Nissan Juke F15. Manual - part 806





A
B

D

E

F

G

H

I

J

K

L

M

N

P

O

C

Q

QUICK REFERENCE INDEX



A GENERAL INFORMATION

GI

General Information

B ENGINE

EM

Engine Mechanical

LU

Engine Lubrication System

CO

Engine Cooling System

EC

Engine Control System

FL

Fuel System

EX

Exhaust System

STR

Starting System

ACC

Accelerator Control System

C ELECTRIC POWER TRAIN

HBC

Hybrid Control System

HBB

Hybrid Battery System

HBR

Hybrid Brake System

EVC

EV Control System

TMS

Traction Motor System

EVB

EV Battery System

VC

Vehicle Charging System

HCO

High Voltage Cooling System

D TRANSMISSION & DRIVELINE

CL

Clutch

TM

Transaxle & Transmission

DLN

Driveline

FAX

Front Axle

RAX

Rear Axle

E SUSPENSION

FSU

Front Suspension

RSU

Rear Suspension

SCS

Suspension Control System

WT

Road Wheels & Tires

F BRAKES

BR

Brake System

PB

Parking Brake System

BRC

Brake Control System

G STEERING

ST

Steering System

STC

Steering Control System

H RESTRAINTS

SB

Seat Belt

SBC

Seat Belt Control System

SR

SRS Airbag

SRC

SRS Airbag Control System

I

VENTILATION, HEATER & AIR
CONDITIONER

VTL

Ventilation System

HA

Heater & Air Conditioning System

HAC

Heater & Air Conditioning Control System

J BODY INTERIOR

INT

Interior

IP

Instrument Panel

SE

Seat

ADP

Automatic Drive Positioner

K BODY EXTERIOR, DOORS,

ROOF & VEHICLE SECURITY

DLK

Door & Lock

SEC

Security Control System

GW

Glass & Window System

PWC

Power Window Control System

RF

Roof

HD

Hood

EXT

Exterior

BRM

Body Repair

L DRIVER CONTROLS

MIR

Mirrors

EXL

Exterior Lighting System

INL

Interior Lighting System

WW

Wiper & Washer

DEF

Defogger

HRN

Horn

VSP

Approaching Vehicle Sound for Pedestrians (VSP)

M ELECTRICAL & POWER CON-

TROL

PWO

Power Outlet

BCS

Body Control System

LAN

LAN System

PCS

Power Control System

CHG

Charging System

PG

Power Supply, Ground & Circuit Elements

N DRIVER INFORMATION &

MULTIMEDIA

MWI

Meter, Warning Lamp & Indicator

WCS

Warning Chime System

SN

Sonar System

AV

Audio, Visual & Navigation System

O CRUISE CONTROL &

DRIVER ASSISTANCE

CCS

Cruise Control System

DAS

Driver Assistance System

DMS

Drive Mode System

P MAINTENANCE

MA

Maintenance

Q INDEX

IDX

Alphabetical Index

All Rights Reserved. No part
of this Service Manual may
be reproduced or stored in a
retrieval system, or transmit-
ted in any form, or by any
means, electronic, mechani-
cal, recording or otherwise,
without the prior written per-
mission of NISSAN MOTOR
CO., LTD.

FOREWORD

This manual contains maintenance and repair procedure for the 2016
NISSAN JUKE.

In order to assure your safety and the efficient functioning of the vehicle,
this manual should be read thoroughly. It is especially important that the
PRECAUTIONS in the GI section be completely understood before starting
any repair task.

All information in this manual is based on the latest product information
at the time of publication. The right is reserved to make changes in specifi-
cations and methods at any time without notice.

IMPORTANT SAFETY NOTICE

The proper performance of service is essential for both the safety of
the technician and the efficient functioning of the vehicle.
The service methods in this Service Manual are described in such a
manner that the service may be performed safely and accurately.
Service varies with the procedures used, the skills of the technician
and the tools and parts available. Accordingly, anyone using service
procedures, tools or parts which are not specifically recommended
by NISSAN must first be completely satisfied that neither personal
safety nor the vehicle’s safety will be jeopardized by the service
method selected.

