Mitsubishi Outlander Sport (2022 year). Manual in english - page 9

Multi-information display

NOTE

z The system check screen display varies

5

depending on your equipment.

1- Doors and liftgate are closed

1- Screen when the ignition switch or oper-

Service reminder

2- Doors or liftgate is open

ation mode is OFF

2- System check screen

3- Screen when the ignition switch or oper-

When the time for periodic inspection arrives,

ation mode is ON

the warning display is displayed for a few

Information screen (When the

seconds after the screen that is initially dis-

ignition switch is turned from

played when the ignition switch is turned

the “OFF” position to the “ON”

System check screen

“ON” or the operation mode is changed to

position or the operation mode

ON.

Refer to “Service reminder” on page 5-118.

is changed from OFF to ON)

When the ignition switch is turned to the

N00555801316

“ON” position or the operation mode is

changed to ON, the system check screen is

When the ignition switch is turned to the

displayed for approximately

4 seconds. If

“ON” position or the operation mode changed

there in no fault, the information screen is

to ON, the display screen switches in the fol-

displayed.

lowing order.

If there is a fault, the screen changes to warn-

ing display.

Drive mode indicator display

Refer to “Warning display list (With ignition

screen (if so equipped)

switch or operation mode in ON)” on page

N00555900020

5-132.

Shows the 4WD drive status.

Refer to “Drive mode-selector” on page 5-62.

5-112

Features and controls

Multi-information display

5- Average fuel consumption display,

Warning display screen

Information screen (With igni-

momentary fuel consumption display

(With ignition switch or opera-

tion switch or operation mode

6- Average speed display, momentary fuel

tion mode in ON)

in ON)

consumption display

N00555200182

N00556201359

7- Function setting screen

8- Redisplay of a warning display screen

This is displayed when you press the multi-

Each time you lightly press the multi-infor-

information meter switch and switch the

mation meter switch, the display

screen

warning display screen.

switches in the following order.

NOTE

5

This mark is also displayed if there is another

z

While driving, the function setting screen is

warning other than the one displayed.

not displayed even if you operate the multi-

When the cause of the warning display is

information meter switch. Always park the

vehicle in a safe place before operating.

eliminated, the

warning goes out automat-

Refer to

“Changing the function settings

ically.

(With ignition switch or operation mode in

ON)” on page 5-120.

When there is no

z

When there is information to be announced,

NOTE

warning display

such as a system fault, the tone sounds and

z

When the warning is displayed, the warn-

the screen display is switched.

ing display screen can be redisplayed on the

Refer to “Interrupt display screen (With igni-

information screen.

tion switch or operation mode in ON)” on

Refer to “Information screen (With ignition

page 5-116.

switch or operation mode in OFF)” on page

5-110.

Refer to “Information screen (With ignition

When there is a

Odometer/Trip odometer

switch or operation mode in ON)” on page

warning display

5-113.

The operation method is the same as when

the ignition switch or the operation mode is in

1-

Trip odometer

OFF.

For further details, refer to “Odometer/Trip

2-

Trip odometer

odometer” on page 5-110.

3-

Service reminder

4-

Driving range display, momentary fuel

consumption display

Features and controls

5-113

Multi-information display

Be conscious of maintaining the momentary

Service reminder

NOTE

fuel consumption above the average fuel con-

z

The driving range is determined based on the

sumption, it can help you drive with the better

Shows the distance and number of months

fuel consumption data. This may vary

fuel consumption.

depending on the driving conditions and hab-

until the next periodic inspection.

its. Treat the distance displayed as just a

Refer to “Service reminder” on page 5-118.

rough guideline.

NOTE

z

When you refuel, the driving range display is

z

When the momentary fuel consumption can-

Engine coolant temperature dis-

updated.

not be measured, a bar graph is not shown.

5

play

However, if you only add a small amount of

z

The display setting can be changed to the

fuel, the correct value will not be displayed.

preferred units

{mpg

(US), mpg

(UK),

Fill to a full tank whenever possible.

L/100km or km/L}.

Shows the engine coolant temperature.

z

When your vehicle is stopped on an

Refer to

“Changing the function settings

If the coolant becomes hot, “

” will blink.

extremely steep hill, the driving range value

(With ignition switch or operation mode in

Pay careful attention to the engine coolant

may, change. This is due to the movement of

ON)” on page 5-120.

temperature display while you are driving.

fuel in the tank and does not indicate any

z

It is possible to cancel the green bar graph.

breakdown.

