Blind Spot Warning (BSW) (with Lane Change Assist) (if so equipped)
When there is a malfunction in the
When the sensor is temporarily
When there is a foreign object on
system
not available
the sensor
N00592700058
N00592800059
N00592900076
5
When the warning display appears, the BSW
When the warning display appears, the sensor
When the warning display appears, the radar
does not operate normally because there is a
is temporarily not available for some reason
sensor cannot detect a vehicle traveling side
malfunction in the system. Have the vehicle
such as the environmental condition or
by side or an approaching vehicle, because
inspected at an authorized Mitsubishi Motors
increase of the sensor temperature. When the
foreign objects, such as dirt, snow or ice,
dealer as soon as possible.
warning display does not disappear after
adhere to the bumper surface around the sen-
waiting for a while, contact an authorized
sor.
Mitsubishi Motors dealer.
Remove a dirt, freezing or foreign material on
NOTE
the bumper surface around the sensor.
z When the warning display appears, the BSW
When the warning display does not disappear
will be deactivated.
after having cleaned the bumper surface
around the sensor, contact an authorized
Mitsubishi Motors dealer.
Features and controls
5-91
Blind Spot Warning (BSW) (with Lane Change Assist) (if so equipped)
General information
N00593900086
For vehicles sold in U.S.A.
5
5-92
Features and controls
Rear Cross Traffic Alert (RCTA) (if so equipped)
For vehicles sold in Canada
view mirrors on both sides will blink and a
WARNING
Applicable law: RSS-210
buzzer will sound to alert the driver. A warn-
z
Before using the RCTA, read this entire
ing message will appear on the information
section to fully understand the limitations
This device contains licence-exempt trans-
screen of the multi-information display and
of this system. Failure to follow instruc-
mitter(s)/receiver(s) that comply with Innova-
the
indicator will be changed from green
tions could result in an accident.
tion, Science and Economic Development
to flashing in yellow.
z
Never rely solely on the RCTA when back-
Canada’s licence-exempt RSS(s). Operation
ing up. The RCTA is an aid system. It is
is subject to the following two conditions:
not a substitute for your safe and careful
5
driving. Always check visually behind and
1. This device may not cause interference.
all around your vehicle for other vehicles,
2. This device must accept any interference,
persons, animals or obstructions.
including interference that may cause
The performance of the RCTA may vary
undesired operation of the device.
depending on driving, traffic and/or sur-
rounding conditions.
Radiofrequency radiation exposure informa-
tion:
This equipment complies with radiation
NOTE
exposure limits set forth for an uncontrolled
z
The Blind Spot Warning lights in the outside
environment. This equipment should be
rearview mirrors on both sides will blink,
installed and operated with minimum dis-
even when only one vehicle is approaching
tance of 8 inches (20 cm) between the radia-
from one side.
tor and your body.
z
If a system problem, etc., is detected after the
RCTA warning message appears on the
information screen in the multi-information
Rear Cross Traffic Alert
display, the information screen may change
to another warning message.
(RCTA) (if so equipped)
N00593000133
The Rear Cross Traffic Alert (RCTA) is an
aid system for backing up. When the RCTA
system detects vehicles approaching from the
sides while your vehicle is reversing, the
Blind Spot Warning lights in the outside rear-
Features and controls
5-93
Rear Cross Traffic Alert (RCTA) (if so equipped)
Detection areas
CAUTION
CAUTION
• When the speed of an approaching vehicle
z If the bumper has experienced an impact, the
The detection area is shown as illustrated.
is approximately 4 mph (7 km/h) or less.
sensor may have been damaged and the
• If the sensor detection area is blocked by a
RCTA may not function properly. Have the
nearby object, such as wall or parked vehi-
vehicle inspected at an authorized Mitsubishi
cle.
Motors dealer.
• When a vehicle is approaching from
straight behind your vehicle.
5
To operate
• When your vehicle is exiting from an
angled parking spot.
1. Press the BSW switch while the ignition
switch is turned to the “ON” position or
the operation mode is put in ON.
(Refer to “Blind Spot Warning (BSW): To
operate” on page 5-89.)
2. When the selector lever is moved to the
“R” (REVERSE) position, the RCTA will
operate.
• Immediately after the RCTA has been
CAUTION
turned on.
