TIRE PRESSURE MONITORING SYSTEM

WT-15

< WIRING DIAGRAM >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

JREWC2207GB

WT-16

< WIRING DIAGRAM >

TIRE PRESSURE MONITORING SYSTEM

JREWC2208GB

DIAGNOSIS AND REPAIR WORK FLOW

WT-17

< BASIC INSPECTION >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

BASIC INSPECTION

DIAGNOSIS AND REPAIR WORK FLOW

Work Flow

INFOID:0000000012201844

DETAILED FLOW

1.

COLLECT THE INFORMATION FROM THE CUSTOMER

It is also important to clarify customer concerns before starting the inspection. Reproduce the symptom, and

understand it fully. Interview the customer about the concerns carefully. In some cases, it is necessary to

check the symptoms by driving the vehicle with the customer.

CAUTION:

Customers are not professionals. Never assume“maybe the customer means...” or “maybe the cus-

tomer mentioned this symptom.

>> GO TO 2.

2.

BASIC INSPECTION

1. Turn the ignition switch ON.

CAUTION:

Never start the engine.

2. Check the tire pressure for all wheels and adjust to the specified value. Refer to

WT-47, "Tire Air Pres-

sure"

.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Inspect or repair the tires or wheels.

3.

CHECK LOW TIRE PRESSURE WARNING LAMP

Check low tire pressure warning lamp display.
Does not low tire pressure warning lamp turn OFF?

YES

>> GO TO 4.

NO

>> GO TO 8.

4.

PERFORM SELF-DIAGNOSIS

With CONSULT

Perform “SELF-DIAG RESULTS”.
Is any DTC detected?

YES

>> Record or print DTC and freeze frame data (FFD). GO TO 5.

NO

>> GO TO 7.

5.

RECHECK THE SYMPTOM

With CONSULT

Perform “DTC CONFIRMATION PROCEDURE” with recorded DTC.

If two or more DTCs are detected, refer to

BCS-62, "DTC Index"

 and determine trouble diagnosis order.

Is any DTC detected?

YES

>> GO TO 6.

NO

>> GO TO 7.

6.

REPAIR OR REPLACE ERROR-DETECTED PART

• Repair or replace error-detected parts.

• Reconnect part or connector after repairing or replacing.

• When DTC is detected, erase self-diagnostic result in “AIR PRESSURE MONITOR” of “BCM”.

>> GO TO 9.

7.

CRUISE FOR SYMPTOM CHECK

WT-18

< BASIC INSPECTION >

DIAGNOSIS AND REPAIR WORK FLOW

1. Start the engine.

2. Drive for 10 minutes at a speed of 40 km/h (25 MPH) or more, then stop the vehicle.

CAUTION:

Total time driving at a speed of 40 km/h (25 MPH) or more must be 10 minutes.

>> GO TO 8.

8.

IDENTIFY ERROR-DETECTED SYSTEM BY SYMPTOM DIAGNOSIS

Estimate error-detected system based on symptom diagnosis.

>> GO TO 10.

9.

FINAL CHECK (WHEN DTC WAS DETECTED)

With CONSULT

Perform “DTC CONFIRMATION PROCEDURE” with displayed DTC.
Is any DTC detected?

YES

>> GO TO 6.

NO

>> INSPECTION END

10.

FINAL CHECK (WHEN SYMPTOM OCCURRED)

Make sure that the symptom is not detected.
Does symptom remain?

YES

>> GO TO 8.

NO

>> INSPECTION END