Refer to

“Changing the function settings

z

The display setting can be changed to the

(With ignition switch or operation mode in

CAUTION

preferred units (miles or km).

ON)” on page 5-120.

z If the engine is overheating, “

” will blink.

Refer to

“Changing the function settings

(With ignition switch or operation mode in

In this case, the bar graph is on the red zone.

ON)” on page 5-120.

Immediately park the vehicle in a safe place

Average fuel consumption display

and take the required measures. Refer to

“Engine overheating” on page 8-4.

This displays the average fuel consumption

Momentary fuel consumption dis-

from the last reset to the present.

play

There are 2 types of mode settings as follows.

Driving range display

For details on how to change the average fuel

While driving, the momentary fuel consump-

consumption display setting, refer to “Chang-

Shows the approximate driving range (how

tion is shown with a bar graph.

ing the function settings (With ignition switch

many more miles or kilometers you can

When the momentary fuel consumption sur-

or operation mode in ON)” on page 5-120.

drive). When this driving range falls below

passes the average fuel consumption, the

The “

” mark in the momentary fuel gauge

30 miles (50 km), “---” is displayed.

momentary fuel consumption is displayed

shows the average fuel consumption.

Refuel immediately.

with a green bar graph.

5-114

Features and controls

Multi-information display

information screen is switched to the warning

Auto reset mode

NOTE

display screen.

z The display setting can be changed to the

z

When the average speed is being dis-

Refer to the warning list and take the neces-

preferred units (mph or km/h).

played, if you hold down the multi-infor-

sary measures. Refer to “Warning display list

Refer to

“Changing the function settings

mation meter switch, these calculations

(With ignition switch or operation mode in

(With ignition switch or operation mode in

will be reset to zero.

ON)” on page 5-120.

ON)” on page 5-132.

z

When the engine switch or the operation

z Disconnecting the battery cable will erase

When the cause of the warning display is

mode is in the following conditions, the

from memory the manual reset mode or auto

eliminated, the warning display goes out

5

average speed display will automatically

reset mode setting for the average speed dis-

automatically.

reset.

play.

Returning to the display screen from

[Except for vehicles equipped with the

Function setting screen

before the warning display

F.A.S.T.-key]

The ignition switch has been set to the

Even if the cause of the warning display is

The “Display language”, “Temperature unit”,

“ACC” or

“OFF” position for about

not eliminated, you can return to the screen

“Fuel consumption unit”, and “Average fuel

4 hours or more.

that was displayed before the warning dis-

consumption and speed reset method” set-

play.

[For vehicles equipped with the F.A.S.T.-

tings can be modified as desired.

key]

For further details, refer to

“Changing the

If you press the multi-information meter

The operation mode has been set to ACC

function settings

(With ignition switch or

switch, the display screen switches to the

or OFF for about 4 hours or more.

operation mode in ON)” on page 5-120.

screen display from before the warning and

the

warning (A) is displayed.

Interrupt display screen (With

NOTE

z The average speed display and the average

ignition switch or operation

fuel consumption display can be reset sepa-

mode in ON)

rately in both auto reset mode and manual

N00556301262

reset mode.

z “---” is displayed when the average speed

cannot be measured.

Warning display

z The initial

(default) setting is

“Auto reset

mode”.

When there is information to be announced,

such as a system fault, a tone sounds and the

5-116

Features and controls

Multi-information display

Other interrupt displays

ECO indicator

N00568701061

The operation status of each system is dis-

This indicator will be displayed when fuel-

played on the information screen.

efficient driving is achieved.

For further details, refer to the appropriate

page in the warning display list.

Fuel remaining display screen

Refer to “Other interrupt displays” on page

N00556601249

5-141.

5

Shows the amount of fuel remaining.

Selector lever position display

screen

NOTE

N00556401074

z

Warning display

screens

with

a

“

”

or

Shows the position of the selector lever.

“

” mark displayed in the upper right of the

Refer to “Selector lever operation” on page

screen can be switched. If you want to switch

5-55.

the display, press the multi-information

meter switch as follows.