• Immediately after the ignition switch is
z Within approximately
7 seconds after the
turned to the “ON” position or the opera-
ignition switch is turned to the “ON” posi-
tion mode is put in ON.
tion or the operation mode is put in ON, a
warning message will not appear on the
• When the bumper surface around the sensor
information screen of the multi-information
is covered with dirt, snow and ice, etc.
display even if the system detects a vehicle
• When the sensor becomes extremely hot or
CAUTION
approaching your vehicle.
cold, such as after the vehicle has been
z
In certain situations,
the
RCTA may not
parked for a prolonged time under the blaz-
detect a vehicle in the detection areas. Some
ing sun or in cold weather.
of these situations include;
• When the reversing speed of your vehicle is
approximately 11 mph (18 km/h) or higher.
5-94
Features and controls
Rear Cross Traffic Alert (RCTA) (if so equipped)
NOTE
z
After the system check screen disappears,
the
indicator (green) appears on the infor-
mation screen of the multi-information dis-
play.
Refer to “Information screen (When the igni-
tion switch is turned from the “OFF” posi-
tion to the “ON” position or the operation
5
mode is changed from OFF to ON)” on page
5-112.
z
Set the RCTA to OFF when towing.
z
The Blind Spot Warning light in the outside
rearview mirror may not be visible due to
strong direct sunlight or the glare from the
headlights of vehicles behind you during
night driving.
When a problem is detected in
the system
If the system detects a problem, a warning is
displayed on the information screen in the
multi-information display.
Refer to “Blind Spot Warning (BSW): Sys-
tem problem warning” on page 5-90.
Features and controls
5-95
Rear Cross Traffic Alert (RCTA) (if so equipped)
General information
N00594000084
For vehicles sold in U.S.A.
5
5-96
Features and controls
Lane Departure Warning (LDW) (if so equipped)
For vehicles sold in Canada
you both visual and audible warnings when
WARNING
Applicable law: RSS-210
your vehicle is leaving or has left the lane.
z Before using the LDW, read this entire
For details about handling the sensor, refer to
section to understand the limitations of
This device contains licence-exempt trans-
“Handling of the sensor” on page 5-86.
this system. Failure to follow instructions
mitter(s)/receiver(s) that comply with Innova-
could result in an accident.
tion, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation
is subject to the following two conditions:
To turn on/off the LDW
N00578000060
5
1. This device may not cause interference.
2. This device must accept any interference,
NOTE
including interference that may cause
z The LDW is turned on when the vehicle is
undesired operation of the device.
shipped from the factory.
z The currently selected LDW setting (on or
Radiofrequency radiation exposure informa-
off) is stored even when the ignition switch
tion:
is turned to the “OFF” position or the opera-
This equipment complies with radiation
tion mode is put in OFF.
exposure limits set forth for an uncontrolled
environment. This equipment should be
To turn on the LDW, press the LDW switch.
installed and operated with minimum dis-
The indicator will appear on the informa-
tance of 8 inches (20 cm) between the radia-
tion screen of the multi-information display.
tor and your body.
Lane Departure Warning
(LDW) (if so equipped)
N00577900105
The Lane Departure Warning (LDW) is a
WARNING
driving aid system to help prevent uninten-
z Never rely solely on the LDW. The LDW is
tional lane departure. The LDW is designed
not a collision avoidance system and is not
to read lane markers by using a sensor (A)
a substitute for your safe and careful driv-
under certain conditions. The LDW will give
ing.
Features and controls
5-97
Lane Departure Warning (LDW) (if so equipped)
z The hazard warning light is being oper-
NOTE
ated or has been operated in the past
z
If the lane markers are only on one side of
7 seconds.
the road, the LDW will operate only for the
appropriate side where the lane marker is
Lane departure warning
drawn.
N00581200079
While the
indicator on the information
WARNING
5
screen in the multi-information display is lit
To turn off the LDW, press the LDW switch.
z
The LDW will not function when no lane
in green, if your vehicle is leaving or has left
marker exists, such as at an intersection
The indicator on the information screen of
the lane, a buzzer will sound intermittently,
or near a toll booth.
the multi-information display will then go
and the
indicator will be flashing in yel-
z
The LDW may not operate correctly in the
out.
low.
following situations and the LDW may not
To return the LDW to “ON”, press the LDW
give warnings or may give false warnings:
switch again.
