AV-94

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

AV CONTROL UNIT

11

(BR)

12

(P)

Sound signal front RH

Output

Ignition

switch

ON

Voice output

13

(O)

14

(V)

Sound signal rear RH

Output

Ignition

switch

ON

Voice output

15

(B)

Ground

Steering switch signal GND

—

Ignition

switch

ON

—

0  V

16

(Y)

15

(B)

Steering switch signal B

Input

Ignition

switch

ON

Keep pressing VOL DOWN
switch.

0 V

Keep pressing VOL UP
switch.

1.2 V

Keep pressing



switch.

2.5 V

Keep pressing

 switch.

3.7 V

Except for above.

5 V

19

(LG)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

20

(B)

Ground

GND

—

Ignition

switch

ON

—

0  V

23

(L)

—

AV communication signal
(H)

Input/

Output

—

—

—

24

(P)

—

AV communication signal
(L)

Input/

Output

—

—

—

30

(W)

31

(O)

TEL voice signal

Input

Ignition

switch

ON

TEL voice output

32

(O)

33

(W)

Voice guidance signal

Input

Ignition

switch

ON

Voice guidance output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

AV CONTROL UNIT

AV-95

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

37

—

Shield

—

—

—

—

38

—

Shield

—

—

—

—

42

—

Antenna signal

Input

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

AV-96

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

AV CONTROL UNIT

Wiring Diagram

INFOID:0000000001728762

ALNWA0140GB

AV

AV CONTROL UNIT

AV-97

< ECU DIAGNOSIS >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ALNWA0141GB