Outside temperature display

“

”: Press lightly.

screen

“

”: Press for about 2 seconds or more.

N00556500065

Shows the temperature outside the vehicle.

CAUTION

Redisplay of a warning display

z

Running out of gas could damage the cata-

screen

NOTE

lytic converter. If the warning display

z The display setting can be changed to the

appears, refuel immediately.

preferred units (°F or °C).

When the

warning is displayed, if you

Refer to

“Changing the function settings

lightly press the multi-information meter

(With ignition switch or operation mode in

NOTE

switch a few times, the warning display

ON)” on page 5-120.

z

It may take several seconds to stabilize the

screen you switched from is redisplayed.

z Depending on factors such as the driving

display after refilling the tank.

conditions, the displayed temperature may

vary from the actual outside temperature.

Features and controls

5-117

Multi-information display

NOTE

z If fuel is added with the ignition switch or

operation mode in ON, the remaining fuel

display may incorrectly indicate the fuel

level.

Fuel tank filler door mark

5

The arrow (A) indicates that the fuel tank

filler door is located on the left side of the

vehicle. (Refer to “Filling the fuel tank” on

1. Shows the time until the next periodic

page 3-3.)

NOTE

inspection.

z On hills or curves, the display may be incor-

rect due to the movement of fuel in the tank.

Fuel remaining warning display

NOTE

z Shows the distance in units of

100 miles

(100 km) and the time in units of 1 month.

When the fuel level runs low, the information

Service reminder

screen switches to the interrupt display of the

N00556701354

fuel remaining warning display and the mark

2. This informs you that a periodic inspec-

Displays the approximate time until the next

(B) on the fuel remaining display flashes. If

tion is due. Contact an authorized

recommended periodic inspection.

“---” is

the warning display appears, refuel immedi-

Mitsubishi Motors dealer or a repair facil-

displayed when the inspection time has

ately.

ity of your choice to have the system

arrived.

checked.

NOTE

At that time, when the ignition switch is

z The service reminder time can be modified

switched from the “OFF” position to the

by an authorized Mitsubishi Motors dealer,

“ON” position or the operation mode is

to adjust for severe usage, etc. Refer to

changed from OFF to ON, the warning

“Severe maintenance schedule” in your vehi-

display is displayed for a few seconds on

cle’s Warranty and Maintenance Manual. For

the information screen.

further information, please contact your

authorized Mitsubishi Motors dealer.

5-118

Features and controls

Multi-information display

3. After your vehicle is inspected at an

authorized Mitsubishi Motors dealer, it

displays the time until the next periodic

5

inspection.

To reset

2. Press and hold the multi-information

CAUTION

meter switch

(for about

2 seconds or

z

The customer is responsible for making sure

The “---” display can be reset while the igni-

that regular inspections and maintenance and

tion switch or the operation mode is in OFF.

more) to display “

” and make it flash.

periodic inspections and maintenance are

When the display is reset, the time until the

(If there is no operation for about 10 sec-

performed.

next periodic inspection is displayed and the

onds with this indicator flashing, the dis-

Inspections and maintenance must be per-

warning display is no longer displayed when

play returns to the previous screen.)

formed to prevent accidents and malfunc-

the ignition switch is switched from the

tions.

“OFF” position to the “ON” position or the

3. With this indicator flashing, if you lightly

operation mode is changed from OFF to ON.

press the multi-information meter switch,

the screen switches from

“---” to

NOTE

1. When you lightly press the multi-informa-

“CLEAR”. After that, the time until the

z

The “---” display cannot be reset while the

tion meter switch, the information screen

next periodic inspection is shown.

ignition switch or the operation mode is in

switches to the service reminder display

ON.

screen.

z

When “---” is displayed, after a certain dis-

tance and a certain period of time, the dis-

play is reset and the time until the next

periodic inspection is displayed.

z

If you accidentally reset the display, consult

an authorized Mitsubishi Motors dealer for

assistance.

Features and controls

5-119

Multi-information display

Fully apply the parking brake and move

Door ajar warning display

the selector lever into the

“P” (PARK)

screen (With ignition switch or

position.

operation mode is in ON)

2. When you lightly press the multi-informa-

N00555701155

tion meter switch, the information screen

switches to the function setting screen.