• When lane markers are not clearly visi-
ble due to rain, snow, fog, dark area, etc.
Operation of the LDW
• When the road surface is shiny.
N00581100081
• When old lane markers remain on the
road surface.
The LDW, when turned ON, is capable of
• When the lane markers are double lines
recognizing the lane in which your vehicle is
or the shape of the lane markers are
travelling and issuing an audible warning
complicated.
(green)
(flashing in yellow)
when your vehicle begins to leave that travel
• When driving in an extremely narrow
lane. When operating, the
indicator on the
lane.
information screen in the multi-information
• When the distance between your vehicle
display will be changed to green. However,
and a vehicle in front is short.
the LDW will not operate in the following sit-
NOTE
• When driving into the sun light.
z
The warning will not continue for more than
• When driving on curves.
uations even if the
indicator appears:
3 seconds, even if your vehicle continues
• When driving on bumpy roads.
z The vehicle speed is less than approxi-
leaving the lane.
• When driving in construction zones.
mately 38 mph (60 km/h).
• When passing through a place where the
z The turn signal lever is being operated or
brightness suddenly changes, such as at
the entrance to or exit of a tunnel.
has been operated in the past 7 seconds.
5-98
Features and controls
Lane Departure Warning (LDW) (if so equipped)
WARNING
System problem warning
Windshield is dirty
• When the headlights of an oncoming
N00578100061
The alarm shown below is displayed if the
vehicle are very bright.
If a problem occurs with the system, a visual
system becomes temporarily unavailable due
• When the rear of your vehicle is weighed
warning specific to the type of the problem is
down with the weight of passengers and
to the dirty windshield of the sensor portion.
given together with an audible alarm.
luggage.
After having cleaned the windshield, the sys-
• When the headlights of your vehicle are
tem will automatically return to operation.
not clean or are not properly aimed.
Sensor is too hot or cold
If the alarm continues showing, there is a pos-
5
• When the front windshield is not clean.
sibility that the LDW has a malfunction. Con-
The alarm shown below is displayed if the
• When the front windshield wipers do not
tact an authorized Mitsubishi Motors dealer
clean the windshield properly.
system becomes temporarily unavailable due
for inspection of the sensor.
to the high or low temperature of the sensor.
After temperature of the sensor has been in
CAUTION
range, the system will automatically return to
z
To maintain proper function of the LDW:
operation.
• Always keep the windshield and the head-
If the alarm continues showing, there is a pos-
lights clean.
sibility that the LDW has a malfunction. Con-
• Do not put anything, such as a sticker, on
tact an authorized Mitsubishi Motors dealer
the front windshield in front of the sensor.
for inspection of the system.
• Avoid applying a shock or load to the sen-
sor.
• Do not attempt to detach or disassemble the
sensor.
• Use only Mitsubishi Motors Genuine parts
when replacing the windshield wipers.
NOTE
z When driving conditions are not suitable to
use the LDW, turn off the LDW.
Features and controls
5-99
Tire pressure monitoring system
LDW deactivation due to fault
Tire pressure monitoring
NOTE
z
The tire pressure monitoring system is not a
If the LDW is deactivated due to a malfunc-
system
substitute for regularly checking tire infla-
tion in the system, the either alarm shown
N00530201625
tion pressures.
below is displayed. Contact your authorized
The tire pressure monitoring system uses tire
Be sure to check the tire inflation pressures
Mitsubishi Motors dealer for inspection of the
inflation pressure sensors (A) on the wheels
as described in “Tires” on page 9-14.
system.
to monitor the tire inflation pressures. The
z
The tire inflation pressure sensor
(B) is
system only indicates when a tire is signifi-
installed in the illustrated location.
5
cantly under-inflated.
• On vehicles with Type 1 sensor which has
the metallic air valve (C), replace grommet
and washer (D) with a new one when the
tire is replaced.
• On vehicles with Type 2 sensor which has
the rubber air valve (E), replace rubber air
valve (E) with a new one when the tire is
replaced.
NOTE
z If the sensor or its surrounding area becomes
extremely hot (after prolonged exposure to
direct sunlight, for example), the
“LDW
WARNING
SERVICE REQUIRED” message may
z The compact spare wheel does not have a
appear.
tire inflation pressure sensor.
