NOTE

•

The key switch is operated at the correct
distance from the vehicle, but the doors
are not locked/unlocked in response.

•

The indication lamp (3) is dim or does not
come on.

For further information, please contact a
MITSUBISHI MOTORS Authorized
Service Point.
If you replace the battery yourself, refer to
“Procedure for replacing the key battery”
on page 3-06.

If your key is lost or damaged, please con-
tact a MITSUBISHI MOTORS Authorized
Service Point for a replacement key.

If you wish to add key, please contact a
MITSUBISHI MOTORS Authorized Serv-
ice Point.
The following numbers of the keys are avail-
able.

•

Keyless entry key: up to 4 keys.

•

Keyless operation key: up to 4 keys.

Procedure for replacing the

key battery

E00309501849

Before replacing the battery, remove static
electricity from your body by touching a met-
al grounded object.

WARNING

Danger of explosion if battery is incor-
rectly replaced.
Replace only with the same battery or an
equivalent type.

CAUTION

When the key case is opened, be careful to
keep water, dust, etc. out. Also, do not touch
the internal components.

NOTE

You may purchase a replacement battery at
an electric appliance store.

A MITSUBISHI MOTORS Authorized
Service Point can replace the battery for you
if you prefer.

1. Remove the screw (A) from the key.

(Keyless entry key only)

Keyless entry key

2. Remove the emergency key from the

key. (Keyless operation key only)
Refer to “Emergency key” on page
3-11.

3. With the MITSUBISHI mark facing

you, insert the cloth-covered tip of a
straight blade (or minus) screwdriver in-
to the notch in the key case and use it to
open the case.

Keyless entry key

Keyless operation key

Keyless entry system*

3-06

OKTE18E1

Locking and unlocking

NOTE

Be  sure  to  perform  the  procedure  with  the
MITSUBISHI  mark  facing  you.  If  the
MITSUBISHI  mark  is  not  facing  you  when
you  open  the  key  case,  the  switches  may
come out.

4. Remove the old battery.
5. Install a new battery with the + side (B)

up.

Keyless entry key

+ side

- side

Coin type
battery
CR1620

Keyless operation key

+ side

- side

Coin type
battery
CR2032

6. Close the key case firmly.
7. Attach the screw (A) removed in step 1.

(Keyless entry key only)

8. Install the emergency key removed in

step 2. (Keyless operation key only)

9. Check the keyless entry system to see

that it works.

Keyless operation system*

E00305602230

The  keyless  operation  system  allows  you  to
lock  and  unlock  the  doors,  start  the  engine
and  change  the  operation  mode  simply  by
carrying the keyless operation key with you.
The  switches  on  the  keyless  operation  key
can also be used as the key switch of keyless
entry system.
Refer  to  “Starting  and  stopping  the  engine”
on page 6-18.
Refer  to  “Keyless  entry  system*”  on  page
3-04.

The  driver  should  always  carry  the  keyless
operation key. This key is necessary for lock-
ing and unlocking the doors, starting the en-
gine  and  otherwise  operating  the  vehicle,  so
before  locking  and  leaving  the  vehicle,  be
sure to check that you have the keyless oper-
ation key.

WARNING

People  with  implantable  cardiac  pace-
makers or implantable cardiovascular-de-
fibrillators should not go near the exterior
transmitters  (A)  or  the  interior  transmit-
ters (B). The radio waves used by the key-
less  operation  system  could  adversely  af-
fect  implantable  cardiac  pacemakers  or
implantable cardiovascular-defibrillators.

Club cab

Keyless operation system*

3-07

OKTE18E1

Locking and unlocking

Double cab

WARNING

When using electro-medical devices other
than  implantable  cardiac  pacemakers  or
implantable  cardiovascular-defibrillators,
contact  the  electro-medical  device  manu-
facturer  ahead  of  time  to  determine  the
affects of radio waves on the devices. Elec-
tro-medical device operations could be af-
fected by radio waves.

You  can  limit  the  possible  operations  of  the
keyless  operation  system  in  the  following
ways.  (The  keyless  operation  system  can  be
used  as  a  keyless  entry  system.)  Please  con-
sult  a  MITSUBISHI  MOTORS  Authorized
Service Point.

