GENERAL INFORMATION
M11703000001USA0000010000
The emission control system consists of the
following subsystems:
｠
Positive crankcase ventilation system
｠
Evaporative emission system
｠
Exhaust emission control system
SERVICE SPECIFICATIONS
M11703000003USA0000010000
ITEM
STANDARD VALUE
Emission control system
EGR valve (Stepper Motor) connector resistance [at 20°C (68°F)] Ω
20 - 24
Evaporative emission purge solenoid coil resistance [at 20°C (68°F)] Ω
22 - 26
Evaporative emission ventilation solenoid coil resistance [at 20°C (68°F)] Ω
17 - 21
Purge flow cm3/s (SCFH) [at 80 - 95°C (176 - 205°F) with sudden revving]
20 (2.5)
DIAGNOSIS
M11703000007USA0000010000
SYMPTOM
PROBABLE CAUSE
REMEDY
Engine will not start or hard
to start
Vacuum hose disconnected or damaged
Repair or replace
The EGR valve (Stepper Motor) is not
closed.
Repair or replace
Malfunction of the evaporative emission
purge solenoid
Repair or replace
Rough idle or engine stalls
The EGR valve (Stepper Motor) is not
closed.
Repair or replace
Vacuum hose disconnected or damaged.
Repair or replace
Malfunction of the positive crankcase
ventilation valve
Replace
Malfunction of the purge control system
Check the system; If there is a
problem, check its component
parts.
Engine hesitates or poor
acceleration
Malfunction of the exhaust gas recirculation
system
Check the system; If there is a
problem, check its component
parts.
Excessive oil consumption
Positive crankcase ventilation line clogged
Check
positive
crankcase
ventilation system
Poor fuel mileage
Malfunction of the exhaust gas recirculation
system
Check the system; If there is a
problem, check its component
parts.
EMISSION CONTROL <MFI>
17c-3
GENERAL INFORMATION