If the message remains even after the tem-
When the spare tire is used, the tire pres-
perature of the sensor or its surrounding area
sure monitoring system will not work
has been in range, please contact an autho-
properly.
rized Mitsubishi Motors dealer.
See an authorized Mitsubishi Motors
dealer as soon as possible to replace or
repair the original tire.
5-100
Features and controls
Tire pressure monitoring system
warning light normally illuminates and goes
NOTE
CAUTION
off a few seconds later.
For details, please contact your authorized
z
If the tire pressure monitoring system warn-
Mitsubishi Motors dealer.
ing light does not illuminate when the igni-
If one or more of the vehicle tires (except for
tion switch is turned to the “ON” position or
the spare tire) is significantly under-inflated,
Type 1
the operation mode is put in ON, it means
the warning light will remain illuminated
that the tire pressure monitoring system is
while the ignition switch or the operation
not working properly. Have the system
mode is in ON.
inspected by an authorized Mitsubishi
Refer to “If the warning light / display illumi-
5
Motors dealer.
nates while driving” on page 5-102 and take
In such situations, a malfunctioning of the
the necessary measures.
system may be preventing the monitoring of
the tire pressure. Avoid sudden braking,
sharp turning and high-speed driving.
NOTE
z
If a malfunction is detected in the tire pres-
Type 2
z
In addition, the warning display is displayed
sure monitoring system, the tire pressure
on the information screen in the multi-infor-
monitoring system warning light will blink
mation display.
for approximately 1 minute and then remain
continuously illuminated. The warning light
will issue further warnings each time the
engine is restarted as long as the malfunction
exists.
Check to see whether the warning light goes
off after few minutes driving.
If it then goes off during driving, there is no
The tire pressure monitoring
problem.
system warning light / display
However, if the warning light does not go
N00532701406
off, or if it blinks again when the engine is
restarted, have the vehicle inspected by an
authorized Mitsubishi Motors dealer.
In such situations, a malfunctioning of the
system may be preventing the monitoring of
When the ignition switch is turned to the
the tire pressure. For safety reasons, when
“ON” position or the operation mode is put in
the warning light appears while driving,
ON, the tire pressure monitoring system
avoid sudden braking, sharp turning and
high-speed driving.
Features and controls
5-101
Tire pressure monitoring system
Under-inflation also reduces fuel efficiency
allow the TPMS to continue to function prop-
NOTE
and tire tread life, and may affect the vehi-
erly.
z In addition, the warning display is displayed
cle’s handling and stopping ability. Please
on the information screen in the multi-infor-
note that the TPMS is not a substitute for
mation display.
If the warning light/display illu-
proper tire maintenance, and it is the driver’s
minates while driving
responsibility to maintain correct tire pres-
sure, even if under-inflation has not reached
N00532801524
1. If the tire pressure monitoring system
the level to trigger illumination of the TPMS
5
warning light illuminates, avoiding hard
low tire pressure telltale.
braking, sharp steering maneuvers and
Your vehicle has also been equipped with a
high speeds. You should stop and adjust
Each tire, including the spare (if provided),
TPMS malfunction indicator to indicate when
the tires to the proper inflation pressure as
should be checked monthly when cold and
the system is not operating properly. The
soon as possible. Adjust the spare tire at
inflated to the inflation pressure recom-
TPMS malfunction indicator is combined
the same time. Refer to “Tires” on page
mended by the vehicle manufacturer on the
with the low tire pressure telltale.
9-14.
vehicle placard or tire inflation pressure label.
When the system detects a malfunction, the
(If your vehicle has tires of a different size
telltale will flash for approximately one min-
NOTE
than the size indicated on the vehicle placard
ute and then remain continuously illuminated.
z
In addition, the warning display is displayed
or tire inflation pressure label, you should
This sequence will continue upon subsequent
on the information screen in the multi-infor-
determine the proper tire inflation pressure
vehicle start-ups as long as the malfunction
mation display.
for those tires.)
exists.
z
When inspecting or adjusting the tire pres-
As an added safety feature, your vehicle has
When the malfunction indicator is illumi-
sure, do not apply excessive force to the
valve stem to avoid breakage.
