SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-237

SEAT BELT
PRE-TENSIONER (LH)

SEAT BELT
PRE-TENSIONER (RH)

LAP
PRE-TENSIONER

PASSENGER'S
(FRONT)
AIR BAG MODULE
(SQUIB)

NOTE

: CONNECTOR COUPLED : ON

CONNECTOR UNCOUPLED : OFF

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-238

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

SIDE IMPACT SENSOR
(FRONT : LH)

ACCELERO
METER

CPU

CPU

SIDE IMPACT SENSOR
(REAR : LH)

SIDE-AIR BAG MODULE
(SQUIB) (LH)

CURTAIN AIR BAG MODULE
(SQUIB) (LH)

ACCELERO
METER

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-239

CPU

CPU

SRS-ECU

SIDE IMPACT SENSOR
(FRONT : RH)

SIDE IMPACT SENSOR
(REAR : RH)

NOTE

: CONNECTOR COUPLED : ON

CONNECTOR UNCOUPLED : OFF

SIDE-AIR BAG MODULE
(SQUIB) (RH)

CURTAIN AIR BAG MODULE
(SQUIB) (RH)

ACCELERO
METER

ACCELERO
METER

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK SWITCH

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

CIRCUIT DIAGRAMS

90-240

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

ETACS-
ECU

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

SRS-ECU

NOTE

:

POWER
SUPPLY

·AIR CONDITIONING
 SYSTEM
·ANTI-LOCK BRAKING
 SYSTEM (ABS)
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE SKID
 CONTROL SYSTEM
 (ASC)
·CENTRAL DOOR
 LOCKING SYSTEM
·CONTROLLER AREA
 NETWORK (CAN)
·DAYTIME RUNNING
 LIGHT

·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT
 AND IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT AUTOMATIC
 LEVELING SYSTEM
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER
 TONE ALARM
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·KEYLESS OPERATING
 SYSTEM (KOS)

·POWER WINDOWS
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·TAILLIGHT, POSITION LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

·AC POWER
 SUPPLY
·ELECTRIC
 CONTROLLED
 AWD

·BACKUP LIGHT
·INVECS-II 6A/T
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR TRAILER LIGHT)