Refer to “Information screen (With igni-

tion switch or operation mode in ON)” on

5

page 5-113.

If any of the doors or the liftgate is not com-

pletely closed, this displays the open door or

NOTE

liftgate.

z To return the menu screen to the function set-

If the speed increases to about

5 mph

ting screen, press and hold the multi-infor-

mation meter switch

(for approximately

(8 km/h) or higher with a door ajar, a tone

CAUTION

2 seconds or more).

will sound 4 times to inform you that a door

z For safety, stop the vehicle before operating.

While driving, even if you operate the multi-

z If no operations are made within approxi-

is ajar.

information meter switch, the function set-

mately 15 seconds of the menu screen being

ting screen is not displayed.

displayed, the display returns to the function

CAUTION

setting screen.

z Always make sure that the warning display

3. Press and hold the multi-information

goes out before beginning to drive.

meter switch (for approximately 2 sec-

4. Select the item to change on the menu

onds or more) to switch from the setting

screen and change to the desired setting.

mode screen to the menu screen.

For further details on the operation meth-

Changing the function settings

ods, refer to the following sections.

(With ignition switch or opera-

tion mode is in ON)

Refer to “Changing the reset mode for

N00556801326

average fuel consumption and average

1. Park your vehicle in a safe place.

speed” on page 5-121.

Refer to “Changing the fuel consumption

display unit” on page 5-122.

5-120

Features and controls

Multi-information display

Refer to “Changing the temperature unit”

2. Lightly press the multi-information meter

[Except for vehicles equipped with the

on page 5-123.

switch to select “AVG” (average fuel con-

F.A.S.T.-key]

Refer to “Changing the display language”

sumption and average speed setting).

Turn the ignition switch to the “ON” posi-

on page 5-123.

tion from the “ACC” or “OFF” position.

Refer to

“Operation sound setting” on

page 5-123.

[For vehicles equipped with the F.A.S.T.-

Refer to “Changing the time until “REST

key]

REMINDER” is displayed” on page

Change the operation mode to ON from

ACC or OFF.

5

5-124.

Refer to “Changing the turn signal sound”

on page 5-124.

Auto reset mode

Refer to “Changing the momentary fuel

consumption display” on page 5-125.

z

When the average fuel consumption and

Refer to “Returning to the factory set-

average speed are being displayed, if you

tings” on page 5-125.

hold down the multi-information meter

3. Press and hold the multi-information

switch, these calculations will be reset to

meter switch

(for about

2 seconds or

zero.

Changing the reset mode for aver-

more) to switch in sequence from A or 1

z

When the engine switch or the operation

(Auto reset)  M, 2 or P (Manual reset)

age fuel consumption and average

mode is in the following conditions, the

 A or 1 (Auto reset).

speed

average fuel consumption display and the

The setting is changed to the selected

N00557001282

average speed display will automatically

reset condition.

You can change the mode condition for the

reset.

average fuel consumption and average speed

Manual reset mode

[Except for vehicles equipped with the

display to “Auto reset” or “Manual reset.”

F.A.S.T.-key]

z If you press and hold the multi-informa-

1. Press and hold the multi-information

The ignition switch has been set to the

tion meter switch when the average fuel

meter switch

(for about

2 seconds or

“ACC” or

“OFF” position for about

consumption and average speed are dis-

more) to switch from the setting mode

4 hours or more.

played, these calculations will be reset to

screen to the menu screen.

zero.

[For vehicles equipped with the F.A.S.T.-

Refer to “Changing the function settings

z When the following operation is per-

key]

(With ignition switch or operation mode is

formed, the mode setting changes auto-

The operation mode has been in ACC or

in ON)” on page 5-120.

matically from manual to auto.

OFF for about 4 hours or more.

Features and controls

5-121

Multi-information display

5. Press and hold the multi-information

NOTE

meter switch

(for about

2 seconds or

z Disconnecting the battery cable will erase

more) to change the setting to the selected

from memory the manual reset mode or auto

unit.

reset mode setting for the average speed dis-

play and average fuel consumption display.

z The initial

(default) setting is

“Auto reset

NOTE

mode”.

z The display units for the driving range, the

5

average fuel consumption, the average speed

and the momentary fuel consumption are

Changing the fuel consumption

changed, but the units for the indicating nee-

dle (speedometer), the odometer and the trip

display unit

3. Press and hold the multi-information

odometer will remain unchanged.