You can limit operations to locking and
unlocking the doors.

You can limit operations to starting the
engine.

The keyless operation system can be dis-
abled.

When keyless operation system operations
are modified, the operating transmitters are as
follows.

Only locking and unlocking doors: exte-
rior transmitter and interior transmitter

Only starting the engine: interior trans-
mitter

NOTE

The keyless operation key uses an ultra-
weak electromagnetic wave. In the following
cases, the keyless operation system may not
operate properly or may be unstable.

•

When there is equipment nearby that
emits strong radio waves, such as: a pow-
er station, a radio/TV broadcasting station
or an airport.

•

The  keyless  operation  system  is  carried
together  with  a  communications  device
such  as  a  cellular  phone  or  radio  set,  or
with  an  electronic  device  such  as  a  per-
sonal computer.

•

The keyless operation key is touching or
covered by a metal object.

•

A keyless entry system is being used
nearby.

•

When the keyless operation key battery is
worn out.

NOTE

•

When the keyless operation key is placed
in  an  area  with  strong  radio  waves  or
noise.
In such cases, use the emergency key.
Refer  to  “To  lock/unlock  without  using
the  keyless  operation  function”  on  page
3-11.

Because  the  keyless  operation  key  receives
signals  in  order  to  communicate  with  the
transmitters  in  the  vehicle,  the  battery  con-
tinually  wears  down  regardless  of  keyless
operation key use. The battery life is 1 to 2
years, depending on usage conditions. When
the battery wears out, replace the battery ac-
cording  to  the  description  in  this  manual  or
have  it  replaced  a  MITSUBISHI  MOTORS
Authorized Service Point.
Refer  to  “Procedure  for  replacing  the  key
battery” on page 3-06.

Because the keyless operation key continual-
ly receives signals, strong radio wave recep-
tion could affect battery wear. Do not leave
the key near a TV, personal computer, or
other electronic device.

Operating range of the keyless

operation system

E00305701609

If you are carrying the keyless operation key,
enter the operating range of the keyless oper-
ation system, and press the driver’s or front
passenger’s door lock/unlock switch, the ID
code for your key is verified.

Keyless operation system*

3-08

OKTE18E1

Locking and unlocking

You can lock and unlock the doors, start the
engine and change the operation mode only if
the ID codes of your keyless operation key
and the vehicle match.

NOTE

If the keyless operation key battery is wear-
ing out or there are strong electromagnetic
waves or noise present, the operating range
may become smaller and operation may be-
come unstable.

Operating range for locking
and unlocking the doors

E00306201568

The operating range is approximately 70 cm
from the driver’s or front passenger’s door
lock/unlock switch.

* : Forward direction

: Operating range

NOTE

Locking and unlocking operates only when
you press a door switch that detects the key-
less operation key.

Operation may not be possible if you are too
close to the front door, door window.

Even  if  the  keyless  operation  key  is  within
70  cm  of  the  driver’s  or  front  passenger’s
door lock/unlock switch, if the key is near to
the  ground  or  high  up,  the  system  may  not
operate.

If the keyless operation key is within the op-
erating range, even someone not carrying the
key can lock and unlock the doors by press-
ing the driver’s or front passenger’s door
lock/unlock switch.

Operating range for starting the
engine and changing the opera-
tion mode

E00306301338

The operating range is the interior of the ve-
hicle.

*: Forward direction

: Operating range

NOTE

Even if it is within the operating range, if the
keyless  operation  key  is  in  a  small  item
holder  such  as  the  glove  box,  on  top  of  the
instrument panel, door pocket or in the lug-
gage  compartment,  it  may  be  impossible  to
start  the  engine  and  change  the  operation
mode.

Keyless operation system*

3-09

OKTE18E1

Locking and unlocking

NOTE

If a keyless operation key is too close to the
door or door window, it may be possible to
start the engine or change the operation
mode even when the key is outside the vehi-
cle.

To operate using the keyless

operation function

E00305802173

Locking the doors

When you are carrying the keyless operation
key, if you press the driver’s or front passen-
ger’s door lock/unlock switch (A), within the
operating range, the doors are locked.
The turn-signal lamps will blink once.
Also refer to “Locking and unlocking: Doors,
Central door locks” on pages 3-15, and
3-17.

