EXL-224
< REMOVAL AND INSTALLATION >
[HALOGEN TYPE]
LICENSE PLATE LAMP
LICENSE PLATE LAMP
Exploded View
INFOID:0000000012201808
Removal and Installation
INFOID:0000000012201809
CAUTION:
Disconnect the battery negative terminal or remove power circuit fuse when performing the operation
for preventing electric leakage. Refer to
EXL-119, "Precautions for Removing Battery Terminal"
REMOVAL
1. While pressing the license plate lamp to direction right side, pull
it to direction outside and then remove it.
2. Disconnect license plate lamp connector.
INSTALLATION
Install in the reverse order of removal.
Replacement
INFOID:0000000012201810
CAUTION:
• Disconnect the battery negative terminal or remove power circuit fuse when performing the opera-
tion for preventing electric leakage. Refer to
EXL-119, "Precautions for Removing Battery Terminal"
• Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
• Never touch bulb by hand while it is lit or right after being turned off.
• Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
LICENSE PLATE LAMP BULB
1. Remove license plate lamp. Refer to
EXL-224, "Removal and Installation"
.
2. Rotate the bulb socket counterclockwise and unlock it.
1.
License plate lamp housing assembly
2.
Bulb
3.
License plate lamp bulb socket
: Pawl
JMLIA1219ZZ
JPLIA0364ZZ
