Mitsubishi Outlander XL. Manual - part 1319

LUGGAGE ROOM

M25200000130USA0000010000

ZC6002380000

Luggage floor board

<When tonneau cover is used>

<When tonneau cover is retracted>

Utility bar

Tonneau cover

Tonneau cover
fixing position

Rear side box

Luggage hook

Tonneau cover
fixing position

Luggage hook

Luggage floor box

｠

A utility bar that can be used as a hooking rail for
small articles or as a base for the storage tray has
been adopted to improve usability.

｠

The rear side box has been equipped to improve
usability.

｠

Two  upper  tonneau  cover  fixing  positions  have
been adopted. When the fixing point at the rear is
used, the second seats can be reclined even when
the  tonneau  cover  is  being  used.  Also,  the  third

tonneau  cover  fixing  position  has  been  added  to
near  the  floor  of  luggage  room  so  that  when  the
tonneau  cover  is  not  used,  it  can  be  fixed  on  the
luggage room floor. (Vehicles with tonneau cover)

｠

Luggage hooks have been installed to two positions
in  the  front  and  two  positions  in  the  rear  of  the
luggage room to provide several positions that can
accommodate large-size cargo such as a bicycle.

｠

Luggage  floor  box  has  been  equipped  to  the
luggage room floor to improve usability.

52A-12

INTERIOR

HEADLINING

HEADLINING

M25200000140USA0000010000

ZC604388AA00

Headlining

NOTE
       : Energy absorption rib positions

Interior design with safe material has been adopted,
achieving more safe and comfortable interior.

｠

Energy absorption ribs have been adopted to the
inside  of  headlining.  This  reduces  head  injuries
upon the secondary impact against the cabin during
a collision, and improves safety.

｠

Headlining which absorbs and dissolves chemical
substances  has  been  adopted.  This  headlining
efficiently absorbs and dissolves a smoking smell,
a life-smell, and formaldehyde*.

｠

Chemical  substances  such  as  formaldehyde  and
organic  solvent  generated  from  the  interior  parts
have  been  minimized  by  the  refined  material  and
method, improving amenity.

NOTE:

 *: Clear and colorless, toxic, irritating

odor

INTERIOR

52A-13

HEADLINING

MEMO

52A-14

INTERIOR

GROUP 52B

SUPPLEMENTAL RESTRAINT

SYSTEM (SRS)

CONTENTS

GENERAL INFORMATION............

52B-2

SYSTEM OPERATION...............

52B-9

ADVANCED AIRBAG AND SEAT BELT PRE-
TENSIONER......................

52B-9

SIDE AND CURTAIN AIR BAGS. . . . .

52B-10

SYSTEM CONSTRUCTION...........

52B-10

DRIVER'S AIR BAG MODULE.......

52B-10

CLOCK SPRING..................

52B-11

PASSENGER'S (FRONT) AIR BAG MODULE
..............................

52B-11

SIDE-AIRBAG MODULE............

52B-12

CURTAIN AIR BAG MODULE........

52B-12

FRONT IMPACT SENSOR...........

52B-13

SIDE IMPACT SENSOR............

52B-13

SEAT SLIDE SENSOR.............

52B-14

OCCUPANT CLASSIFICATION-ECU AND
WEIGHT SENSOR.................

52B-15

SEAT BELT WITH PRE-TENSIONER. .

52B-15

LAP BELT PRE-TENSIONER (LH). . .

52B-16

PASSENGER’S SEAT BELT WARNING LIGHT
..............................

52B-16

PASSENGER’S AIR BAG OFF INDICATOR
LIGHT.........................

52B-17

SRS-ECU.......................

52B-17

SRS AIR BAG SPECIAL CONNECTOR
..............................

52B-22

52B-1
