STEP 17. Check the harness between condenser fan relay
connector A-35X (terminal 2) and condenser fan motor
connector A-43 (terminal 1).
｠
Check the output line for short or open circuit.
Q:Is the check result normal?
YES:
Go to Step 18.
NO:
Repair the wiring harness.
STEP 18. Check for continuity at condenser fan motor
connector A-43.
(1)
Remove the condenser fan motor connector, and measure
at harness side.
ZC6036480000
A-43 Harness
connector:
Component side
(2)
Check that there is continuity between terminal number 2 and
body ground.
OK: Continuity (less than 2 ohms)
Q:Is the check result normal?
YES:
Go to Step 20.
NO:
Go to Step 19.
STEP 19. Check the harness between condenser fan motor
connector A-43 (terminal 2) and ground.
｠
Check the ground line for open circuit.
Q:Is the check result normal?
YES:
An intermittent malfunction is suspected (Refer to
GROUP 00, How to Use Troubleshooting/Inspection Service
Points - How to Cope with Intermittent Malfunctions P.
00-15).
NO:
Repair the wiring harness.
STEP 20. Check the harness between ETACS-ECU
connector C-312 (terminal 2) and radiator fan relay
connector A-34X (terminal 1).
｠
Check the ETACS-ECU input line for open circuit.
Q:Is the check result normal?
YES:
Go to Step 21.
NO:
Repair the wiring harness.
STEP 21. Check the harness between ETACS-ECU
connector C-312 (terminal 9) and fan control relay
connector A-36X (terminal 3).
｠
Check the ETACS-ECU input line for open circuit.
Q:Is the check result normal?
YES:
Go to Step 22.
NO:
Repair the wiring harness.
STEP 22. Check the harness between ETACS-ECU
connector C-312 (terminal 8) and condenser fan relay
connector A-35X (terminal 1).
｠
Check the ETACS-ECU input line for open circuit.
ENGINE COOLING
14-11
ENGINE COOLING DIAGNOSIS
