Adjustment
item (scan tool
MB991958
display)

Adjustment item

Adjusting

 contents

(scan  tool  MB991958
display)

Adjusting contents

Front

 wiper

operation

Adjustment  of  the
intermittent
windshield

 wiper

operation

Normal INT

Intermittent  wiper  interval  is  fixed  to  4
seconds.

Variable INT

Intermittent wiper interval is calculated only
by the wiper volume control.

Vehicle

 speed

dependent

Intermittent  wiper  interval  is  calculated
according to the intermittent wiper volume
control and vehicle speed (default).

Front

 wiper

washer

Disabling

 or

enabling

 washer-

linked

 wiper

function

Washer only

Without function

Washer-linked wiper

With function (default)

Rear

 wiper

intermittent
duration

Adjustment  of  rear
wiper interval

0 seconds

No wiper interval

4 seconds

4 seconds

8 seconds

8 seconds (default)

16 seconds

16 seconds

Rear  wiper  low
speed mode

Disabling

 or

enabling  rear  wiper
continuous
operation

Disabled

Without function (default)

Enabled

With function

51-14

EXTERIOR

CONFIGURATION FUNCTION

GROUP 52A

INTERIOR

CONTENTS

GENERAL INFORMATION............

52A-2

INSTRUMENT PANEL AND FLOOR CONSOLE
...............................

52A-3

SEAT...........................

52A-5

FRONT SEAT.....................

52A-5

SECOND SEAT....................

52A-6

THIRD SEAT <7-seater>..........

52A-7

MULTI SEAT ARRANGEMENT.........

52A-7

SEAT BELT......................

52A-9

TRIMS.........................

52A-10

INTERIOR TRIM.................

52A-10

DOOR TRIM.....................

52A-11

LUGGAGE ROOM..................

52A-12

HEADLINING....................

52A-13

52A-1

GENERAL INFORMATION

M25200000001USA0000010000

Functionality, interior comfort, and safety have been
emphasized, giving interior design for elegance and
relaxation space. Various measures have been taken
actively  to  protect  the  environment  and  recycle
resources.

FEATURES

Quality improvement

1.

Full interior trim

2.

Upper glove box

Usability improvement

1.

Armrest  (rear  floor  console,  rear  seat,  rear  door
trim)

2.

Cup holder (driver’s side, rear floor console, rear
seat armrest)

3.

Bottle holder

4.

Tonneau cover <Vehicles with tonneau cover>

5.

Luggage hook

Convenient boxes

1.

Lower glove box with key

2.

Pen holder, card holder (lower glove box)

3.

Seatback pocket (front seat)

4.

Side box (driver’s side)

5.

Center lower tray

6.

Armrest box

7.

Rear floor console box

8.

Rear side box (lower quarter trim RH)

9.

Door pocket (front door trim, rear door trim)

Safety improvement

1.

Front and rear collision protection seat mechanism
(front seat)

2.

Child restraint LATCH system (outer rear seats)

3.

Tether anchorage (rear seat)

4.

ELR 3-point seat belt (driver’s seat)

5.

ELR/ALR 3-point seat belt (passenger’s seat, rear)

6.

Seat belt retractor with a driver's side double pre-
tensioner and variable force limiter

7.

Seat  belt  retractor  with  a  passenger’s  side  pre-
tensioner and force limiter

8.

Headlining  energy  absorption  rib  <Vehicles
without curtain air bag>

Consideration for the optimum driving position

1.

Seat height adjustment (driver’s seat)

2.

Headrestraint with height adjustment (front, rear)

3.

Seat slide adjustment (front, rear)

Measures for resource recycling

1.

Aggressively  use  PP  materials  that  are  easy  to
recycle and easy to stamp material symbols on the
plastic (resin) parts.

2.

Reduction  of  chemical  material  (formaldehyde*,
organic solvent)

NOTE:

 *: Clear and colorless, toxic, irritating

odor

52A-2

INTERIOR

GENERAL INFORMATION

INSTRUMENT PANEL AND FLOOR CONSOLE

M25200000010USA0000010000

ZC600231

Card holder

Pen holder

0000

Upper glove box

Upper box

Tissue holder

Front floor console

Lower glove box

Rear floor console

Center lower tray

Side box

Built-in cup holder

Armrest box

Console cup holder

Rear floor
console box

Armrest

The instrument panel offers the following features:

INTERIOR

52A-3

INSTRUMENT PANEL AND FLOOR CONSOLE
