HAC-140 < REMOVAL AND INSTALLATION > [AUTOMATIC AIR CONDITIONING] DOOR MOTOR INSTALLATION Install in the reverse order of removal. MODE DOOR MOTOR MODE DOOR MOTOR : Removal and Installation INFOID:0000000010432264 REMOVAL 1. Remove instrument lower panel RH (RHD models) or glove box cover (LHD models). Refer to 2. Remove foot duct RH. Refer to VTL-14, "FOOT DUCT : Removal and Installation" 3. Disconnect mode door motor harness connector. 4. Remove fixing screws , mode door motor. INSTALLATION Note the following item, and then install in the reverse order of removal. CAUTION: After installing door motor, perform door motor starting position. Refer to JMIIA3396ZZ |
