3.
On Step 2 completion, if the seat belt is not fastened when
the vehicle speed changes from 3 km/h to 8 km/h, the
indicator illuminates and blinks again and the alarm sounds
again.
When the front passenger's seat belt is released
1.
When the ignition switch is turned ON, the front passenger's
seat belt indicator illuminates for 6 seconds, regardless of
whether the front passenger's seat belt is fastened or
released. The alarm does not sound.
2.
60 seconds after the ignition switch is turned ON, the front
passenger's seat belt reminder operates the same manner
as for the driver's seat belt that is released, but the alarm does
not sound.
PADDLE SHIFT CANCEL TONE ALARM
When the paddle shift switch is operated, the tone alarm sounds.
THEFT-ALARM FUNCTION
When the theft-alarm function is activated, the tone alarm
sounds.
KEYLESS OPERATION KEY REMINDER TONE ALARM
FUNCTION (VEHICLES WITH KOS)/IGNITION KEY
REMINDER TONE ALARM FUNCTION (VEHICLES WITHOUT
KOS)
With the ignition switch in the LOCK (OFF) position, when the
driver's door is opened with the ignition key inserted into the
ignition key cylinder or the keyless operation key left in the
vehicle, the tone alarm sounds.
LIGHT REMINDER TONE ALARM FUNCTION
With the ignition switch in the LOCK (OFF) position, when the
driver's door is opened with the tail light switch remaining ON,
the tone alarm sounds.
DOOR-AJAR WARNING TONE ALARM FUNCTION
With the ignition switch in the ON position, when any of the doors
(including the liftgate) is open and the vehicle speed information
sent via the CAN communication is 8 km/h or more, the tone
alarm sounds.
FREEZE WARNING TONE ALARM
When the ignition switch is in the ON position, if the ambient
temperature is at 0°C or below, the tone alarm sounds.
54A-22
CHASSIS ELECTRICAL
COMBINATION METER
