Nissan Tiida C11. Manual - part 27





AV-102

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

NAVI CONTROL UNIT

48

(B)

Ground

RGB synchronizing signal

Output

Ignition

switch

ON

49

Ground

Shield

50

(G)

Ground

RGB area (YS) signal

Output

Ignition

switch

ON

At RGB image displayed

5 V

At rear view camera image
displayed

51

(R)

Ground

Horizontal synchronizing
(HP) signal

Input

Ignition

switch

ON

52

(W)

Ground

Vertical synchronizing (VP)
signal

Input

Ignition

switch

ON

53

(W)

Ground

Communication signal
(CONT

DISP)

Output

Ignition

switch

ON

When adjusting display-
brightness.

54

(O)

Ground

Communication signal
(DISP

CONT)

Input

Ignition

switch

ON

When adjusting display-
brightness.

55

Shield

61

(R/L)

Ground

Illumination signal

Input

OFF

Lighting switch is OFF.

0 V

Lighting switch is ON.

12 V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

Signal name

Input/

Output

SKIB0825E

PKIB4948J

SKIB0825E

SKIB0823E

PKIB5039J

PKIB5039J

AV

NAVI CONTROL UNIT

AV-103

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DTC Index

INFOID:0000000001728760

Self-diagnosis results display item

63

(W)

Ground

Ignition signal

Input

Ignition

switch

ON

Battery voltage

64

(V)

Ground

Parking brake signal

Input

Ignition

switch

ON

Parking brake ON

0 V

Parking brake OFF

12 V

65

(Y/G)

Ground

Reverse signal

Input

Ignition

switch

ON

R position

12 V

Other than R position

0 V

66

(Y)

Ground

Vehicle speed signal (8-
pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25MPH)

67

(Y)

Ground

Camera-connection recog-
nition signal

Input

Ignition

switch

ON

Connected to camera con-
trol unit connector

0 V

Not connected to camera
control unit connector

5 V

69

(L)

AV communication signal
(H)

Input/

Output

70

(P)

AV communication signal
(L)

Input/

Output

71

(L)

CAN–H

Input/

Output

72

(P)

CAN–L

Input/

Output

73

Ground

GPS antenna signal

Input

Ignition

switch

ACC

Not connected to GPS an-
tenna connector

5 V

74

Shield

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

Signal name

Input/

Output

SKIA6649J

DTC

Error item

Refer to

U1000

CAN COMM CIRCUIT [U1000]

AV-52, "Diagnosis Procedure"

U1010 CONTROL

UNIT (CAN) [U1010]

AV-53, "Diagnosis Procedure"

U1310

CONTROL UNIT (AV) [U1310]

AV-54, "DTC Logic"

U1300
U1240
U1249

U124E
U124F

AV COMM CIRCUIT [U1300]
SWITCH CONN [U1240]
AUDIO H/U CONN [U1249]
AMP CONN [U124E]
RDS CONN [U124F]

AV-79, "Description"

U1243

FRONT DISP CONN [U1243]

AV-76, "Diagnosis Procedure"

U1244

GPS ANTENNA CONN [U1244]

AV-78, "Diagnosis Procedure"

U1200

Control Unit FLASH-ROM [U1200]

AV-55, "DTC Logic"

U1201

Gyro NO CONN [U1201]

AV-56, "DTC Logic"

AV-104

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

NAVI CONTROL UNIT

U1204

GPS COMM [U1204]

AV-59, "Diagnosis Procedure"

U1205

GPS ROM [U1205]

AV-60, "Diagnosis Procedure"

U1206

GPS RAM [U1206]

AV-61, "Diagnosis Procedure"

U1207

GPS RTC [U1207]

AV-62, "Diagnosis Procedure"

U1208

DVD-ROM COMM [U1208]

AV-63, "Diagnosis Procedure"

U1209

DVD-ROM READ [U1209]

AV-64, "Diagnosis Procedure"

U120A

DVD-ROM DISC [U120A]

AV-65, "Diagnosis Procedure"

U120C

DVD-ROM MECHA DETECT [U120C]

AV-66, "Diagnosis Procedure"

U120D

DVD-ROM DRIVE MECHA [U120D]

AV-67, "Diagnosis Procedure"

U120E

DVD-ROM FOCUS [U120E]

AV-68, "Diagnosis Procedure"

U120F

DVD-ROM TOC [U120F]

AV-69, "Diagnosis Procedure"

U1210

DVD-ROM SEEK [U1210]

AV-70, "Diagnosis Procedure"

U1211

DVD-ROM ERR CORRECTION [U1211]

AV-71, "Diagnosis Procedure"

U1212

DVD-ROM DATA FORWARD [U1212]

AV-72, "Diagnosis Procedure"

U1213

DVD-ROM DATA [U1213]

AV-73, "Diagnosis Procedure"

U1214

DVD-ROM TIMEOUT [U1214]

AV-74, "Diagnosis Procedure"

U1215

DVD-ROM LOAD [U1215]

AV-75, "Diagnosis Procedure"

U1216

CAN CONT [U1216]

AV-57, "DTC Logic"

U1217

BLUETOOTH CONN [U1217]

AV-58, "DTC Logic"

DTC

Error item

Refer to

AV

DISPLAY UNIT

AV-105

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DISPLAY UNIT

Reference Value

INFOID:0000000001728763

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0228ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

Signal name

Input/

Output

1

(G)

8

(B)

RGB signal (R: red)

Input

Ignition

switch

ON

Start “Confirmation / Adjust-
ment Mode”, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

2

(G)

Ground

RGB area (YS) signal

Input

Ignition

switch

ON

At RGB image displayed

5 V

At rear view camera image
displayed

3

(R)

8

(B)

RGB signal (G: green)

Input

Ignition

switch

ON

Start “Confirmation / Adjust-
ment Mode”, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

4

(R)

Ground

Horizontal synchronizing
(HP) signal

Output

Ignition

switch

ON

JPNIA0221ZZ

PKIB4948J

JPNIA0222ZZ

SKIB0825E