PLEASE HELP MAKE THIS SERVICE MANUAL BETTER!

Your comments are important to NISSAN and will help us to improve our Service Manuals.
Use this form to report any issues or comments you may have regarding our Service Manuals.
Please print this form and type or write your comments below. Mail or fax to:

Nissan North America, Inc.
Technical Service Information
39001 Sunrise Drive, P.O. Box 9200
Farmington Hills, MI USA 48331
FAX: (248) 488-3880

SERVICE MANUAL: Model:

Year:

PUBLICATION NO. (Refer to Quick Reference Index ):
Please describe any Service Manual issues or problems in detail:
Page number(s)

Note: Please include a copy of each page, marked with your comments.

Are the trouble diagnosis procedures logical and easy to use? (circle your answer)

YES

NO

If no, what page number(s)?

Note: Please include a copy of each page, marked with your comments.

Please describe the issue or problem in detail:

Is the organization of the manual clear and easy to follow? (circle your answer)

YES

NO

Please comment:

What information should be included in NISSAN Service Manuals to better support you in servicing or
repairing customer vehicles?

DATE:

YOUR NAME:

POSITION:

DEALER:

DEALER NO.:

ADDRESS:

CITY:

STATE/PROV./COUNTRY:

ZIP/POSTAL CODE:

QUICK REFERENCE CHART JUKE

QUICK REFERENCE CHART JUKE

PFP:00000

ENGINE TUNE-UP DATA (MR16DDT)

ELS0003W

*: Under the following conditions

• A/C switch: OFF

• Electric load: OFF (Lights, heater fan & rear window defogger)

• Steering wheel: Kept in straight-ahead position

Engine model

MR16DDT

Firing order

1 - 3 - 4 - 2

Idle speed

rpm

CVT: No load* (in P or N position)

650

±

 50

M/T: No load* (in Neutral position)

600

±

 50

Ignition timing (BTDC at idle speed)

For NISMO RS models

CVT: No load* (in P or N position)

6

°



±

 2

°

M/T: No load* (in Neutral position)

8

°



±

 2

°

Except for NISMO RS models

CVT: No load* (in P or N position)

5

°



±

 2

°

M/T: No load* (in Neutral position)

5

°



±

 2

°

Tensions of drive belt

 Belt tension is not necessary, as it is automatically adjusted

by drive belt auto-tensioner.

Radiator cap relief pressure

kPa (kg/cm

2

, psi)

For NISMO RS models

Standard

78 - 98 (0.8 - 1.0, 11 - 14)

Limit

59 (0.6, 9)

Except for NISMO RS models

Standard

80 - 100 (0.8 - 1.0, 11.6 - 14.5)

Limit

60 (0.6, 8.7)

Cooling system leakage testing pressure

kPa (kg/cm

2

, psi)

For NISMO RS models

98 (1.0, 14)

Except for NISMO RS models

100 (1.0, 14.5)

Compression pressure

kPa (kg/cm

2

, psi)/rpm

For NISMO RS models

Standard

1,560 (15.9, 226.2)/250

Minimum

1,190 (12.1, 172.6)/250

Differential limit between cylinders

100 (1.0, 14.5)/250

Except for NISMO RS models

Standard

1,550 (15.81, 224.7)/200

Minimum

1,290 (13.15, 187.0)/200

Differential limit between cylinders

100 (1.0, 14.5)/200

Spark plug (Iridium-tipped type)

For NISMO RS models

Make

NGK

Standard type

DILKAR7C9H

Except for NISMO RS models

Make

NGK

Standard type

DILKAR7E9HS

Gap (Nominal)

Standard

0.9 (0.035)

Limit

1.1 (0.043)

2016
