AUTO ANTI-DAZZLING MIRROR SYSTEM

MIR-51

< WIRING DIAGRAM >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

JRLWE4140GB

MIR-52

< BASIC INSPECTION >

DIAGNOSIS AND REPAIR WORK FLOW

BASIC INSPECTION

DIAGNOSIS AND REPAIR WORK FLOW

Work Flow

INFOID:0000000011378312

DETAILED FLOW

1.

OBTAIN INFORMATION ABOUT SYMPTOM

Interview the customer to obtain as much malfunction information (conditions and environment when the mal-
function occurred) as possible when the customer brings the vehicle in.

>> GO TO 2.

2.

REPRODUCE THE MALFUNCTION INFORMATION

Check the malfunction on the vehicle that the customer describes.
Inspect the relation of the symptoms and the condition when the symptoms occur.

>> GO TO 3.

3.

IDENTIFY THE MALFUNCTIONING SYSTEM WITH “SYMPTOM DIAGNOSIS”

Use “Symptom diagnosis” from the symptom inspection result in step 2. Then identify where to start the diag-
nosis based on possible causes and symptoms.

>> GO TO 4.

4.

IDENTIFY MALFUNCTIONING PARTS WITH “COMPONENT DIAGNOSIS”

Perform the diagnosis with “Component diagnosis” of the applicable system.

>> GO TO 5.

5.

REPAIR OR REPLACE THE MALFUNCTIONING PARTS

Repair or replace the specified malfunctioning parts.

>> GO TO 6.

6.

FINAL CHECK

Check that malfunctions are not reproduced when obtaining the malfunction information from the customer,
referring to the symptom inspection result in step 2.

Is the malfunctioning part repaired or replaced?

YES

>> Trouble diagnosis is completed.

NO

>> GO TO 3.

DOOR MIRROR REMOTE CONTROL SWITCH (MIRROR SWITCH/

CHANGEOVER SWITCH)

MIR-53

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

DTC/CIRCUIT DIAGNOSIS

DOOR MIRROR REMOTE CONTROL SWITCH (MIRROR SWITCH/
CHANGEOVER SWITCH)

Component Inspection

INFOID:0000000011405231

1.

CHECK MIRROR SWITCH & CHANGEOVER SWITCH

1.

Turn ignition switch OFF.

2.

Disconnect door mirror remote control switch connector.

3.

Check door mirror remote control switch.

Is the inspection result normal?

YES

>> INSPECTION END.

NO

>> Replace door mirror remote control switch.

Door mirror remote control switch

condition

Continuity

Terminal

Change over

switch

Mirror switch

Driver side (RHD models)
Passenger side (LHD models)

15

11

RIGHT

RIGHT

Existed

10

9

15

9

LEFT

10

11

15

3

UP

10

11

15

11

DOWN

10

3

Driver side (LHD models)
Passenger side (RHD models)

15

12

LEFT

RIGHT

10

1

15

1

LEFT

10

12

15

4

UP

10

12

15

12

DOWN

10

4

MIR-54

< DTC/CIRCUIT DIAGNOSIS >

DOOR MIRROR (OPEN/CLOSE MOTOR)

DOOR MIRROR (OPEN/CLOSE MOTOR)

Component Function Check

INFOID:0000000011405232

1.

CHECK DOOR MIRROR RETRACT FUNCTION

1.

Turn ignition switch ON.

2.

Operate open/close switch. Check that door mirror operates normally.

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Refer to

MIR-54, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000011405233

1.

CHECK DOOR MIRROR REMOTE CONTROL SWITCH POWER SUPPLY

1.

Turn ignition switch OFF.

2.

Disconnect door mirror remote control switch connector.

3.

Turn ignition switch ON.

4.

Check voltage between door mirror remote control switch harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> GO TO 2.

2.

DETECT MALFUNCTIONING PART

Check the following.
• 10 A fuse (#14)
• Harness for open or short between door mirror remote control switch harness connector and battery termi-

nal.

Is the inspection result normal?

YES

>> GO TO 11.

NO

>> Repair or replace the malfunctioning parts.

3.

CHECK DOOR MIRROR REMOTE CONTROL SWITCH GROUND CIRCUIT

1.

Turn ignition switch OFF.

2.

Check continuity between door mirror remote control switch harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace harness or connector.

4.

CHECK DOOR MIRROR OPEN RELAY AND DOOR MIRROR CLOSE RELAY INPUT SIGNAL

1.

Connect door mirror remote control switch connector.

2.

Disconnect door mirror open relay and door mirror close relay connector.

3.

Turn ignition switch ON.

4.

Check voltage between door mirror open relay and door mirror close relay harness connector and ground.

(+)

(

−

)

Voltage (V)

(Approx.)

Door mirror remote control switch

Connector

Terminal

D6 (LHD models)

D36 (RHD models)

15

Ground

Battery voltage

Door mirror remote control switch

Ground

Continuity

Connector

Terminal

D6 (LHD models)

D36 (RHD models)

10

Existed