been equipped with a tire pressure monitoring
nated, the system may not be able to detect or
z
After inspecting or adjusting the tire pres-
system (TPMS) that illuminates a low tire
signal low tire pressure as intended.
sure, always reinstall the valve cap on the
pressure telltale when one or more of your
TPMS malfunctions may occur for a variety
valve stem.
tires is significantly under-inflated.
of reasons, including the installation of
Without the valve cap, dirt or moisture could
Accordingly, when the low tire pressure tell-
replacement or alternate tires or wheels on the
get into the valve, resulting in damage to the
tale illuminates, you should stop and check
vehicle that prevent the TPMS from function-
tire inflation pressure sensor.
your tires as soon as possible, and inflate
ing properly. Always check the TPMS mal-
z
Do not use metal valve caps, which may
them to the proper pressure. Driving on a sig-
function telltale after replacing one or more
cause a metal reaction, resulting in corrosion
nificantly under-inflated tire causes the tire to
tires or wheels on your vehicle to ensure that
and damage of the tire inflation pressure sen-
overheat and can lead to tire failure.
the replacement or alternate tires and wheels
sors.
5-102
Features and controls
Tire pressure monitoring system
z A window tint that affects the radio wave
NOTE
NOTE
signals is installed.
z Once adjustments have been made, the warn-
z To avoid the risk of damage to the tire infla-
ing light will go off after a few minutes of
tion pressure sensors, have any punctured
driving.
tire repaired by an authorized Mitsubishi
NOTE
Motors dealer. If the tire repair is not done by
z Tire inflation pressures vary with the ambi-
2. If the tire pressure monitoring system
an authorized Mitsubishi Motors dealer, it is
ent temperature. If the vehicle is subjected to
warning light remains illuminated after
not covered by your warranty.
large variations in ambient temperature, the
you have been driving for about 20 min-
z Do not use an aerosol puncture-repair spray
tire inflation pressures may be under-inflated
5
utes after you adjust the tire inflation pres-
on any tire.
(causing the warning light/display to come
sure, one or more of the tires may have a
Such a spray could damage the tire inflation
on) when the ambient temperature is rela-
puncture. Inspect the tire and if it has a
pressure sensors.
tively low. If the warning light/display
puncture, have it repaired by an autho-
Have any puncture repaired by an authorized
comes on, adjust the tire inflation pressure.
Mitsubishi Motors dealer.
rized Mitsubishi Motors dealer as soon as
possible.
The tire pressure monitoring system may not
Whenever the tires and wheels
WARNING
work normally in the following circum-
are replaced with new ones
stances:
N00532901192
z If the warning light/display illuminates
while you are driving, avoid hard braking,
If new wheels with new tire inflation pressure
z A wireless facility or device using the
sharp steering maneuvers and high
sensors are installed, their ID codes must be
same frequency is near the vehicle.
speeds.
programmed into the tire pressure monitoring
Driving with an under-inflated tire
z Snow or ice is stuck inside the fenders
system. Have the tire and wheel replacement
adversely affects vehicle performance and
and/or on the wheels.
performed by an authorized Mitsubishi
can result in an accident.
z The tire inflation pressure sensor’s battery
Motors dealer to avoid the risk of damaging
is dead.
the tire inflation pressure sensors. If the
z Wheels other than Mitsubishi genuine
wheel replacement is not done by an autho-
CAUTION
wheels are being used.
rized Mitsubishi Motors dealer, it is not cov-
z If a tire has a puncture, replace that tire with
z Wheels that are not fitted with tire infla-
ered by your warranty.
the spare tire. Driving on a punctured tire
tion pressure sensors are being used.
could lead to an accident.
z Wheels whose ID codes are not memo-
z The warning light/display may not illuminate
rized by the vehicle are used.
immediately in the event of a tire blowout or
z Compact spare tire is fitted on a road
rapid leak.
wheel.
Features and controls
5-103
Rear-view camera
CAUTION
Rear-view camera
z The use of non-genuine wheels will prevent
N00546201402
the proper fit of the tire inflation pressure
When the selector lever is in the “R” position
sensors, resulting air leakage or damage of
with the ignition switch or the operation
the sensors.
mode is in ON, the rear-view image will be
displayed on the screen of the Smartphone-
link Display Audio (SDA) or the DISPLAY
5
General information
AUDIO in the center panel.