Unlocking the doors

When you are carrying the keyless operation
key, if you press the driver’s or front passen-
ger’s door lock/unlock switch (A), within the
operating range, all the doors are unlocked.
If  the  room  lamp  switch  is  in  the  middle  (•)
position at this time, the room lamp will turn
on for 15 seconds. The turn-signal lamps will
blink twice.
If the driver’s or front passenger’s door lock/
unlock switch is pressed and any of the doors
is  not  opened  within  approximately  30  sec-
onds, relocking will automatically occur.
Refer  to  “Locking  and  unlocking:  Doors,
Central  door  locks”  on  pages  3-15,  and
3-17.

NOTE

For vehicles equipped with the mirror retrac-
tor switch, the outside rear-view mirrors au-
tomatically retract/extend when all the doors
are locked/unlocked using the keyless opera-
tion function. Refer to “Starting and driving:
Outside rear-view mirrors” on page 6-09.

For  vehicles  equipped  with  the  Dead  Lock
System,  pressing  the  driver’s  or  front  pas-
senger’s  door  lock/unlock  switch  (A)  two
times  in  succession  causes  the  Dead  Lock
System to be set. (Refer to “Setting the sys-
tem” on page 3-18.)

The keyless operation function does not op-
erate under the following conditions:

NOTE

•

The keyless operation key is inside the
vehicle.

•

A door is open or ajar.

•

The operation mode is not in OFF.

The  time  between  unlocking  and  automatic
locking  can  be  adjusted.  Please  consult  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

Operation confirmation when locking and
unlocking
Operation can be confirmed as shown below.
However, the room lamp will illuminate only
if the room lamp switch is in the middle (•)
position.

When locking:

The turn-signal
lamps will blink
once.

When unlocking:

The room lamp illu-
minates for approxi-
mately 15 seconds,
the turn-signal lamps
blink twice.

NOTE

Functions can be modified as stated below.
For further information, please contact a

Keyless operation system*

3-10

OKTE18E1

Locking and unlocking

NOTE

MITSUBISHI MOTORS Authorized Serv-
ice Point.

•

Activating  the  operation  confirmation
function  (blinking  of  the  turn-signal
lamps)  only  during  locking,  or  only  dur-
ing unlocking.

•

Disabling the operation confirmation
function (blinking of the turn-signal
lamps).

•

Changing the number of blinks for the op-
eration confirmation function (blinking of
the turn-signal lamps).

To lock/unlock without using

the keyless operation function

E00306000165

Emergency key

E00307201581

The emergency key (A) can only be used to
lock and unlock the door. To use the emer-
gency key, unlock the lock knob (B) and re-
move it from the keyless operation key (C).

NOTE

Only  use  the  emergency  key  for  emergen-
cies.  If  the  keyless  operation  key  battery
wears  out,  replace  it  as  quickly  as  possible
so  that  you  can  use  the  keyless  operation
key.

The emergency key is built in the keyless
operation key.

After using the emergency key, always re-
turn it into the original position.

Locking and unlocking the door
Turning the emergency key in the forward di-
rection locks the door, and turning it in the
rear direction unlocks the door. Also refer to
“Locking and unlocking: Doors” on page
3-15.

1- Lock
2- Unlock

Operation of the Dead Lock
System

E00313900023

For  vehicles  equipped  with  the  Dead  Lock
System,  it  is  possible  to  set  the  Dead  Lock
System  using  the  driver’s  or  front  passen-
ger’s door lock/unlock switch.
(Refer  to  “Dead  Lock  System*”  on  page
3-18.)

Keyless operation system*

3-11

OKTE18E1

Locking and unlocking

Warning activation

E00305902031

In order to prevent vehicle theft or the accidental operation of the keyless operation system, the lamp and buzzer are used to alert the driver.

Lamp

Buzzer

Item

Cause

Note (Solution)

Blinks.

Outer buzzer sounds
4 times. Inner buzzer
sounds.

