SYSTEM (INTELLIGENT KEY SYSTEM)
DLK-217
< SYSTEM DESCRIPTION >
[TYPE 2]
C
D
E
F
G
H
I
J
L
M
A
B
DLK
N
O
P
• Intelligent Key low battery warning
• Key ID verification information
• Steering lock information
• Key ID warning
OPERATION CONDITION
Operation condition of warning and information is as per the following table.
*: M/T models do not apply.
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Warning/Information functions
Operation procedure
Intelligent Key system malfunction
A malfunction is detected on BCM and key warning lamp turns ON
OFF position warning
When condition A or B is satisfied
• Condition A
- Turn ignition switch from ON to OFF while door is open
• Condition B
- Intelligent Key backside is contacted to push-button ignition switch while
brake pedal is depressed and ignition switch is LOCK or OFF (When the In-
telligent Key battery is discharged)
- Door switch (driver side): ON (Door is open)
P position warning*
For internal
• Shift position: Except P position
• Engine is running to stopped (Ignition switch is ON to OFF)
For external
• P position warning (For internal) operates
• Door switch: ON to OFF (Door is open to close)
• Intelligent Key cannot be detected inside the vehicle
Take away warning
Door status changes
from open to close
• Ignition switch: Except LOCK or OFF position
• Door switch: ON to OFF (Door is open to close)
• Registered Intelligent Key is not detected inside the vehicle
Door status is open
• Ignition switch: Except OFF position
• Door switch: ON (Door is open)
• Registered Intelligent Key is not detected inside the vehicle during Key ID ver-
ification for 5 seconds
Push button-ignition
switch operation
• Ignition switch: OFF position
• Press push-button ignition switch
• Registered Intelligent Key is not detected inside the vehicle
Door lock operation warning
When door lock operation is requested while door lock operating condition of
door request switch not satisfied
Engine start information
Ignition switch is ON po-
sition
• Ignition switch: ON position
• Shift position: P position*
• Engine is stopped
Ignition switch is except
ON position
• Ignition switch: Except ON position
• Shift position: P position*
• Intelligent Key can be detected inside the vehicle
Ignition switch is ON po-
sition to OFF position
• Ignition switch: ON position to OFF position
• Shift position: P position
NOTE:
Engine start information turns ON for several seconds and then turns OFF, when
ignition switch is turned to the ON position from the OFF position. Engine start
information does not turn ON until opening and closing of driver door is detected
again.
Intelligent Key low battery warning
BCM detects that Intelligent Key is low battery, after ignition switch is turned ON
Key ID verification information
• Ignition switch: LOCK position
• Push-button ignition switch: Pressed
• Registered Intelligent Key is not detected inside the vehicle
Steering lock information
When the steering lock can not be unlocked
Key ID warning
• Push-button ignition switch is pressed
• Registered Intelligent Key is not detected inside the vehicle
