STEP 1. Using scan tool MB991958, read the diagnostic
trouble code (DTC).
ZC501967
AC404789
ZC5019680000
MB991824
MB991827
MB991910
Data link
connector
To prevent damage to scan tool MB991958, always turn the
ignition switch to the "LOCK" (OFF) position before
connecting or disconnecting scan tool MB991958.
(1)
Connect scan tool MB991958 to the data link connector.
(2)
Turn the ignition switch to the "ON" position.
(3)
Read the DTC.
(4)
Turn the ignition switch to the "LOCK" (OFF) position.
Q:Is DTC P1246 set?
YES:
Replace the ECM. When the ECM is replaced, register
the ID code. Refer to GROUP 42B, ID Code Registration
Judgment Table <Vehicles with KOS> P.42B-12or GROUP
42C, ID Code Registration Judgment Table <Vehicles with
WCM> P.42C-8.
NO:
It can be assumed that this malfunction is
intermittent. Refer to GROUP 00, How to Use
Troubleshooting/Inspection Service Points - How to Cope
with Intermittent Malfunctions P.00-15.
DTC P1247: A/T Plausibility
M11310100393USA0000010000
TECHNICAL DESCRIPTION
Checks for an abnormal signal of transmission control
module.
DTC SET CONDITIONS
Check Condition
｠
Ignition switch is "ON" position.
Judgment Criterion
｠
A torque demand signal from TCM is not normal.
TROUBLESHOOTING HINTS (The most likely
causes for this code to be set are:)
｠
Automatic transaxle system failed.
｠
ECM failed.
DIAGNOSIS
Required Special Tools:
｠
MB991958: Scan Tool (M.U.T.-III Sub Assembly)
｠
MB991824: V.C.I.
｠
MB991827: USB Cable
｠
MB991910: Main Harness A
MULTIPORT INJECTION SYSTEM (MFI) <DIAGNOSIS>
13Ab-655
DIAGNOSTIC TROUBLE CODE PROCEDURES