N00557101212

meter switch

(for about

2 seconds or

z If the battery is disconnected, the memory of

The fuel consumption display unit can be

the unit setting is erased and is automatically

more) to display “AVG UNIT” (fuel con-

changed. The distance, speed, and amount

set to {mpg (US) or L/100 km}.

sumption display unit setting).

units are also changed to match the selected

4. Lightly press the multi-information meter

fuel consumption unit.

switch to switch in sequence from km/L

The distance and speed units are also changed

 L/100 km  mpg (US)  mpg (UK)

in the following combinations to match the

1. Press and hold the multi-information

 RETURN  km/L.

selected fuel consumption unit.

meter switch

(for about

2 seconds or

more) to change from the setting mode

screen to the menu screen.

Distance

Speed

Fuel

Refer to “Changing the function settings

(driving

(average

economy

(With ignition switch or operation mode is

range)

speed)

in ON)” on page 5-120.

mpg (US)

mile (s)

mph

2. Lightly press the multi-information meter

mpg (UK)

mile (s)

mph

switch to select “AVG UNIT” (fuel con-

sumption display unit setting).

km / L

km

km / h

L / 100 km

km

km / h

5-122

Features and controls

Multi-information display

3. Press and hold the multi-information

Changing the temperature unit

NOTE

meter switch

(for about

2 seconds or

N00557201239

z If the battery is disconnected, the memory of

more) to display

“LANGUAGE” (lan-

The temperature display unit can be switched.

the unit setting is erased and is automatically

guage setting).

set to °F (°C).

4. Lightly press the multi-information meter

1. Press and hold the multi-information

switch to select the desired language.

meter switch

(for about

2 seconds or

5. Press and hold the multi-information

more) to switch from the setting mode

Changing the display language

meter switch

(for about

2 seconds or

screen to the menu screen.

N00557301227

5

more) to change the setting to the selected

Refer to “Changing the function settings

The language of the multi-information dis-

language.

(With ignition switch or operation mode is

play can be changed.

in ON)” on page 5-120.

NOTE

2. Lightly press the multi-information meter

1. Press and hold the multi-information

z If the battery is disconnected, the memory of

meter switch

(for about

2 seconds or

switch to select “

” (temperature unit

the language setting is erased and is automat-

more) to change from the setting mode

setting).

ically set to ENGLISH.

screen to the menu screen.

z If “---” is selected in the language setting, a

Refer to “Changing the function settings

warning message is not displayed when there

(With ignition switch or operation mode is

is a warning display or interrupt display.

in ON)” on page 5-120.

2. Lightly press the multi-information meter

switch to select

“LANGUAGE” (lan-

Operation sound setting

guage setting).

N00557401198

You can turn off the operation sounds of the

multi-information meter switch and rheostat

meter illumination button.

3. Press and hold the multi-information

1. Press and hold the multi-information

meter switch

(for about

2 seconds or

meter switch

(for about

2 seconds or

more) to change in sequence from °F 

more) to switch from the setting mode

°C  °F.

screen to the menu screen.

The setting is changed to the selected tem-

Refer to “Changing the function settings

perature unit.

(With ignition switch or operation mode is

in ON)” on page 5-120.

Features and controls

5-123

Multi-information display

2. Lightly press the multi-information meter

Changing the time until “REST

switch to select

“

” (operation sound

REMINDER” is displayed

setting).

N00557501203

The time until the display appears can be

changed.

1. Press and hold the multi-information

5

meter switch

(for about

2 seconds or

more) to switch from the setting mode

screen to the menu screen.

Refer to “Changing the function settings

4. Lightly press the multi-information meter

(With ignition switch or operation mode is

switch to select the time until the display

in ON)” on page 5-120.

appears.

2. Lightly press the multi-information meter

5. Press and hold the multi-information

3. Press and hold the multi-information

switch to select “ALARM” (rest time set-

meter switch

(for about

2 seconds or

meter switch

(for about

2 seconds or

ting).

more) to change the setting to the selected

more) to switch in sequence from ON

time.

(operation sound on)  OFF (operation

sound off)  ON (operation sound on).