N00533001246
When the selector lever is shifted out of the
Your tire pressure monitoring system oper-
“R” position, the rear-view image will go off.
ates on a radio frequency subject to Federal
Communications Commission (FCC) Rules
CAUTION
WARNING
(For vehicles sold in U.S.A.) and Industry
z
If the camera lens gets dirty, a clear image
z
Never rely solely on the rear-view camera
Canada Rules (For vehicles sold in Canada).
cannot be obtained. As necessary, rinse the
to clear the area behind your vehicle.
This device complies with part 15 of FCC
lens with clean water and gently wipe with a
Always check visually behind and all
clean, soft cloth.
Rules and Industry Canada licence-exempt
around your vehicle for persons, animals,
z
To avoid damaging the camera;
RSS standard(s).
obstructions or other vehicles. Failure to
• Do not rub the cover excessively or polish
Operation is subject to the following two con-
do so can result in vehicle damage, serious
it by using an abrasive compound.
ditions.
injury or death.
• Do not disassemble the camera.
z
The rear-view camera is an aid system for
z This device may not cause harmful inter-
• Do not splash hot water directly on the lens.
backing up, but it is not a substitute for
ference.
your visual confirmation.
• Do not spray the camera and its surround-
z This device must accept any interference
z
The view on the screen is limited, and
ings with high-pressure water.
received, including interference that may
objects outside the view, such as under the
• Make sure that the liftgate is securely
cause undesired operation.
bumper or around either corner of the
closed when backing up.
bumper end, cannot be seen on the screen.
CAUTION
Reference lines on the screen
z Changes or modifications not expressly
Location of rear-view camera
approved by the manufacturer for compli-
ance could void the user’s authority to oper-
Reference lines and upper surface of the rear
ate the equipment.
The rear-view camera (A) is in the liftgate, at
bumper (A) are displayed on the screen.
the left side of the liftgate handle.
5-104
Features and controls
Rear-view camera
z
Red line
(B) indicates approximately
CAUTION
Case 2
20 inches (50 cm) behind the rear bumper.
z
Actual distance may be different from dis-
z
Two Green lines (C) indicate approxi-
tance indicated by the lines on the screen,
mately 8 inches (20 cm) outside of the
depending on the loading condition of the
vehicle body.
vehicle and road surface condition.
z
Short transverse lines (1 to 3) indicate dis-
The reference lines for distance and vehicle
tance from the rear bumper.
width are based on a level, flat road surface.
In the following cases, objects shown on the
A- Actual objects
5
screen will appear to be farther off than they
B- Objects shown on the screen
actually are.
• When the rear of the vehicle is weighed
down with the weight of passengers and
luggage in the vehicle. (Case 1)
CAUTION
• When there is an upward slope at the back.
z
The reference lines for distance and vehicle
(Case 2)
width are intended to indicate the distance to
a flat object such as a level, flat road surface.
Case 1
They may not indicate correct distance
depending on the shape of an obstacle.
For example, when there is an object behind
1:
Approximately at the rear edge of
the
the vehicle that has upper sections projecting
in the direction of the vehicle, the reference
rear bumper (if so equipped)
lines on the screen will indicate that point A
2:
Approximately 39 inches (100 cm)
is the farthest point and point B is the closest
3:
Approximately 79 inches (200 cm)
point to the vehicle. In reality, point A and B
A- Actual objects
are actually the same distance from the vehi-
B- Objects shown on the screen
cle, and point C is farther off than point A
CAUTION
and B.
z The rear-view camera uses a wide-angle
lens. As a result, images and distances shown
on the screen are not exact.
Features and controls
5-105
Instrument cluster
Instrument cluster
Type A
N00519001486
5
NOTE
Type B
z
Mirror image is displayed on the screen.
1- Tachometer P.5-106
z
Monitor brightness is adjusted automatically
2- Multi-information display P.5-108
by sensors.
Information screen display list
z
On vehicles equipped with the Smartphone-
P.5-128
link Display Audio (SDA), it is possible to
3- Speedometer P.5-106
change the display language of the screen.
4- Rheostat meter illumination button
For details, please refer to the separated
owner’s manual.
P.5-107
z
Under certain circumstances, it may become
difficult to see an image on the screen, even
when the system is functioning correctly.
