Mitsubishi Outlander XL. Manual - part 152

HANDS FREE SYSTEM

CIRCUIT DIAGRAMS

90-305

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

RADIO AND CD PLAYER
OR CD CHANGER

AUDIO VISUAL
NAVIGATION UNIT

HANDS FREE MODULE

<VEHICLES WITH MITSUBISHI
 MULTI-COMMUNICATION SYSTEM (MMCS)>

<VEHICLES WITHOUT MITSUBISHI
 MULTI-COMMUNICATION SYSTEM (MMCS)>

SPARE CONNECTOR (FOR TRAILER LIGHTS)

CIRCUIT DIAGRAMS

90-306

SPARE CONNECTOR (FOR TRAILER LIGHTS)

FUSIBLE
LINK

34

POWER
DISTRIBUTION
SYSTEM

ETACS-
ECU

STOPLIGHT
SWITCH

STOPLIGHT

TAILLIGHT,
POSITION LIGHT,
LICENSE PLATE
LIGHT AND
LIGHTING MONITOR
TONE ALARM

TURN-SIGNAL
LIGHT AND
HAZARD
WARNING LIGHT

SPARE CONNECTOR (FOR SWITCH BOX)

TAILLIGHT
CONTROL CIRCUIT

TURN-SIGNAL LIGHT
CONTROL CIRCUIT

·ANTI-LOCK
 BRAKING SYSTEM
 (ABS)
·ANTI-LOCK
 BRAKING SYSTEM
 (ABS)
 AND ACTIVE SKID
 CONTROL SYSTEM
 (ASC)
·AUTO-CRUISE
 CONTROL SYSTEM
·INVECS-II 6A/T

SPARE CONNECTOR (FOR TRAILER LIGHTS)

CIRCUIT DIAGRAMS

90-307

IG1
RELAY

IGNITION
SWITCH (IG1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

·BACKUP LIGHT
·INVECS-II 6A/T
·SUPPLEMENTAL
 RESTRAINT
 SYSTEM (SRS)

SPARE
CONNECTOR

FOR TRAILER
HARNESS

CONTROLLER AREA NETWORK (CAN)

CIRCUIT DIAGRAMS

90-308

CONTROLLER AREA NETWORK (CAN)

ETACS-ECU

FRONT SIDE

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

DATA LINK
CONNECTOR

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

NOTE

: ·BACKUP LIGHT

·INVECS-II 6A/T
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR TRAILER LIGHT)