Keyless operation key
take-out monitoring
system

When the vehicle is parked with the opera-
tion mode in any mode other than OFF, if
you close the door after opening any of the
doors and taking the keyless operation key
out of the vehicle.
Outer buzzer sounds 4 times at this time.
And when a vehicle starts, inner buzzer
sounds once.

If  you  take  the  keyless  opera-
tion  key  out  of  the  vehicle
through  a  window  without
opening  a  door,  this  system
does not operate.

It is possible to change the set-
ting to make the system operate
if  you  take  the  keyless  opera-
tion  key  out  from  the  vehicle
through  a  window  without
opening a door. For further in-
formation,  please  contact  a
MITSUBISHI  MOTORS  Au-
thorized Service Point.

Even  if  you  have  the  keyless
operation key within the engine
start operating range, if the key
and vehicle ID codes cannot be
matched,  for  example  due  to
the  ambient  environment  or
electromagnetic conditions, the
warning may be activated.

Keyless operation system*

3-12

OKTE18E1

Locking and unlocking

Lamp

Buzzer

Item

Cause

Note (Solution)

Blinks.

Outer buzzer sounds
approximately 3 sec-
onds

Key lock-in preven-
tion system

When the operation mode is in OFF, if you
close all the doors with the keyless opera-
tion key left in the vehicle and you try to
lock the doors by pressing the driver’s or
front passenger’s door lock/unlock switch.

Make sure you have the keyless op-
eration key with you before locking
the  doors.  Even  if  you  leave  the
keyless operation key inside the ve-
hicle,  it  is  possible  that  the  doors
will  lock  depending  on  the  sur-
rounding  environment  and  wireless
signal conditions.

Blinks.

Outer buzzer sounds
approximately 3 sec-
onds

Door ajar prevention
system

When the operation mode is in OFF, if you
try to lock the doors by pressing the driv-
er’s or front passenger’s door lock/unlock
switch with one of the doors not complete-
ly closed.

—

Blinks.

No sounds

Keyless operation sys-
tem

The battery in the keyless operation key
has worn out.

Replace the battery as soon as pos-
sible at a MITSUBISHI MOTORS
Authorized Service Point.

Illuminates.

A power supply is not switched over from
OFF  because  the  keyless  operation  key  in
the vehicle cannot be detected.
When  a  warning  is  issued  while  being  in
the vehicle, it is because the battery of the
keyless  operation  key  has  worn  out  or  the
state of the surrounding radio wave is bad.

Please  confirm  that  the  keyless  op-
eration key is in the vehicle.
If the key is in the vehicle, insert the
slot.
Starting  the  engine  and  changing
the  operation  mode  should  now  be
possible.

Keyless operation system*

3-13

OKTE18E1

Locking and unlocking

Lamp

Buzzer

Item

Cause

Note (Solution)

There is a fault in the keyless operation sys-
tem.

If the warning lamp illuminates,
please contact a MITSUBISHI
MOTORS

Authorized

Service

Point.

Immediately stop the vehicle in a
safe

place

and

contact

MITSUBISHI MOTORS Authorized
Service Point.

Inner buzzer sounds
(intermittent sounds)

There is a fault in the electrical system.

Inner buzzer sounds
(continuous sounds).

Blinks.

Outer  buzzer  sounds
approximately  3  sec-
onds.  Inner  buzzer
sounds  approximately
1 minute.

Keyless operation key
reminder.

When the operation mode is in OFF with
the keyless operation key left in the key
slot, if you try to open the driver’s door.

Remove the keyless operation key
from the key slot.
Refer to “Starting and stopping the
engine” on page 6-18.

Illuminates.

Inner buzzer sounds.

Steering wheel lock.

There is a fault in the steering wheel lock
system.

Refer to “Steering wheel lock” on
page 6-16.

Blinks.

Outer buzzer sounds
approximately 3 sec-
onds.

Operation mode OFF
reminder system.

When  the  operation  mode  is  in  any  mode
other  than  OFF  with  all  the  doors  are
closed, if you try to lock by using the driv-
er’s  or  front  passenger’s  door  lock/unlock
switch.

Refer to “Operation mode OFF re-
minder system” on page 6-16.

Keyless operation system*

3-14

OKTE18E1

Locking and unlocking

Lamp

Buzzer

Item

Cause

Note (Solution)

Illuminates.

