BRM-88 < SERVICE DATA AND SPECIFICATIONS (SDS) [FOR EUROPE (LHD)] BODY ALIGNMENT 2WD : Body Center Marks (With Sunroof Models) INFOID:0000000010305264 A mark is placed on each part of the body to indicate the vehicle center. When repairing the vehicle frame Unit: mm (in) D Trans control reinforcement Hole 12 × 14 (0.47 × 0.55) E Rear roof Embossment Points Portion Marks : Vehicle front Points Portion Marks A Upper front roof rail Embossment B Cowl top indent C Cowl top Hole φ 8 (0.31) JSKIA3904ZZ |
