DLK-502 < COMPONENT DIAGNOSIS > [WITHOUT I-KEY & SUPER LOCK] DOOR SWITCH 2. Check continuity between BCM connector (A) M18 terminal 30 3. Check continuity between BCM connector (A) M18 terminal 30 Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace harness between BCM and door switch. 3. CHECK DOOR SWITCH Check door switch. DLK-502, "PASSENGER SIDE : Component Inspection" . Is the inspection result normal? YES >> GO TO 4. NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****" . 4. CHECK INTERMITTENT INCIDENT Refer to @@@. >> INSPECTION END PASSENGER SIDE : Component Inspection INFOID:0000000001530629 1. CHECK DOOR SWITCH 1. Turn ignition switch OFF. 2. Check passenger door switch. Is the inspection result normal? YES >> Door switch is OK. NO >> Replace front door switch (passenger side). Refer to XX-XX, "*****" . REAR LH BCM connector Terminal Door switch connector Terminal Continuity M18 30 B27 2 Yes BCM connector Terminal Ground Continuity M18 30 No ALKIA0748ZZ ALKIA0747ZZ Terminal Door switch condition Continuity Door switch 2 Ground part of door switch Pressed Yes Released No |
