THEFT-ALARM SYSTEM

CIRCUIT DIAGRAMS

90-297

NOTES

HANDS FREE SYSTEM

CIRCUIT DIAGRAMS

90-298

HANDS FREE SYSTEM

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

MICROPHONE
UNIT

ETACS-
ECU

POWER
SUPPLY

HANDS
FREE
MODULE

·AUDIO SYSTEM

·CLOCK

·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT
 ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
 (FOR REAR DISPLAY)

: VEHICLES WITH MITSUBISHI

MULTI-COMMUNICATION SYSTEM (MMCS)

VEHICLES WITHOUT MITSUBISHI
MULTI-COMMUNICATION SYSTEM (MMCS)

:

NOTE

HANDS FREE SYSTEM

CIRCUIT DIAGRAMS

90-299

INPUT SIGNAL

OUTPUT SHAFT
SPEED SENSOR

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ETACS-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

HANDS
FREE
MODULE

TRANSMISSION
CONTROL
MODULE

HANDS FREE SYSTEM

CIRCUIT DIAGRAMS

90-300

HANDS FREE SYSTEM (CONTINUED)

CLOCK
SPRING

STEERING
AUDIO
SWITCH

COMBINATION
METER

CPU

RHEOSTAT

INTERFACE
CIRCUIT

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

ETACS-
ECU

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE SKID
 CONTROL SYSTEM
 (ASC)

<VEHICLES WITHOUT MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)>

THEFT-ALARM SYSTEM

·CLOCK
·ELECTRIC
 CONTROLLED AWD
·INVECS-II 6A/T
·TURN-SIGNAL
 LIGHT AND HAZARD
 WARNING LIGHT