No sounds.

Immobilizer system.

There is a fault in the electronic immobiliz-
er (Anti-theft starting system).

Put the operation mode in OFF and
then  start  the  engine  again.  If  the
warning  is  not  cancelled,  contact  a
MITSUBISHI  MOTORS  Author-
ized Service Point.

Blinks.

Inner buzzer sounds. Steering wheel lock.

Steering wheel does not unlock.

Unlock the steering wheel lock fol-
lowing the procedure of reference
page.
Refer to “Steering wheel lock” on
page 6-16.

Illuminates.

No sounds.

Steering wheel lock is abnormal.

Refer to “Steering wheel lock” on
page 6-16.

Doors

E00300403605

CAUTION

Make sure the doors are closed: driving with
doors not completely closed is dangerous.

Never leave children in the vehicle unatten-
ded.

Be careful not to lock the doors while the
key is inside the vehicle.

NOTE

To prevent the key from being locked inside
the vehicle, neither the lock knob on the
driver’s door nor the key can be used to lock
the driver’s door when it is open.

To lock or unlock with the key

1- Lock

Doors

3-15

OKTE18E1

Locking and unlocking

2- Unlock

NOTE

On vehicles with central door locks, when
locking or unlocking with the key, all doors
will be locked or unlocked.
Refer to “Central door locks” on page 3-17.

If the vehicle is equipped with the keyless
operation system, the driver’s door can be
locked or unlocked with the emergency key.
Refer to “Emergency key” on page 3-11.

To lock or unlock from inside

the vehicle

1- Lock
2- Unlock

NOTE

The driver’s door can be opened without us-
ing the lock knob by pulling on the inside
door handle.
On vehicles with central door locks, all other
doors are unlocked at the same time.

In a vehicle that has a Dead Lock System, it
is not possible to unlock the door by pushing
the lock knob to the unlock side while the
Dead Lock System is set.
(Refer to “Dead Lock System*” on page
3-18.)

To lock without using the key

Set the inside lock knob (1) to the locked po-
sition, and close the door (2).

NOTE

The driver’s door cannot be locked using the
inside lock knob while the driver’s door is
opened.

To open or close the rear door

(Club cab)

E00313800048

You can open or close the rear door while the
front door is opened.

1. Open the front door wide.
2. Pull the door handle (A) of the rear door.

3. Open the rear door.
4. When closing these doors, close the

front door after closing the rear door.

Doors

3-16

OKTE18E1

Locking and unlocking

WARNING

When opening the rear door, confirm that
the  occupant  of  the  front  seat  has  taken
off  the  seat  belt  before  opening  the  rear
door.
If  you  open  the  rear  door  with  the  front
seat  belt  being  worn,  the  occupant  of  the
front  seat  may  be  tightened  with  the
locked seat belt and could result in serious
injury.

When closing the rear door, make sure
not being trapped your hands or your fin-
gers in the doors.

Before  driving,  make  sure  that  the  rear
door is securely closed.
If  a  door  is  ajar,  the  door  ajar  warning
lamp  will  illuminates.  If  a  door  is  not
completely  closed,  the  rear  door  could
open  while  driving  and  this  could  cause
an  accident  such  as  occupants  being
thrown from the vehicle.

CAUTION

When opening or closing the rear door,
please observe the followings. If you do not
follow them, it could result in damage to
your vehicle.

•

Do not open or close the rear door when
the front door is not completely opened.

•

Do not open or close the rear door and the
front door at the same time.

•

Do not close the rear door after closing
the front door.

Central door locks

E00300803306

NOTE

Repeated continuous operation between lock
and  unlock  could  activate  the  central  door
locking  systems  built-in  protection  circuit
and  prevent  the  system  from  operating.  If
this occurs, wait approximately 1 minute be-
fore operating the central door lock system.

All of the doors can be locked and unlocked
as described hereafter.

Driver’s door with key

Using the key on the driver’s door locks or
unlocks.

1. Lock
2. Unlock

NOTE

If the vehicle is equipped with the keyless
operation system, the driver’s door can be
locked or unlocked with the emergency key.
Refer to “Emergency key” on page 3-11

Driver’s door with inside lock

knob

Using the door lock knob on the driver’s door
locks or unlocks all doors.