Speedometer
• In a dark area, such as at night.
N00519100259
Tachometer
• When water drops or condensation are on
The speedometer shows the vehicle speed in
N00519201345
the lens.
miles per hour (mph) or kilometers per hour
• When sun light or headlights shine directly
The tachometer shows engine revolutions per
(km/h).
into the lens.
minute. This allows the driver to determine
the most efficient selector position and engine
speed combinations.
This gauge also assists in evaluating engine
performance.
5-106
Features and controls
Instrument cluster
NOTE
z
When the light switch is in the “
”, “
”,
or “AUTO” position, the meter illumination
switches automatically to the adjusted
brightness, depending on the brightness out-
side the vehicle.
z
The brightness level of the instruments is
stored when the ignition switch is turned to
5
the “OFF” position or the operation mode is
put in OFF.
z
If you press and hold the button for longer
1-
Brightness display
than approximately 1 second when the front
CAUTION
2-
Rheostat illumination button
side-marker lights are illuminated, the
z
The red zone indicates an engine speed
brightness level changes to the maximum
beyond the range of safe operation.
level. Pressing and holding the button for
Select the correct selector position to control
longer than approximately 1 second again
the engine speed so that the tachometer indi-
returns the brightness level to the previous
cator does not enter the red zone.
level.
It is recommended to use this function when
it is difficult to read the meter due to the
Rheostat meter illumination
meter illumination is dimmed by turning on
the front side-marker lights in bright areas.
button
For vehicles equipped with the Smartphone-
N00554901378
Link Display Audio (SDA), the operation of
Each time you press this button, there is a
the screen background theme and the switch
sound and the brightness of the instruments
illumination when the meter illumination
changes.
brightness level is changed to the maximum
vary depending on the specifications of the
SDA.
NOTE
z You can adjust to 8 different levels respec-
tively for when the front side-marker and
parking lights are illuminated and when they
are not.
Features and controls
5-107
Multi-information display
Multi-information display
N00555001552
The multi-information display displays warnings, the odometer, trip odometer, service reminder, engine coolant temperature, fuel remaining, out-
side temperature, selector lever position, all-wheel drive operation status, average and momentary fuel consumption, driving range, average
speed, instrument brightness, etc.
It is also possible to change elements such as the language and units used on the multi-information display.
5
With ignition switch or operation mode in OFF
With ignition switch or operation mode in ON
1-
4- Odometer P.5-110
10- Information screen
(With ignition
Warning display screen (With igni-
5- Drive mode indicator display screen (if
switch or operation mode in ON)
tion switch or operation mode in OFF)
so equipped) P.5-112
P.5-113
P.5-109
6-
Interrupt display screen (With ignition
2- Information screen
(With ignition
Warning display screen (With igni-
switch or operation mode in ON)
switch or operation mode in OFF)
tion switch or operation mode in ON)
P.5-116
P.5-110
P.5-113
11- Fuel remaining display screen
Interrupt display screen (With ignition
7- Lane Departure Warning (LDW) dis-
P.5-117
switch or operation mode in OFF)
play screen (if so equipped) P.5-97
12- Outside temperature display screen
P.5-111
8- Blind Spot Warning
(BSW) display
P.5-117
3- Door ajar warning display screen (With
screen (if so equipped) P.5-87
13- Selector lever position display screen
ignition switch or operation mode in
9- ECO indicator P.5-117
P.5-117
OFF) P.5-111
5-108
Features and controls
Multi-information display
14- Engine coolant temperature display
Multi-information meter switch
Warning display screen
P.5-113
N00555101250
(With ignition switch or opera-
The multi-information meter switch is a but-
tion mode in OFF)
NOTE
ton marked “INFO” on the left side of the
z
The fuel units, temperature units, display
N00555200179
dash.
language, and other settings can be changed.
If you press the multi-information meter
Each time the multi-information meter switch
Refer to
“Changing the function settings
switch and return from the warning display
is operated, a sound is emitted and the multi-
(With ignition switch or operation mode in
information display changes between infor-
screen to the previous screen, the
warning
5
ON)” on page 5-120.
mation such as warnings, trip odometer, ser-
is displayed.
z
The display screen is different depending on
whether the ignition switch or the operation
vice reminder, average and momentary fuel
Refer to
“Returning to the display screen
mode in OFF or ON.
consumption, driving range, and average
from before the warning display” on page
Refer to “Information screen (With ignition
speed.
