Mitsubishi Outlander XL. Manual - part 831

Item No.

Check items

Check
conditions

Normal conditions

36

Threshold of PRS. warning

The

 tire

pressure

 is

within

 the

specified  value
range.

OFF

The

 tire

pressure  is  not
within

 the

specified  value
range.

ON

37

Threshold  of  PRS.  warning
release

The

 tire

pressure

 is

within

 the

specified  value
range.

ON

The

 tire

pressure  is  not
within

 the

specified  value
range.

OFF

38

Number of registered TPMS ID

-

Number of stored TPMS

41

VSS

Drive

 the

vehicle

The  scan  tool  and  the  tachometer
readings are approximately the same

CHECK AT ECU TERMINALS

M14209200046USA0000010000

ZC603896

C-29

0001

Terminal
No.

Check items

Check conditions

Normal conditions

1 - 5

-

-

-

6

Power supply (Battery)

Always

Battery voltage

7

Ground

Always

0 V

8

-

-

-

9

Power supply (Ignition switch: IG1) Ignition switch: ON

Battery voltage

10

CAN L

-

-

11

CAN H

-

-

WIRELESS CONTROL MODULE (WCM)

42C-83

DIAGNOSIS

SPECIAL TOOLS

M14209200003USA0000010000

Tool

Tool  number  and
name

Supersession

Application

MB991910

MB991826

YB9919580000

MB991911

MB991914

MB991824

MB991827

MB991825

Do not use

Do not use

a

b

c

d

e

f

g

MB991958

a.

MB991824

b.

MB991827

c.

MB991910

d.

MB991911

e.

MB991914

f.

MB991825

g.

MB991826

M.U.T.-III

 sub

assembly

a.

Vehicle
communication
interface (V.C.I.)

b.

M.U.T.-III

 USB

cable

c.

M.U.T.-III

 main

harness

 A

(Vehicles

 with

CAN
communication
system)

d.

M.U.T.-III

 main

harness

 B

(Vehicles  without
CAN
communication
system)

e.

M.U.T.-III

 main

harness  C  (for
Daimler  Chrysler
models only)

f.

M.U.T.-III
measurement
adapter

g.

M.U.T.-III  trigger
harness

MB991824-KIT

NOTE:

G: MB991826

M.U.T.-III Trigger
Harness is not
necessary when
pushing V.C.I. ENTER
key.

M.U.T.-III  main  harness  A
(MB991910)  should  be  used.
M.U.T.-III main harness B and C
should  not  be  used  for  this
vehicle.

｠

Check of the diagnostic trouble
code and service data

｠

Registration of ID codes

42C-84

WIRELESS CONTROL MODULE (WCM)

SPECIAL TOOLS

Tool

Tool  number  and
name

Supersession

Application

YB9912230000

Do not use

a

b

c

d

MB991223

a.

MB991219

b.

MB991220

c.

MB991221

d.

MB991222

Harness set

a.

Test harness

b.

LED harness

c.

LED

 harness

adaptor

d.

Probe

General service tools Continuity  check  and  voltage

measurement  at  harness  wire  or
connector  for  loose,  corroded  or
damaged  terminals,  or  terminals
pushed back in the connector.

a.

Connector

 pin

 contact

pressure inspection

b.

Power circuit inspection

c.

Power circuit inspection

d.

Commercial tester connection

MB992006

MB992006
Extra fine probe

-

Making  voltage  and  resistance
measurement

 during

troubleshooting

ON-VEHICLE SERVICE

ID CODES REGISTRATION PROCEDURE

M14209200048USA0000010000

The  ID  codes  necessary  for  the  engine  immobilizer
system, the keyless entry system and the TPMS can
be registered using the M.U.T.-III.

If  the  ignition  key  with  transmitter  is  added  or
replaced,  register  the  key  (key  ID),  and  then
register the keyless entry secret code again.

WIRELESS CONTROL MODULE (WCM)

42C-85

ON-VEHICLE SERVICE

SUPPLY UNIT LIST FOR INDIVIDUAL KEY

Ignition key (with transmitter)

NOTE:

Blank key (It is the key that

comes with the door service key set and
the glove box service key set. It can
only be used for locking and unlocking,
and it cannot start the engine.)

ZC6037530000

ZC6044010001

Blank key



KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY

Full service key set

Handle lock service key
set

Door service key set

Glove  box  service  key
set

ZC6045380000

ZC6045400000

ZC6045500000

ZC6045390000

NOTE:

｠

When re-registering the key (key ID), all the keys
(key  ID)  registered  before  must  be  re-registered
because all of them will be erased.

｠

After  registering  the  keys,  make  sure  that  the
engine  is  started  normally  with  all  of  the  keys
registered.

42C-86

WIRELESS CONTROL MODULE (WCM)

ON-VEHICLE SERVICE