1. Lock
2. Unlock

NOTE

Be careful not to lock the doors while the
key is inside the vehicle when getting off the
vehicle.

Central door locks

3-17

OKTE18E1

Locking and unlocking

Vehicle-speed sensitive auto-

matic door lock (with impact-

sensitive unlock mechanism)

All of the doors lock automatically when the
vehicle

speed

exceeds

approximately

15 km/h (9 mph). In addition, all of the doors
unlock when a strong impact that could be
very dangerous to the occupants is sustained
by the collision of the vehicle. This is pre-
pared for rescue activities when an unexpec-
ted accident occurs.

WARNING

When the vehicle-speed sensitive automat-
ic door lock/impact-sensitive unlock
mechanism may not operate in the follow-
ing conditions, have the vehicle inspected
at a MITSUBISHI MOTORS Authorized
Service Point immediately.

•

The door does not lock automatically
even when the vehicle speed exceeds ap-
proximately 15 km/h (9 mph).

•

The door unlocks automatically while
driving.

•

Even  when  the  ignition  switch  or  the
operation  mode  is  in  ON,  the  SRS
warning  lamp  does  not  come  on  or  it
remains on.

•

The SRS warning lamp comes on while
driving.

•

The central door lock system is broken
down.

NOTE

Even if the vehicle suffers significant defor-
mation  from  a  collision  etc.,  depending  on
the  location  and  angle  of  the  collision,  as
well  as  on  the  shape  and  condition  of  the
other  object  in  the  collision,  the  doors  may
not  unlock.  The  extent  of  deformation  or
damage  to  the  vehicle  does  not  necessarily
correlate with unlocking of the doors.

These functions are activated when the vehi-
cle is shipped from the factory. If you wish
to activate or deactivate these functions,
please contact a MITSUBISHI MOTORS
Authorized Service Point.

Unlocking by using the ignition

switch, the engine switch or the

selector lever

It is possible to unlock all of the doors when-
ever as follows.
[Vehicles with M/T]
The ignition switch is turned to the “LOCK”
position or the operation mode is put in OFF.
[Vehicles with A/T]
The selector lever is placed in the “P”
(PARK) position while the operation mode is
in ON. Or the operation mode is put in OFF.

These functions are deactivated when the ve-
hicle is shipped from the factory. If you wish
to activate or deactivate these functions,
please contact a MITSUBISHI MOTORS
Authorized Service Point.

Dead Lock System*

E00305101209

The  Dead  Lock  System  helps  prevent  theft.
When the keyless entry system or the keyless
operation  function  has  been  used  to  lock  all
of the doors, the Dead Lock System makes it
impossible  to  unlock  the  doors  using  the  in-
side lock knobs.

CAUTION

Do  not  set  the  Dead  Lock  System  when
someone is inside the vehicle. With the Dead
Lock System set, it is not possible to unlock
the doors using the inside lock knobs. If you
erroneously  set  the  Dead  Lock  System,  un-
lock  the  doors  using  the  UNLOCK  switch
on  the  key  or  using  the  keyless  operation
function.

Setting the system

E00305201314

1. Turn the ignition switch to the “LOCK”

position and then remove the key (vehi-
cles with keyless entry system), or put
the operation mode in OFF (vehicles
with keyless operation system).

Dead Lock System*

3-18

OKTE18E1

Locking and unlocking

2. Get out of the vehicle. Close all of the

doors.

3. Press the LOCK switch (A) on the key,

the driver’s or front passenger’s door
lock/unlock switch (C) to lock all of the
doors. The turn-signal lamps will blink
once.

4. Press the switch again within 2 seconds.

The turn-signal lamps will blink three
times to show that the Dead Lock Sys-
tem has been set.

Keyless entry system

Keyless operation
system

NOTE

Pressing  the  LOCK  switch  (A)  on  the  key
once while the Dead Lock System is set cau-
ses  the  turn-signal  lamps  to  blink  three
times,  so  it  is  possible  to  confirm  that  the
Dead Lock System is set.

