DOOR MIRROR (OPEN/CLOSE MOTOR)

MIR-55

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> GO TO 5.

5.

CHECK HARNESS CONTINUITY-1

1.

Turn ignition switch OFF.

2.

Disconnect door mirror remote control switch connector.

3.

Check continuity between door mirror remote control switch harness connector and door mirror open/
close relay harness connector.

4.

Check continuity between door mirror remote control switch harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 10.

NO

>> Repair or replace harness.

6.

CHECK DOOR MIRROR MOTOR INPUT SIGNAL

1.

Turn ignition switch OFF.

2.

Connect door mirror open relay and door mirror close relay connector.

3.

Disconnect door mirror (driver side) connector and door mirror (passenger side) connector.

4.

Turn ignition switch ON.

5.

Check voltage between door mirror connector and ground.

Is the inspection result normal?

(+)

(–)

Condition

Voltage (V)

(Approx.)

Door mirror open/close relay

Connector

Terminal

M100

4

Ground

Door mirror remote
control switch
(open/close switch)

Auto

12

Other than above

0

M101

Close

12

Other than above

0

door mirror remote control switch

Door mirror open/close relay

Continuity

Connector

Terminal

Connector

Terminal

D6 (LHD models)

D36 (RHD models)

5

M100

4

Existed

7

M101

door mirror remote control switch

Ground

Continuity

Connector

Terminal

Not existed

D6 (LHD models)

D36 (RHD models)

5

7

(+)

(–)

Condition

Voltage (V)

(Approx.)

Door mirror

Connector

Terminal

D27 (LHD models)

D16 (RHD models)

3

Ground

Door mirror remote
control switch
(open/close switch)

Auto

12

Close

0

11

Auto

0

Close

12

D3 (LHD models)

D40 (RHD models)

3

Auto

12

Close

0

11

Auto

0

Close

12

MIR-56

< DTC/CIRCUIT DIAGNOSIS >

DOOR MIRROR (OPEN/CLOSE MOTOR)

YES

>> GO TO 8.

NO

>> GO TO 7.

7.

CHECK HARNESS CONTINUITY-2

1.

Turn ignition switch OFF.

2.

Disconnect door mirror open relay connector and door mirror close relay connector.

3.

Check continuity between door mirror harness connector and door mirror open relay and door mirror close
relay harness connector.

4.

Check continuity between door mirror harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 8.

NO

>> Repair or replace harness.

8.

CHECK DOOR MIRROR OPEN RELAY

Check door mirror open relay.
Refer to

MIR-57, "Component Inspection (Door Mirror Open Relay)"

.

Is the inspection result normal?

YES

>> GO TO 9.

NO

>> Replace door mirror open relay.

9.

CHECK DOOR MIRROR CLOSE RELAY

Check door mirror close relay.
Refer to

MIR-57, "Component Inspection (Door Mirror Close Relay)"

.

Is the inspection result normal?

YES

>> GO TO 10.

NO

>> Replace door mirror close relay.

10.

CHECK DOOR MIRROR REMOTE CONTROL SWITCH

Check door mirror remote control switch (open/close switch).
Refer to

MIR-57, "Component Inspection (Door Mirror Remote Control Switch)"

.

Is the inspection result normal?

YES

>> Replace door mirror open/close motor.

NO

>> Replace door mirror remote control switch.

11.

CHECK INTERMITTENT INCIDENT

Refer to

GI-44, "Intermittent Incident"

.

>> INSPECTION END

door mirror

Door mirror open/close relay

Continuity

Connector

Terminal

Connector

Terminal

D27 (LHD models)

D16 (RHD models)

3

M100

3

Existed

11

M101

D3 (LHD models)

D40 (RHD models)

3

M100

11

M101

door mirror

Ground

Continuity

Connector

Terminal

Not existed

D27 (LHD models)

D16 (RHD models)

3

11

D3 (LHD models)

D40 (RHD models)

3

11

DOOR MIRROR (OPEN/CLOSE MOTOR)

MIR-57

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

Component Inspection (Door Mirror Remote Control Switch)

INFOID:0000000011405234

1.

CHECK OPEN/CLOSE SWITCH

1.

Turn ignition switch OFF.

2.

Disconnect door mirror remote control switch connector.

3.

Check door mirror remote control switch.

Is the inspection result normal?

YES

>> INSPECTION END.

NO

>> Replace door mirror remote control switch.

Component Inspection (Door Mirror Open Relay)

INFOID:0000000011405235

1.

CHECK DOOR MIRROR OPEN RELAY

1.

Turn ignition switch OFF.

2.

Remove door mirror open relay.

3.

Check the continuity between door mirror open relay terminals
under the following conditions.

Is the inspection result normal?

YES

>> INSPECTION END.

NO

>> Replace door mirror open relay.

Component Inspection (Door Mirror Close Relay)

INFOID:0000000011405236

1.

CHECK DOOR MIRROR OPEN/CLOSE RELAY

1.

Turn ignition switch OFF.

2.

Remove door mirror close relay.

3.

Check the continuity between door mirror close relay terminals
under the following conditions.

Is the inspection result normal?

YES

>> INSPECTION END.

Door mirror remote control switch

Condition

Continuity

Terminal

15

5

Open/close switch

AUTO

Existed

10

7

15

7

CLOSE

10

5

Terminal

Condition

Continuity

4

3

No current supply

Existed

12 V direct current supply between ter-
minals 1 and 2.

Not existed

5

12 V direct current supply between ter-
minals 1 and 2.

Existed

No current supply

Not existed

JMLIA0997ZZ

Terminal

Condition

Continuity

4

3

No current supply

Existed

12 V direct current supply between ter-
minals 1 and 2.

Not existed

5

12 V direct current supply between ter-
minals 1 and 2.

Existed

No current supply

Not existed

JMLIA0997ZZ

MIR-58

< DTC/CIRCUIT DIAGNOSIS >

DOOR MIRROR (OPEN/CLOSE MOTOR)

NO

>> Replace door mirror close relay.
