenna (-)

Input

Power position
ON and any
door is open

Intelligent Key is outside
the vehicle

Intelligent Key is inside
the vehicle

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

JMMIA1652GB

JMMIA1653GB

JSMIA1348GB

JSMIA1406GB

JSMIA1507GB

JSMIA1506GB

BCS-84

< ECU DIAGNOSIS INFORMATION >

BCM

119*

3

(P)

Ground

Passenger door an-
tenna (+)

Output

Power position
ON and any
door is open

Intelligent Key is outside
the vehicle

Intelligent Key is inside
the vehicle

120*

3

(BR)

Ground

Driver door antenna
(-)

Input

Power position
ON and any
door is open

Intelligent Key is outside
the vehicle

Intelligent Key is inside
the vehicle

121

(B)

Ground

Back door open

Output

Back door
opener actuator

Activated

9 – 16 V

Not activated

0 V

122

(R)

Ground

Rear fog lamp

Output

Rear fog lamp

OFF

0 V

ON

9 – 16 V

123

(GR)*

5

(W)*

6

Ground

Rear wiper

Output

Power position
ON

Rear wiper switch OFF

0 V

Rear wiper switch ON

9 – 16 V

124

(G)

Ground

Rear door UNLOCK

Output

Rear door

UNLOCK (Actuator is acti-
vated)

9 – 16 V

Other than UNLOCK (Ac-
tuator is not activated)

0 V

125

(V)

Ground

Rear door LOCK

Output

Rear door

LOCK (Actuator is activat-
ed)

9 – 16 V

Other than LOCK (Actua-
tor is not activated)

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

JSMIA1507GB

JSMIA1506GB

JMMIA1652GB

JMMIA1653GB

BCS

BCM

BCS-85

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

127

(L)

Ground

Luggage room lamp
control

Output

Luggage room
lamp

OFF

9 – 16 V

ON

0 – 0.5 V

129

(Y)

Ground

Stop lamp LH output

Output

Brake pedal

Not depressed

0 V

Depressed

9 – 16 V

131*

2

(G)

Ground

Super lock (Rear
door)

Output

Super lock actu-
ator (Rear door)

Activated

9 – 16 V

Not activated

0 V

133

(GR)

Ground

Turn signal LH out-
put (Rear)

Output

Power position
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

(Turn signal lamp turn on: 9 - 16

V)

134

(Y)

Ground

Stop lamp RH output

Output

Brake pedal

Not depressed

0 V

Depressed

9 – 16 V

136

(P)

Ground

Turn signal RH out-
put (Rear)

Output

Power position
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

(Turn signal lamp turn on: 9 - 16

V)

137
(W)

Ground

Battery power sup-
ply (BCM)

Input

Power position OFF

9 – 16 V

138

(R)

Ground

Interior room lamp
control

Output

Map lamp, room
lamp and per-
sonal lamp
(Door position)

When all doors are closed
(Interior room lamp are
turned OFF)

9 – 16 V

Any doors opens (Interior
room lamp are turned ON)

0 – 1 V

139

(Y)

Ground

Passenger door UN-
LOCK

Output

Passenger door

UNLOCK (Actuator is acti-
vated)

9 – 16 V

Other than UNLOCK (Ac-
tuator is not activated)

0 V

141

(GR)

Ground

Front doors LOCK

Output

Front doors

LOCK (Actuator is activat-
ed)

9 – 16 V

Other than LOCK (Actua-
tor is not activated)

0 V

143

(V)

Ground

Battery power sup-
ply (Front door lock
actuator)

Input

Power position OFF

9 – 16 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

−

Signal name

Input/

Output

PKID0926E