NOTE

The setting is changed to the selected con-

dition.

z If the battery is disconnected, the memory of

the unit setting is erased and is automatically

set to the “OFF”.

NOTE

z The drive time is reset when the ignition

z If the battery is disconnected, the memory of

switch is in the “OFF” position or the opera-

the operation sound setting is erased and is

tion mode is in OFF.

automatically set to “ON” (operation sound

on).

z The operation sound setting only deactivates

3. Press

and hold the multi-information

Changing the turn signal sound

the operation sound of the multi-information

meter

switch

(for about

2 seconds or

N00563501123

meter switch and rheostat meter illumination

button. The warning display and other

more)

to display

“ALARM” (rest time

It is possible to change the turn signal sound.

sounds cannot be deactivated.

setting).

5-124

Features and controls

Multi-information display

1. Press and hold the multi-information

3. Press and hold the multi-information

Changing the momentary fuel con-

meter switch for about 2 seconds or more

meter switch for about 2 seconds or more

sumption display

to switch from the setting mode screen to

to switch in sequence from ON (with the

N00563601065

the menu screen.

green bar graph)

 OFF (without the

Refer to “Changing the function settings

It is possible to change the bar graph setting

green bar graph)  ON (with the green

(With ignition switch or operation mode is

of the momentary fuel consumption display.

bar graph).

in ON)” on page 5-120.

The setting changes to the selected bar

1. Press and hold the multi-information

2. Lightly press the multi-information meter

graph setting.

meter switch for about 2 seconds or more

5

switch to select

(changing the turn

to switch from the setting mode screen to

signal sound)

Returning to the factory settings

the menu screen.

N00557601259

Refer to “Changing the function settings

(With ignition switch or operation mode is

All of the function settings can be returned to

in ON)” on page 5-120.

their factory settings.

2. Lightly press the multi-information meter

1. Press and hold the multi-information

switch to select

(changing the

meter switch

(for about

2 seconds or

momentary fuel consumption display)

more) to switch from the setting mode

screen to the menu screen.

Refer to “Changing the function settings

(With ignition switch or operation mode is

in ON)” on page 5-120.

3. Press and hold the multi-information

2. Lightly press the multi-information meter

meter switch for about 2 seconds or more

switch to select “RESET” (return to the

to switch in sequence from 1 (turn signal

factory settings).

sound 1)  2 (turn signal sound 2)  1

(turn signal sound 1).

The setting changes to the selected turn-

signal sound.

Features and controls

5-125

Multi-information display

NOTE

• Momentary fuel consumption with the

green bar graph: ON

5

3. Press and hold the multi-information

meter switch

(for about

5 seconds or

more), the buzzer sounds and all of the

function settings are returned to the fac-

tory settings.

NOTE

z The factory settings are as follows.

• Average fuel consumption and average

speed reset mode: A (Auto reset)

• Fuel consumption display unit: mpg (US)

or (L/100 km)

• Temperature unit:

°F (Fahrenheit) or

°C

(Celsius)

• Display language: ENGLISH

• Cooperative language setting: A

• Operation sounds: ON

(Operation sound

on)

• “REST REMINDER” display: OFF

• Turn signal sound: Turn signal sound 1

5-126

Features and controls

Indicator light, warning light, and information screen display list

Indicator light, warning light, and information screen display list

N00557700048

Indicator and warning light list

N00557801466

Type 1

Type 2

5

1- Position indicator  P.5-144

7- Forward Collision Mitigation system

13- Automatic High Beam (AHB) indicator

2- High beam indicator  P.5-144

(FCM) indicator (if so equipped) 

(if so equipped)  P.5-151

3- Charging system warning light



P.5-83

14- Engine malfunction indicator

(“SER-

P.5-146

8- Tire pressure monitoring system warn-

VICE ENGINE SOON” or “Check

4- Turn signal indicator/hazard warning

ing light  P.5-101

engine light”)  P.5-145

light  P.5-144

9- Brake warning light  P.5-145

15- Active stability control

(ASC) OFF

5- Front fog light indicator

(if so

10- Cruise control indicator  P.5-76

indicator  P.5-74

equipped)  P.5-144

11- Seat belt reminder/warning light



16- Active stability control (ASC) indicator

6- Forward Collision Mitigation system

P.4-15

 P.5-74

(FCM) OFF indicator (if so equipped)

12- Supplemental Restraint System (SRS)

17- Information screen display list



 P.5-83

warning light  P.4-34

P.5-128

Features and controls

5-127

Indicator light, warning light, and information screen display list

18- Anti-lock braking system warning light

 P.5-70

Information screen display list

N00557900082

When there is information to be announced, such as light reminder, the tone sounds and the screen switches to the displays shown below. Refer to

the appropriate page and take the necessary measures.

