Item
Specification
Exhaust manifold cover bolt
16 ± 4 N·m (13 ± 3 ft-lb)
Heated oxygen sensor
44 ± 5 N·m (35 ± 5 ft-lb)
Rocker arms and camshaft
Camshaft position sensor bolt
10 ± 2 N·m (89 ± 17 in-lb)
Camshaft position sensor support bolt
23 ± 6 N·m (17 ± 4 ft-lb)
Camshaft position sensing cylinder bolt
22 ± 4 N·m (17 ± 2 ft-lb)
Positive crankcase ventilation valve
2.5 ± 0.4 N·m (22 ± 3 in-lb)
Rocker arm adjusting nut
9.0 ± 1.0 N·m (80 ± 8 in-lb)
Rocker arms and shaft bolt exhaust side
13 ± 1 N·m (115 ± 8 in-lb)
Rocker arms and shaft bolt intake side
31 ± 3 N·m (23 ± 2 ft-lb)
Rocker cover bolt
8.3 ± 1.0 N·m (74 ± 8 in-lb)
Cylinder head and valve
Cylinder head bolt
45 ± 2 N·m (33 ± 1 ft-lb) → +150°
Oil pan and oil pump
Plate bolt
23 ± 6 N·m (17 ± 4 ft-lb)
Beam bolt
24 ± 2 N·m (18 ± 1 ft-lb) → +60°
Engine oil pressure switch
10 ± 2 N·m (89 ± 17 in-lb)
Drain plug
39 ± 5 N·m (29 ± 3 ft-lb)
Heat protector bolt
10 ± 2 N·m (89 ± 17 in-lb)
Oil filter <MD360935>
14 ± 2 N·m (124 ± 17 in-lb)
Oil filter <MD332687, MD365876>
16 ± 4 N·m (13 ± 3 ft-lb)
Oil filter cover bolt
23 ± 6 N·m (17 ± 4 ft-lb)
Oil pan cover bolt
10 ± 2 N·m (89 ± 17 in-lb)
Oil pan, lower bolt
10 ± 2 N·m (89 ± 17 in-lb)
Oil pan, upper bolt
10 ± 2 N·m (89 ± 17 in-lb)
Oil pump case bolt
23 ± 6 N·m (17 ± 4 ft-lb)
Oil screen bolt
20 ± 5 N·m (15 ± 3 ft-lb)
Piston and connecting rod
Connecting rod cap nut
20 ± 2 N·m (15 ± 1 ft-lb) → +90°
Crankshaft and cylinder block
Bank stiffener bolt
23 ± 6 N·m (17 ± 4 ft-lb)
Bearing cap bolt
24 ± 2 N·m (18 ± 1 ft-lb) → +90°
Crankshaft sensing ring bolt
12 ± 2 N·m (106 ± 17 in-lb)
Drive plate bolt
76 ± 4 N·m (57 ± 2 ft-lb)
Knock sensor
20 ± 2 N·m (15 ± 1 ft-lb)
Oil seal case bolt
10 ± 2 N·m (89 ± 17 in-lb)
Rear plate bolt
10 ± 2 N·m (89 ± 17 in-lb)
ENGINE OVERHAUL
11B-7
FASTENER TIGHTENING SPECIFICATIONS