Cancelling the system

E00305301458

When the following operation is performed,
the doors will unlock and the Dead Lock Sys-
tem will be simultaneously cancelled.

The UNLOCK switch (B) on the key is
pressed.

The  driver’s  or  front  passenger’s  door
lock/unlock  switch  (C)  is  pressed  while
you  are  carrying  the  keyless  operation
key.

NOTE

If a door is opened within 30 seconds of un-
locking, the doors are automatically relocked
and the Dead Lock System is simultaneously
set again.

Even when it is not possible to use the key-
less entry system or keyless operation func-
tion to unlock the doors, it is possible to use
the  key  to  unlock  the  driver’s  door.  When
the  key  is  used  to  unlock  the  driver’s  door,
the Dead Lock System is cancelled for only
the driver’s door. If you wish to subsequent-
ly  unlock  all  other  doors,  turn  the  ignition
switch  to  the  “ON”  or  “ACC”  position,  or
put the operation mode in ON or ACC.

It  is  possible  to  adjust  the  time  between
pressing  the  UNLOCK  switch  (B)  on  the
key or the driver’s or front passenger’s door
lock/unlock  switch  (C)  and  automatic  lock-
ing.  For  details,  please  contact  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

It  is  possible  to  lock  the  doors  and  set  the
Dead  Lock  System  at  the  same  time  with  a
single push of the LOCK switch (A) on the
key,  the  driver’s  or  front  passenger’s  door
lock/unlock  switch  (C).  For  details,  please
contact  a  MITSUBISHI  MOTORS  Author-
ized Service Point.

Testing the system

E00305400159

Open all of the door windows, then set the
Dead Lock System.
(Refer to “Setting the system” on page 3-18.)

Dead Lock System*

3-19

OKTE18E1

Locking and unlocking

After  setting  the  Dead  Lock  System,  reach
into  the  vehicle  through  a  window  and  con-
firm  that  you  cannot  unlock  the  doors  using
the lock knobs.

NOTE

If you need advice on how to set the Dead
Lock System, please contact a MITSUBISHI
MOTORS Authorized Service Point.

“Child-protection” rear
doors (Double cab)

E00300902209

1- Lock
2- Unlock

Child protection helps prevent doors from be-
ing opened accidentally, especially when
small children are in the rear seat.

A lever is provided on each rear door.
If  the  lever  is  set  to  the  locked  position,  the
rear  door  cannot  be  opened  using  the  inside
handle.
To open the rear door while the child protec-
tion is in use, pull the outside door handle.
If  the  lever  is  set  to  the  “Unlock”  position,
the  child  protection  mechanism  does  not
function.

CAUTION

When driving with a child in the rear seat,
please use the child protection to prevent ac-
cidental door opening which may cause an
accident.

Rear gate

E00303001129

CAUTION

Do not stand behind the exhaust pipe when
loading and unloading luggage. Heat from
the exhaust could lead to burns.

Pay attention not to catch your fingers in the
rear gate.

Do not weight the rear gate.

Before driving, make sure that the rear gate
is securely closed. If the rear gate opens
while driving the vehicle, objects stored in
the cargo area could fall out onto the road.

To open

Lift up the handle and lower the rear gate.

To close

Raise the rear gate and close with enough
force to latch the assembly securely into posi-
tion.

“Child-protection” rear doors (Double cab)

3-20

OKTE18E1

Locking and unlocking

To swing down

The rear gate can be swung down in two
stages except some models. To lower it to the
second stage, proceed as follows:

CAUTION

On vehicles with the rear bumper, never
swing down the rear gate because the rear
gate could be damaged.

1. Swing open the rear gate to the first po-

sition. Then, lift it up to the position
shown in the illustration while holding
the wire (A).

2. Remove the wire (A) on one side while

aligning the hole in the wire with the
hook (B).

3. Remove the wire on the other side in the

same manner, and have the rear gate
swing down slowly.

CAUTION

Never close the rear gate with the wire left
unhooked.

Manual window control*

E00302101107

1- To open
2- To close

Electric window control*

E00302201661

The electric windows can only be operated
with the ignition switch or the operation
mode in ON.

Manual window control*

3-21

OKTE18E1

Locking and unlocking

Content .. 1 2 3 4 ..
