The division unit of each part has been enlarged,
also  the  gap  and  level  difference  between  the
instrument panel has been minimized.

｠

To the center of the instrument panel, a 1 DIN-sized
center  panel  box  has  been  adopted  to  improve
usability. (Vehicles without Premiumaudio)

｠

A  light  has  been  added  to  the  large-sized  lower
glove box with a key, and card and pen holders have
been installed for improved convenience.

｠

Approximately 40-mm deep, push-open type large-
size instrument panel upper box has been installed
to the upper center of the instrument panel.

｠

At the lower part of center panel, a center lower tray
that  can  store  up  to  13  CDs  has  been  installed.
Dropping of stored items in this tray during abrupt
start is prevented.

｠

To  improve  usability  while  driving,  a  built-in  cup
holder that can hold a 500-ml plastic bottle as well
as a side box that can store a cigarette box, lighter,

coins, or other small items is installed on the outer
side of the driver's seat.

｠

A  ashtray  that  can  be  moved  to  the  driver's  cup
holder or to the rear armrest has been equipped to
the front part of front floor console.

｠

A  console  cup  holder  that  can  store  two  20-oz
plastic bottles or brick packs has been installed in
the rear floor console. To improve the usability, it is
made to store 2 CDs in the upright position or pen-
size long articles horizontally when it is not used as
a cup holder.

｠

A  rear  floor  console  with  an  armrest  function  can
slide  65  mm  forward  and  backward,  and  a  tissue
box holder has been installed to the underside of
the armrest.

｠

An  armrest  box  that  can  store  a  mobile  phone,
cards,  pens,  and  other  small  items  has  been
installed to the rear floor console, and additionally,
a large rear floor console box that can store 10 CDs
or 6 DVDs has been installed under the rear floor
console.

52A-4

INTERIOR

SEAT

SEAT

FRONT SEAT

M25200000040USA0000010000

ZC6002410000

Seatback pocket

Head restraint

Seatback
frame

Cross frame

<Front/rear collision protection seat
mechanism>

Head restraint adjustment

Reclining adjustment

Height adjustment

Slide adjustment

The front seat offers the following advantages:

｠

The  seats  are  designed  to  be  adjustable  in  the
reclining and sliding directions.

｠

Head  restraints  with  a  vertical  adjustment
mechanism have been adopted.

｠

The  seat  height  adjustment  function  has  been
introduced to the driver’s seat. This function raises
and  lowers  the  seat  cushion  together  with  the
seatback, thus the driver's waist position in relation
to the seatback is always kept constant, resulting in
the  improved  riding  comfort.  By  expanding  the
height adjustment amount up to (Normal height: 47
mm,  Power  height:  46  mm),  the  more  optimized
driving  position  can  be  adjusted.  The  pump  type
seat height adjustment lever has been adopted for
convenient use.

｠

Some  models  are  equipped  with  leather  seats.
<Option>

｠

Some  models  have  a  dual  height  (front,  rear)
adjustment function in the driver’s seat. A motorized
power seat (reclining adjustment, slide adjustment,
dual  height  adjustment)  is  available  on  some
models. <Option>

｠

The driver's seat have seatback pockets for easier
use.

｠

The  frontal  and  rear-end  collision  protection  seat
structure (backward layout of seatback frame and
optimization  of  head  restraint  position)  has  been
adopted to improve safety during a collision at lower
vehicle speed. The cross frame has been installed
below the seat cushion to reduce the forward travel
distance of the passengers during a frontal collision
and has improved safety.

INTERIOR

52A-5

SEAT

SECOND SEAT

M25200000050USA0000010000

ZC601651

Folding lock unlocking lever

0000

Head restraint
adjustment

Reclining
adjustment

Slide
adjustment

Cup holder

: LATCH system anchors
: Tether anchorage positions

Folding structure

The second seats offer the following features.

｠

Reclining  adjustment  and  slide  adjustment
mechanisms  have  been  adopted  to  improve
amenity.

｠

Armrests with a cup holder have been installed to
improve convenience.

｠

Head restraints with height adjustment have been
installed to the outer seats.

｠

The  child  restraint  LATCH  system  is  installed  as
standard  on  the  outer  seats,  and  the  tether
anchorage on all the seats, improving the versatility
of  child  seat  installation.  Also,  because  the  seats
are  equipped  with  the  tether  anchor,  it  is  now
possible to slide the seat with a child seat installed.

52A-6

INTERIOR

SEAT

THIRD SEAT <7-seater>

M25200000060USA0000010001

ZC600431

<Overview of seat operation
(Folding => Seating)>

Underfloor folding

0000

(1) Pull out the seat back.
(2) Raise the headrest.
(3) Pull out the seat.
*The procedure of Seating => Folding
is the reverse order of the procedures
mentioned above.

<When folding into the underfloor>

①

②

③

Third seat

Third seat offers the following features.

｠

The third seat which can be folded underneath the
floor  has  been  adopted,  enabling  the  use  of  flat
luggage space.

｠

Urethane-less structure has been adopted for the
cushion, realizing an extremely thin cushion which
can be folded together with seatback and headrest.

MULTI SEAT ARRANGEMENT

M25200000080USA0000010000

This  vehicle  offers  a  wide  variety  of  seat
arrangements.

Item
Normal

ZC600243