5

When the cause of the warning display is eliminated, the warning display goes out automatically.

Refer to “Warning display list (With ignition switch or operation mode is in OFF)” on page 5-128.

Refer to “Warning display list (With ignition switch or operation mode is in ON)” on page 5-132.

Refer to “Other interrupt displays” on page 5-141.

NOTE

z In the following cases, a warning may be displayed on the information screen and the buzzer may sound for a few seconds, at times.

This is caused by the system picking up interference such as strong electromagnetic waves or noise, and is not a functional problem.

• An extremely strong electromagnetic wave is received from a source such as an illegal radio set, a spark from a wire, or a radar station.

• Abnormal voltage or a static electricity discharge is generated by the operation of your vehicle’s electronics (including after-market parts).

If the warning display has occurred a number of times, take your vehicle to an authorized Mitsubishi Motors dealer or a repair facility of your choice and

have the system checked.

Warning display list (With ignition switch or operation mode is in OFF)

N00558001449

Screen

Cause

Do this (Reference)

z You have forgotten to remove the key from the ignition

z Remove the key.

switch.

Refer to “Key reminder system” on page 5-35.

5-128

Features and controls

Indicator light, warning light, and information screen display list

Screen

Cause

Do this (Reference)

z You have forgotten to turn off the lights.

Refer to “Light auto-cutout function (headlights and other

lights)” on page 5-149.

z The theft-alarm system is operating.

Refer to “Theft-alarm system” on page 5-39.

5

z The system has received the customer key program-

Refer to “Customer key programming (Except for vehi-

ming request correctly and is currently processing the

cles sold in Canada)” on page 5-5.

registration request.

Refer to “Customer F.A.S.T.-key programming (Except

for vehicles sold in Canada)” on page 5-26.

Features and controls

5-129

Indicator light, warning light, and information screen display list

Screen

Cause

Do this (Reference)

z There is a fault in the F. A. S. T. -key.

Refer to “Free-hand Advanced Security Transmitter

(F.A.S.T.-key)” on page 5-14.

5

z There is a fault in the electronic immobilizer. (Anti-

z Contact an authorized Mitsubishi Motors dealer or a

theft starting system).

repair facility of your choice to have the system

checked.

5-130

Features and controls

Indicator light, warning light, and information screen display list

Screen

Cause

Do this (Reference)

z The F. A. S. T. -key is not detected.

z Insert the F. A. S. T. -key into the key slot in the glove

compartment. Refer to “If the F. A. S. T. -key is not

operating properly” on page 5-24.

z You have forgotten to remove the F. A. S. T. -key from

z Remove the F. A. S. T. -key from the key slot in the

the key slot in the glove compartment.

glove compartment.

5

z The engine switch is pressed to stop the engine while

z Place the selector lever in the “P” (PARK) position to

the selector lever is in a position other than the “P”

put the operation mode in OFF.

(PARK) position.

z There is a fault in the electrical system.

z Park your vehicle in a safe place immediately and con-

tact an authorized Mitsubishi Motors dealer or a repair

facility of your choice to have the system checked.

Features and controls

5-131

Indicator light, warning light, and information screen display list

Warning display list (With ignition switch or operation mode is in ON)

N00558101437

Screen

Cause

Do this (Reference)

z The washer fluid is running low.

z Replenish the container with washer fluid.

Refer to “Washer fluid” on page 9-9.

Refer to “Capacity” on page 11-5.

5

(if so equipped)

z There is a fault in the EPS.

z Have the vehicle inspected by an authorized

Mitsubishi Motors dealer or a repair facility of your

choice as soon as possible.

Refer to “Electric power steering system (EPS)” on

page 5-72.

5-132

Features and controls

Content      ..     7      8      9      10     ..
