Mitsubishi Outlander XL. Manual - part 519

ZK603045

1

2

3

4

5

6

7

8

9

10

11

12

13

14

23 ± 3 N·m
17 ± 2 ft-lb

11 ± 1 N·m
97 ± 9 in-lb

68 ± 9 N·m
50 ± 7 ft-lb

23 ± 3 N·m
17 ± 2 ft-lb

90 ± 10 N·m
66 ± 7 ft-lb

23 ± 3 N·m
17 ± 2 ft-lb

23 ± 3 N·m
17 ± 2 ft-lb

22 ± 3 N·m
16 ± 2 ft-lb

23 ± 3 N·m
17 ± 2 ft-lb

90 ± 10 N·m
66 ± 7 ft-lb

AA00

<W6AJ>

Apply automatic
transmission fluid
to all moving parts
before installation.

1.

Transfer assembly

2.

FR roll stopper bracket

3.

RR roll stopper bracket

4.

Corrugate clamp bracket

5.

O-ring

6.

Oil filler tube

7.

Oil level gauge

8.

Corrugate clamp bracket

9.

Spring washer

10. Manual control lever
11. Harness bracket
12. Bracket control cable
13. Corrugate clamp bracket
14. Breather hose

AUTOMATIC TRANSAXLE OVERHAUL

23B-11

TRANSAXLE

ZK602952AA00

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

5.9 N·m
52 in-lb

4.9 N·m
43 in-lb

7.4 N·m
65 in-lb

7.9 N·m
70 in-lb

5.9 N·m
52 in-lb

5.9 N·m
52 in-lb

7.4 N·m
65 in-lb

7.9 N·m
70 in-lb

<F6AJ>

Apply automatic
transmission fluid
to all moving parts
before installation.

7.8 N·m
69 in-lb

1.

Park/neutral position switch

2.

Turbine sensor

23B-12

AUTOMATIC TRANSAXLE OVERHAUL

TRANSAXLE

3.

O-ring

4.

Baffle plate

5.

O-ring

6.

Transaxle assembly

7.

Torque converter

8.

O-ring

9.

ATF adjusting bolt

10. Detent spring
11. Control valve assembly

12. Control valve cover gasket
13. Control valve cover
14. Snap ring
15. Terminal assembly
16. Lip seal
17. Lip seal
18. Pressure test port bolt
19. O-ring

AUTOMATIC TRANSAXLE OVERHAUL

23B-13

TRANSAXLE

ZK602953

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19



AA00

<W6AJ>

Apply automatic
transmission fluid
to all moving parts
before installation.

1.

Park/neutral position switch

2.

Turbine sensor

3.

O-ring

4.

Baffle plate

5.

O-ring

6.

Transaxle assembly

23B-14

AUTOMATIC TRANSAXLE OVERHAUL

TRANSAXLE