5-111.
switch or operation mode in OFF)” on page
It is also possible to change elements such as
This mark is also displayed if there is another
5-110.
the language and units used on the multi-
warning other than the one displayed. When
Refer to “Warning display list (With ignition
information display by operating the multi-
the cause of the warning display is elimi-
switch or operation mode in OFF)” on page
information meter switch.
nated, the
warning goes out automatically.
5-128.
Refer to “Information screen (When the igni-
tion switch is turned from the “OFF” posi-
NOTE
tion to the “ON” position or operation mode
changed from OFF to ON)” on page 5-112.
z When the warning is displayed, the warn-
Refer to “Information screen (With ignition
ing display screen can be redisplayed on the
switch or operation mode in ON)” on page
information screen.
5-113.
Refer to “Information screen (With ignition
Refer to “Warning display list (With ignition
switch or operation mode in OFF)” on page
switch or operation mode in ON)” on page
5-110.
5-132.
Refer to “Information screen (With ignition
switch or operation mode in ON)” on page
5-113.
Features and controls
5-109
Multi-information display
Information screen (With igni-
Odometer/Trip odometer
N00555401152
tion switch or operation mode
in OFF)
Odometer
N00555301223
Shows the total distance traveled.
Each time you lightly press the multi-infor-
mation meter switch, the display screen
Trip odometer
switches in the following order.
5
Shows the distance traveled between two
points.
Usage examples for trip odometer
, trip
NOTE
odometer
z
If there is no warning display, the switching
It is possible to measure two currently
sequence is: trip odometer
trip odom-
When there is no
traveled distances, from home using trip
eter
service reminder trip odome-
warning display
odometer
and from a particular point
ter
on the way using trip odometer
z
Both trip odometers
and
can count
up to 9999.9 miles/kilometers.
When a trip odometer goes past
9999.9
When there is a
To reset the trip odometer
miles/kilometers, it returns to 0.0 miles/kilo-
warning display
meters.
To return the display to 0, hold down the
z
When disconnecting the battery terminal, the
multi-information meter switch for about 2
memories of trip odometer displays
and
seconds or more. Only the currently dis-
are cleared, and their displays return to
played value will be reset.
“0.0 miles/kilometers”.
1-
Example
Trip odometer
2-
If trip odometer
is displayed, only trip
Trip odometer
Service reminder
3-
Service reminder
odometer
will be reset.
N00555500042
4-
Redisplay of a warning display screen
Shows the distance and number of months
until the next periodic inspection.
5-110
Features and controls
Multi-information display
Refer to “Service reminder” on page 5-118.
Returning to the display screen
NOTE
from before the warning display
z Warning display screens with a
” or
Interrupt display screen (With
” mark displayed in the upper right of the
ignition switch or operation
Even if the cause of the warning display is
screen can be switched. If you want to switch
mode in OFF)
not eliminated, you can return to the screen
the display, press the multi-information
N00559601224
that was displayed before the warning dis-
meter switch as follows.
play.
When there is information to be announced,
”: Press lightly.
5
If you press the multi-information meter
such as a key reminder, the buzzer sounds and
switch, the display screen switches to the
”: Press for about 2 seconds or more.
switches to the warning display screen. Refer
screen display from before the warning and
to the appropriate page and take the necessary
Redisplay of a warning display screen
measures.
the
warning (A) is displayed.
When the cause of the warning display is
When the
warning is displayed, if you
eliminated, the warning display goes out
lightly press the multi-information meter
automatically.
switch a few times, the warning display
Refer to “Warning display list (With ignition
screen you switched from is redisplayed.
switch or operation mode in OFF)” on page
Refer to “Information screen (With ignition
5-128.
switch or operation mode in OFF)” on page
5-110.
Door ajar warning display
screen (With ignition switch or
operation mode in OFF)
N00559701179
If any of the doors or the liftgate is not com-
pletely closed, this displays the open door or
liftgate.
1- Information generated
2- Cause eliminated
Features and controls
5-111















Content      ..     6      7      8      9     ..
